Rotadairon STH Series Stone Buriers | Model STH-36 & STH-42 | Working Width 38" & 43" | Hydraulic Flow Range 30-55 GPM | For Mini Skid Steers

Rotadairon STH Series Stone Buriers | Model STH-36 & STH-42 | Working Width 38" & 43" | Hydraulic Flow Range 30-55 GPM | For Mini Skid Steers

$10,941.18
$10,941.18
Sale Sold out
Customizable
Fast
24/7 Support
  • 38" & 43" Working Widths Perfect for burying stones, tilling soil, and leveling surfaces in compact landscaping and turf renovation zones
  • Hydraulic Flow Range: 30–55 GPM Compatible with standard-flow mini skid steers for efficient rotor operation and soil engagement
  • Max Working Depth: 5.5 Inches Adjustable rear roller allows deep soil processing for seedbed prep and debris burial
View full details

Product Description

Rotadairon STH Series Stone Buriers | Model STH-36 & STH-42 | Working Width 38" & 43" | Hydraulic Flow Range 30-55 GPM | For Mini Skid Steers

DESCRIPTION

The STH Series Soil and Stone Burier is expertly designed for mini loaders, offering high-performance soil preparation and debris management in landscaping, green space renovation, and seedbed preparation. The STH 36 and STH 42 models provide flexibility with hitch options for Toro, Ditch Witch, Vermeer, and Bobcat loaders, plus adaptable options for custom carriers. This machine handles tough terrain, tilling, leveling, and burying stones, rubbish, and other debris to leave a clean, even surface ready for seeding.With an oversized rotor and Rotadairon® patented anti-pad blades, the STH Series efficiently overturns soil, buries detritus, and levels the surface. The height-adjustable rear roller provides precise depth control, while the hydraulic motor and oil-bath chain transmission ensure consistent performance.

Key Features

  • 38" & 43" Working Widths Perfect for burying stones, tilling soil, and leveling surfaces in compact landscaping and turf renovation zones
  • Hydraulic Flow Range: 30–55 GPM Compatible with standard-flow mini skid steers for efficient rotor operation and soil engagement
  • Max Working Depth: 5.5 Inches Adjustable rear roller allows deep soil processing for seedbed prep and debris burial
  • Oversized Rotor with 20 or 24 Blades Patented anti-sole blades invert soil and bury rocks, roots, and vegetation in a single pass
  • 400 mm Rotor Diameter Provides aggressive soil mixing and consistent depth control across varied terrain
  • Grid Finger Spacing: 22 mm (7/8") Filters out large debris while retaining fine soil for a smooth finish
  • Manual Forward Speed: 0.5–0.9 mph Optimized for controlled operation and thorough soil conditioning
  • Pressure Range: 200–250 Bars (2900–3625 psi) Ensures consistent hydraulic performance under demanding conditions
  • Compact Transport Dimensions STH-36: 52.25" × 60.75" × 24.5" STH-42: 56.75" × 60.75" × 24.5" — easy to store and maneuver on job sites
  • Multiple Hitch Options Available Models include Toro/Ditch Witch/Vermeer, Bobcat, and Adapt versions for flexible carrier compatibility
  • Operating Weight Range: 562–650 lbs Balanced for stability and effective ground contact without overloading mini loaders

Detailed Specifications

STH Series Light-Duty Stone Burier

Feature

STH 36

STH 42
Working Width 963 mm (38") 1100 mm (43.25")
Total Width 1330 mm (52.25") 1440 mm (56.75")
Weight 265 kg (584.2 lbs)
280 kg (650.3 lbs) – STH 36 B
255 kg (562.2 lbs) – STH 36 ADAPT		 285 kg (628.3 lbs)
275 kg (606.2 lbs) – STH 42 ADAPT
Hydraulic Flow Required 30–45 L/min (7.9–11.8 gpm) 40–55 L/min (10.5–14.5 gpm)
Pressure Range 200–250 Bars (2900–3625 psi) 200–250 Bars (2900–3625 psi)
Max Track Width 1.15 m (45.25") – STH 36
1.00 m (39.33") – STH 36 B		 1.30 m (51.25")
Working Depth (Max) 140 mm (5.5") 140 mm (5.5")
Rotor Outer Diameter 400 mm (15.75") 400 mm (15.75")
Blade Count 20 24
Grid Finger Spacing 22 mm (7/8") 22 mm (7/8")
Forward Speed 0.5–0.9 mph 0.5–0.9 mph
Transport Dimensions 1325×1545×620 mm
(52.25"×60.75"×24.5")		 1440×1545×620 mm
(56.75"×60.75"×24.5")
