Specification
Tech Highlights
WEIGHT
- 24 lbs
RANGE
- 10+ miles
MAX SPEED
- 20 mph
PEDALS
- 0 (sweat-free)
MOTOR
- 300 Watt rear hub brushless electric motor
BATTERY
- Li-Ion 36V 4.2Ah 151.2Wh
BATTERY SAFETY
- Passed CPSC 16 CFR Part 1512, UL 2271 & UL 2272
POWER
- Single on/off button operated on throttle
THROTTLE
- Thumb-activated variable speed control
BATTERY LEVEL
- 3 LED power level on throttle
BATTERY ACCESS
- Removable, secured via barrel-key lock under frame
CHARGER
- 71W 10-240V, US plug, 1.7 A 41V output
CHARGE TIME
- ~3 hours
CHARGING
- Charge through frame or remove battery to charge
DIMENSIONS
- Ride Mode: 48” long x 21” wide x 39” high | Folded: 45” x 7” x 30”
WATER RESISTANCE
- IPX4 resistant to rain and water splashes. Non submersible
FRAME
- Monocoque 6061-T6 aluminum alloy
SEATPOST
- 7” adjustable range, replaceable
REAR TIRE
- 20” x 2.5” all-terrain tire
FRONT TIRE
- 20” x 1.95” all-terrain tire
TIRE TUBE
- Standard 20” x 1.5-2.5” inner tube
MIN TURN RADIUS
- 33” (84 cm) - capable of 180 degree turns in narrow hallways
MAX INCLINE
- 12% grade - or steeper with human-powered kick-stride assist with throttle
BRAKE
- Mechanical rear disc caliper with 180 mm rotor
HEIGHTS SUPPORTED
- 4’10” to 6’2”
WEIGHT SUPPORTED
- Up to 240 pounds (109 kg)
*All units are customizable! We can print and install a customized skin made by you to go on these bikes.
*Please contact us about bulk purchasing options. Get your business or brands logo on a fleet of jackrabbit mini ebikes today!
