Product Description
Woody Equipment Forestry Trailer w/ Gooseneck Log Loader | Model 12-86 + 150-HD | Trailer Length 144" & Width 86" | Pull Type | For Tractors
Description
The Woody Equipment 12′ Forestry Trailer Model 12-86 with Log Loader 150-HD is a robust and versatile piece of machinery designed for efficient forestry operations. This trailer is ideal for forestry professionals looking for reliable and efficient equipment to handle their logging needs.
The 150-HD Woody Log Loader model is ideal for trucks and tractors from 50 HP and more. With its lift capacity that exceeds its competitors, this model is an excellent choice for the most demanding producers. It has a reach of 15'.
Key Features
- Heavy-Duty Construction: Built to withstand tough forestry conditions, ensuring durability and longevity.
- 12-Foot Trailer: Provides ample space for transporting logs and other materials.
- Log Loader 150-HD: Equipped with a powerful hydraulic log loader, making it easy to lift and move heavy logs.
- Compatibility: Designed to be used with tractors, enhancing its versatility and ease of use.
-
Safety Features: Includes various safety mechanisms to ensure secure and efficient operation.
This trailer and log loader combination is ideal for forestry operations, offering a balance of durability, capacity, and versatility.
Note: Each trailer model is interchangeable with each loader model.
Detailed Specifications
Forestry Trailer Specifications
| Category | Details |
|---|---|
| Compatible Log Loaders | Log loader 150 HD, 170 HD, 130 HD |
| Load Length | 12' |
| Overall Length | 17'9" |
| Overall Width | 86’’ |
| Gross Trailer Weight | 2,639 lb |
| Axle Capacity | 8,000 lb / each |
| Trailer Tonnage | 8 Tons / 16,000 lb |
| Volume | 290 Cubic Feet |
| Surface Area | 24.4 Square Feet |
| Surface Wood Cords | 0.76 Wood Cords (8’ Large X 4’ High) |
| Protective Grid | Inclusive |
| Number of Posts | 8 |
| Tires | 8 ply, 11L15 |
Log Loader Specifications
| Category | 150-HD |
|---|---|
| Recommended Vehicle | Tractors 40 HP & more |
| Boom Length | 15’ |
| Telescopic Boom | 36” on Teflon Strip (HDT Model) |
| Boom Rotation Swing | 300° |
| Loader Column Height | 75" |
| Max Lifting Capacity | 1,500 lb / 1,400 lb |
| Mid-Range Lifting Capacity | 3,000 lb / 2,900 lb |
| Recommended Flow | 4 - 8 GPM |
| Stabilizers | Telescopic |
| Grapple Open | 52" |
| Grapple Close | 3" |
| Grapple Rotation | 360° (Continuous) |
| Rotator Max Capacity | 3,000 kg |
| Total Weight (Without Trailer) | 2,000 lb / 2,100 lb |
Log Loader Options
| Option | Details |
|---|---|
| Hydraulic Winch | 6,000 lb |
| Power Unit (Honda) | 9 HP or 13 HP |
| Work Station | Available |
| Bucket Sizes | 14" or 18" |
