Description
The DML/HY series forestry mulcher is the smallest, most versatile fixed hammer excavator mulcher on the market. Featuring an automatic variable displacement hydraulic motor, it avoids the need for any adjustment of hydraulic levels on the excavator it is mounted on. Ideal for mid-size excavators, this robust and compact mulcher is capable of handling various mulching tasks with exceptional performance and efficiency.
Features
- Welded Counterblades: Enhance cutting efficiency and durability.
- Diverter Valve: Facilitates smooth switching between different hydraulic functions.
- Customized Attachment Bracket with Pins: Ensures secure and adaptable attachment to various excavators.
- 55/38cc Variable Torque Hydraulic Piston Motor (21-36 gpm) (DML/HY/VT): Provides optimal power and performance for different hydraulic flow rates.
- Flow Control System Valve: Allows precise control of hydraulic flow, improving efficiency.
- Safety and Anticavitation Valve: Protects the hydraulic system from damage.
- Enclosed / Anti-Dust Machine Body: Shields internal components from dust and debris.
- Motor Enclosed in the Frame: Protects the hydraulic motor, enhancing durability and longevity.
- Belt Transmission: Ensures reliable power transfer to the mulching head.
- Bulkhead for Hydraulic Connections: Simplifies and secures hydraulic connections.
- Front Hood with Mechanical Adjustment: Enhances control and efficiency in mulching operations.
- Rear Hood with Mechanical Adjustment: Provides additional material handling capabilities.
- Protection Chains: Improve safety during operation.
- Supporting Service Leg: Assists in maintenance and stability during storage.
Specifications
| Model | DML/HY 75 | DML/HY 100 | DML/HY 125 | DML/HY/VT 75* | DML/HY/VT 100* | DML/HY/VT 125* |
|---|---|---|---|---|---|---|
| Flow Rate (gal/min) | 13-33 | 13-33 | 13-33 | 21-36 | 21-36 | 21-36 |
| Pressure (PSI) | 2611-3626 | 2611-3626 | 2611-3626 | 2611-5076 | 2611-5076 | 2611-5076 |
| Excavator Weight (t) | 5-13 | 5-13 | 5-13 | 5-13 | 5-13 | 5-13 |
| Working Width (in) | 31 | 39 | 49 | 31 | 39 | 49 |
| Weight (lbs) | 915 | 981 | 1135 | 926 | 992 | 1146 |
| Rotor Diameter (in) | 11.8 | 11.8 | 11.8 | 11.8 | 11.8 | 11.8 |
| Max Shredding Diameter (in) | 5 | 5 | 5 | 5 | 5 | 5 |
| No. Blades Type E | 20 | 24 | 30 | 20 | 24 | 30 |
Options
- 32/65 cc Variable Manual Displacement Hydraulic Piston Motor with Relief and Anticavitation Valve (28-53 gpm) (DML/HY)
- Hydraulic Front Hood
- Customized Setting Hydraulic Motor
- Customized Attachment Bracket with Pins and Leg
- Front Fixed Thumb Bracket
- Multiple Tooth Options
- Hydraulic Thumb
- Case Drain Required (Not Supplied with Hoses)
Standard Equipment
- 17/34 cc Variable Manual Displacement Hydraulic Piston Motor with Relief and Anticavitation Valve (13-33 gpm) (DML/HY)
- Bulkhead for Hydraulic Connections
- 55/38cc Variable Torque Hydraulic Piston Motor (21-36 gpm) (DML/HY/VT)
- Front Hood with Mechanical Adjustment
- Flow Control System Valve
- Rear Hood with Mechanical Adjustment
- Safety and Anticavitation Valve
- Enclosed / Anti-Dust Machine Body
- Supporting Service Leg
- Motor Enclosed in the Frame
- Welded Counterblades
- Belt Transmission
What's Included
- Forestry Mulcher with Fixed Tooth Rotor
- Customized Attachment Bracket with Pins
- 55/38cc Variable Torque Hydraulic Piston Motor
- Flow Control System Valve
- Diverter Valve
- Hydraulic Front Hood
- Safety and Anticavitation Valve
- Enclosed / Anti-Dust Machine Body
- Belt Transmission
- Bulkhead for Hydraulic Connections
- Front Hood with Mechanical Adjustment
- Rear Hood with Mechanical Adjustment
- Protection Chains
- Supporting Service Leg
