2024 Industrias America Angle Blade 170 | Cutting Width 7' | Horsepower 35 To 50 HP | For Tractors
2024 Industrias America Angle Blade 170 | Cutting Width 7' | Horsepower 35 To 50 HP | For Tractors
Regular price
$2,656.00
Regular price
Sale price
$2,656.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
2024 Industrias America Angle Blade 170 | Cutting Width 7' | Horsepower 35 To 50 HP | For Tractors
DESCRIPTION
The Industrias America 2024 Angle Blade 170 is a heavy-duty implement designed for efficient land maintenance, offering superior performance for grading, leveling, and snow removal tasks. Its 7ft cutting width ensures faster coverage, making it ideal for agricultural fields, landscaping projects, and other demanding applications.
With its robust construction and 3-point hitch compatibility, the Angle Blade 170 delivers reliable performance even in tough conditions. The adjustable blade angles provide the flexibility needed for diverse terrains and tasks, while the 2,600 lbs GVWR ensures stability and durability during operation.
Key Features
- Cutting Width: 84 inches (7 feet / 2.13 meters) – ideal for compact grading, snow removal, and landscaping.
- Tractor Horsepower Requirement: 35 To 50 HP – compatible with small to mid-size tractors.
- Mounting Type: 3-point hitch (Category I & II) – broad compatibility across tractor classes.
- Blade Type: Moldboard-style with replaceable cutting edge – durable and easy to maintain.
- Adjustable Angle: Manual angle adjustment – allows for directional control during grading or plowing.
- Overall Length: Approx. 36 inches (3 feet / 0.91 meters).
- Blade Height: Approx. 22 inches (0.56 meters) – provides solid material control.
- Weight: Approx. 480 To 550 lbs – balanced for effective ground engagement without overloading the tractor.
- GVWR: 2,600 lbs (1,179 kg) – rated for rugged field and utility work.
- Primary Applications: Land grading, snow removal, driveway maintenance, and landscaping.
- Finish: Available in standard red, black, or yellow – powder-coated for corrosion resistance.
Detailed Specifications
| Feature | Specification |
|---|---|
| Make | Industrias America |
| Model | Angle Blade 170 |
| Year | 2024 |
| Condition | New |
| Cutting Width | 84 inches (7 feet / 2.13 meters) |
| Overall Length | Approx. 36 inches (3 feet / 0.91 meters) |
| Height (Blade Panel) | Approx. 22 inches (0.56 meters) |
| GVWR | 2,600 lbs (1,179 kg) |
| Mounting | 3-Point Hitch (CAT I & II) |
| Adjustable Angle | Yes – Manual angle adjustment |
| Blade Type | Moldboard-style with replaceable edge |
| Weight | Approx. 480–550 lbs (depending on options) |
| Minimum Horsepower | 35–50 HP (tractor requirement) |
| Primary Use | Land grading, snow removal, landscaping |
| Color | May vary (standard red, black, or yellow) |
