CID Hydraulic Breakers / Hammers | CBR Series | Energy Class 225-1000 ft-lbs | 3.5–26.4 GPM | For Skid Steers
CID Hydraulic Breakers / Hammers | CBR Series | Energy Class 225-1000 ft-lbs | 3.5–26.4 GPM | For Skid Steers
Regular price
$6,366.00
Regular price
Sale price
$6,366.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
CID Hydraulic Breakers / Hammers | CBR Series | Energy Class 225-1000 ft-lbs | 3.5–26.4 GPM | For Skid Steers
DESCRIPTION
The Skid Steer Breaker/Hammer can be utilized by a variety of full size and mini skid steers. This attachment features easy maintenance and a low installation point which enables the breaker to lift higher and hammer more. You MUST consult the manual or specs sheet prior to buying to make sure you use the correct chisel. Ensure your skid steer meets the necessary operating capacity or specs to use this attachment.
Key Features
- Wide Compatibility – Fits excavators, skid steers, compact track loaders, and mini loaders (0.8–8.0 ton carriers).
- Energy Class Options – Models range from 225 ft‑lbs to 1,000 ft‑lbs for light to heavy demolition.
- Durable Build – Heavy‑duty steel construction with reinforced tool diameter (40–75 mm / 1.75–3.14 in).
- Optimized Pressure Range – Operating pressures from 90–170 kg/cm² (1,280–2,418 PSI) for efficient impact.
- High Blow Rate – Delivers 400–1,020 blows per minute, ensuring fast material breakage.
- Flexible Oil Flow – Supports 3.5–26.4 GPM, adaptable to various hydraulic systems.
- Compact & Lightweight – Operating weights from 122 kg (269 lbs) to 510 kg (1,124 lbs) for easy handling.
- Easy Maintenance – Lower installation point allows higher lift; simplified servicing reduces downtime.
- Specialized Applications – Ideal for pile driving, trenching, agricultural demolition, and commercial construction.
- Safety Requirement – Must use chisel paste (not grease) to prevent damage to breaker components.
Detailed Specifications
CBR225
| Specification | Value |
|---|---|
| Energy Class | 225 ft-lbs |
| Operating Weight | 122 kg / 269 lbs |
| Hose Length | 5'3" × 10'0" |
| Operating Pressure | 90–120 kg/cm² / 1,280–1,707 PSI |
| Tool Diameter | 40 mm / 1.75 in |
| Setting Pressure | 175 kg/cm² / 2,489 PSI |
| Oil Flow | 13–27 LPM / 3.5–7.2 GPM |
| Blow Rate (Long Stroke) | 540–1,020 bpm |
| Suitable Carrier | 0.8–2.5 tons |
CBR500
| Specification | Value |
|---|---|
| Energy Class | 500 ft-lbs |
| Operating Weight | 190 kg / 419 lbs |
| Hose Length | 5'3" × 10'0" |
| Operating Pressure | 90–120 kg/cm² / 1,280–1,707 PSI |
| Tool Diameter | 50 mm / 2.0 in |
| Setting Pressure | 175 kg/cm² / 2,489 PSI |
| Oil Flow | 27–50 LPM / 7.2–13.2 GPM |
| Blow Rate (Long Stroke) | 500–900 bpm |
| Suitable Carrier | 1.5–4.0 tons |
CBR650
| Specification | Value |
|---|---|
| Energy Class | 650 ft-lbs |
| Operating Weight | 260 kg / 618 lbs |
| Hose Length | 5'3" × 10'0" |
| Operating Pressure | 110–165 kg/cm² / 1,567–2,347 PSI |
| Tool Diameter | 60 mm / 2.75 in |
| Setting Pressure | 175 kg/cm² / 2,489 PSI |
| Oil Flow | 30–60 LPM / 8–16 GPM |
| Blow Rate (Long Stroke) | 450–800 bpm |
| Suitable Carrier | 3.0–7.0 tons |
CBR850
| Specification | Value |
|---|---|
| Energy Class | 850 ft-lbs |
| Operating Weight | 350 kg / 772 lbs |
| Hose Length | 5'3" × 10'0" |
| Operating Pressure | 120–165 kg/cm² / 1,707–2,347 PSI |
| Tool Diameter | 68 mm / 3.0 in |
| Setting Pressure | 175 kg/cm² / 2,489 PSI |
| Oil Flow | 40–80 LPM / 10.6–21.1 GPM |
| Blow Rate (Long Stroke) | 400–800 bpm |
| Suitable Carrier | 4.0–8.0 tons |
CBR1000
| Specification | Value |
|---|---|
| Energy Class | 1,000 ft-lbs |
| Operating Weight | 510 kg / 1,124 lbs |
| Hose Length | 5'3" × 10'0" |
| Operating Pressure | 140–170 kg/cm² / 1,991–2,418 PSI |
| Tool Diameter | 75 mm / 3.14 in |
| Setting Pressure | 175 kg/cm² / 2,489 PSI |
| Oil Flow | 50–100 LPM / 13.2–26.4 GPM |
| Blow Rate (Long Stroke) | 400–800 bpm |
| Suitable Carrier | 4.5–8.0 tons |
