KIOTI | Hydrostatic Compact Tractor with Loader | CS Series | CS2510 | 46.7" Width | 24.5 HP | For Compact Farming & Landscaping
KIOTI | Hydrostatic Compact Tractor with Loader | CS Series | CS2510 | 46.7" Width | 24.5 HP | For Compact Farming & Landscaping
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
KIOTI | Hydrostatic Compact Tractor with Loader | CS Series | CS2510 | 46.7" Width | 24.5 HP | For Compact Farming & Landscaping
DESCRIPTION
The Kioti CS2510 Hydrostatic Tractor with Loader is a compact powerhouse designed for versatility and efficiency in various agricultural and landscaping tasks. With a robust 24.5 horsepower engine, this tractor is perfect for homeowners and professionals alike who need a reliable machine for small to medium-sized jobs.
Equipped with a hydrostatic transmission, the CS2510 offers smooth and responsive operation, allowing you to easily navigate through tight spaces and perform a variety of tasks. The tractor's loader enhances its functionality, making it ideal for lifting, moving, and transporting materials with ease.
With a fuel capacity of 6.7 gallons, the CS2510 is designed for extended use, minimizing downtime for refueling. Its compact dimensions, including a width of 46.7 inches and a turning radius of 8.2 feet, make it highly maneuverable, allowing you to work efficiently in confined areas.
Key Features
- Engine: KIOTI with 24.5 hp (18.3 kW) for powerful performance.
- Transmission: Hydrostatic for smooth and easy operation.
- PTO Power: 18.5 hp (13.9 kW) for powering various attachments.
- Hydraulic System: Pump capacity of 6.5 gpm (24.6 lpm) for efficient lifting and operation.
- Lift Capacity: 700 lbs (318 kg) for handling heavy loads.
- Compact Dimensions: Width of 46.7 inches and a turning radius of 8.2 feet for excellent maneuverability.
- Fuel Capacity: 6.7 gallons (25.5 liters) for extended operation.
- Weight: 1,485 lbs (675 kg) for stability and strength.
- Three-Point Hitch: Category 1 for easy attachment of implements.
- Mechanical Steering: For precise control and handling.
Detailed Specifications
| Category | Details |
|---|---|
| Model | CS2510 |
| Engine Model | 3C100LFH-U2 (KIOTI) |
| Engine Power | 24.5 hp (18.3 kW) |
| Displacement | 61.5 cu. in. (1,007 cc) |
| Fuel Type | Diesel |
| Fuel Capacity | 6.7 gal (25.5 L) |
| Transmission | Hydrostatic |
| PTO Power | 18.5 hp (13.9 kW) |
| PTO Speeds | Rear: 540 rpm / Mid: 2,200 rpm |
| Hydraulic Pump | Gear pump |
| Hydraulic Flow | 6.5 gpm (24.6 lpm) |
| Lift Capacity | 700 lb (318 kg) |
| 3-Point Hitch | Category 1 |
| Dimensions (L x W) | 99.3” x 46.7” |
| Height | 88” (2,226 mm) |
| Ground Clearance | 6.4” (162 mm) |
| Turning Radius | 8.2 ft (2.54 m) |
| Weight | 1,485 lb (675 kg) |
Comparison Chart
| Model | CS2510 | CS2220 | CK2610 |
|---|---|---|---|
| Horsepower | 24.5 hp | 21.1 hp | 24.5 hp |
| Transmission | Hydrostatic | Hydrostatic | Manual / HST Optional |
| Hydraulic Flow | 6.5 gpm | 6.0 gpm | 11.3 gpm |
| PTO Power | 18.5 hp | 15.0 hp | 19.5 hp |
| 3-Point Lift | 700 lb | 679 lb | 1,631 lb |
| Width | 46.7” | 45.8” | 54.5” |
| Weight | 1,485 lb | 1,452 lb | 2,679 lb |
| Best Use | Home/Garden, Loader Work | Lawn Care, Snow Blower | Loader, Backhoe, Small Farm |
