Product Description
Solesbee’s | Excavator Rake | Models SGR Series | Width 30" To 54" Inches | Hydraulic & Manual Thumb Compatible | Machine Size 7 To 55 Tons | For Excavators
DESCRIPTION
The Solesbee’s Excavator Rake – SGR Series is built for heavy‑duty land clearing, site preparation, and debris removal. Designed for excavators from 9.5 – 39.5 tons (19,000 – 79,000 lbs), these rakes are available in widths from 30″ to 54″ and are fully compatible with both hydraulic and manual thumbs.
Manufactured in the USA from high‑strength ASTM A572 & A514 steel, the SGR Series features replaceable weld‑on wear strips for extended service life and is engineered to mesh perfectly with your thumb tine spacing for secure material handling. The pin‑on or quick‑coupler mounting options make installation simple, while the rugged tine design ensures maximum durability in demanding conditions.
Whether you’re clearing brush, sorting debris, or prepping a site, the SGR Series delivers the strength, precision, and versatility to get the most out of your excavator.
Key Features
- Machine Size Range – Fits excavators from 9.5 – 39.5 tons (19,000 – 79,000 lbs)
- Width Options – Available in 30″, 36″, 42″, 48″, and 54″ models
- Thumb Compatible – Works with both hydraulic and manual thumbs for secure material handling
- Heavy‑Duty Construction – Built from ASTM A572 & A514 high‑strength steel for maximum durability
- Replaceable Wear Strips – Weld‑on strips extend service life and reduce maintenance costs
- Precision Fit – Designed to match your thumb tine spacing and machine’s pin dimensions
- Mounting Flexibility – Pin‑on or quick‑coupler compatible for fast installation
- Versatile Applications – Ideal for land clearing, site prep, demolition debris sorting, and rock handling
- Made in the USA – Quality manufacturing for long‑term reliability in tough environments
Detailed Specifications
Excavator Class (lbs) |
Machine Size (tons) |
Rake Width |
Approx. Weight |
|---|---|---|---|
| 19,000 – 29,000 | 9.5 – 14.5 t | 36″ | 1,400 lbs |
| 30,000 – 40,000 | 15 – 20 t | 42″ | 1,800 lbs |
| 40,000 – 45,000 | 20 – 22.5 t | 42″ | 2,000 lbs |
| 41,000 – 59,000 | 20.5 – 29.5 t | 48″ | 2,200 lbs |
| 60,000 – 79,000 | 30 – 39.5 t | 54″ | 2,800 lbs |
Manuals & Documents
General Warranty Info:
- Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
