Product Description
KIOTI | Manual Tractor with Loader | CK3520SE | 54.5" Width | 34.9 HP | For Agricultural and Landscaping Tasks
DESCRIPTION
The Kioti CK3520SE Manual Tractor with Loader is a powerful and versatile machine engineered to handle a variety of agricultural, landscaping, and utility tasks. With a reliable 34.9-horsepower diesel engine, this open station tractor delivers dependable performance, whether you're tackling heavy lifting, material handling, or land preparation. Its manual Synchro Shuttle transmission, featuring 12 forward and 12 reverse speeds, ensures seamless shifting and precise control, adapting effortlessly to diverse terrains and applications.
Compact yet capable, the CK3520SE is equipped with an independent PTO system producing 30.9 horsepower, making it ideal for operating implements such as mowers, balers, and augers. The gear-driven hydraulic pump provides a flow rate of 11.3 GPM, with a three-point hitch lifting capacity of 1,631 lbs., enabling efficient operation with heavy-duty tools and attachments.
Designed with simplicity and operator convenience in mind, this tractor boasts intuitive controls, hydrostatic power steering, and ergonomic functionality, allowing users to work comfortably and confidently. Its robust construction, wet disc brakes, and excellent ground clearance ensure durability and reliability in challenging environments. Optional loader attachments enhance its versatility for material lifting, excavation, and other essential tasks.
Key Features
- Dependable Diesel Engine: A 34.9-horsepower KIOTI engine offers consistent power and fuel efficiency for various operations.
- Manual Synchro Shuttle Transmission: Includes 12 forward and 12 reverse speed ranges for smooth and precise handling across diverse tasks.
- Independent PTO System: Produces 30.9 PTO horsepower for efficient operation of implements like balers, mowers, and augers.
- Hydraulic Gear Pump: Provides 11.3 GPM of flow capacity for smooth operation of hydraulic-driven tools.
- Three-Point Hitch: Category 1 hitch with position control offers a lift capacity of 1,631 lbs., compatible with a variety of attachments.
- Operator-Friendly Design: Features intuitive controls, hydrostatic power steering, and an ergonomic open station layout for ease of use during long hours of operation.
- High Ground Clearance: Offers 13.4 inches of clearance, ensuring smooth navigation over rugged terrains.
- Durable Build: Wet disc brakes and a dry single clutch provide reliability and safety in tough conditions.
- Optional Loader Attachment: Expands the tractor’s capabilities for lifting, hauling, and material handling.
Detailed Specifications
| Specification | Details |
|---|---|
| Engine Power | 34.9 hp (26 kW) |
| Engine Displacement | 111.40 cu. in. (1,826 cc) |
| RPM | 2,600 rpm |
| Fuel Capacity | 9 gal (34 L) |
| Transmission | Manual Synchro Shuttle |
| Travel Speeds (Max Forward) | 14.88 mph (23.94 km/h) |
| Travel Speeds (Max Reverse) | 16.76 mph (10.41 km/h) |
| PTO Power | 30.9 hp (23 kW) |
| Rear PTO Speed | 540 rpm |
| Mid PTO Speed | 2,000 rpm (optional) |
| Pump Capacity | 11.3 gpm (42.9 lpm) |
| Hitch Category | Category 1 |
| Lift Capacity | 1,631 lbs. (740 kg) |
| Dimensions (Length) | 120.9 in (3,070 mm) |
| Width | 54.5 in (1,385 mm) |
| Weight | 2,906 lbs. (1,318 kg) |
| Ground Clearance | 13.4 in (340 mm) |
| Turning Radius | 8.96 ft (2.73 m) |
| Height | 92.9 in (2,360 mm) |
