Aircraft
|
| Weight (with propeller and battery) |
1250g±0.5g（EVO II Dual 640T RTK V3）
1237g±0.5g（EVO II Pro RTK V3) |
| Size(L*W*H) |
230*130*143mm（folded）
457*558*143mm（unfolded） |
| Wheelbase |
397 mm |
| Maximum Service Ceiling Altitude |
7000 m |
| Max ascent speed |
8 m/s (Ludicrous) |
| Max descent speed |
4 m/s (Ludicrous) |
| Max horizontal flight speed |
20m/s (Ludicrous) |
| Max flight distance (no wind) |
21 km |
| Max angular velocity |
120°/s |
| Max tilt angle |
33° (Ludicrous) |
| Max flight time |
36 min |
| Max hovering time (no wind) |
32 min |
| Operating temperature range |
-10℃ ~ 40℃ |
| Maximum resistance to wind |
Level 8 |
| Operating frequency |
902-928MHz (FCC Only)
2.400-2.4835GHz
5.725-5.850GHz (non-Japan)
5.650-5.755GHz (Japan Only) |
| Transmission power |
900M
FCC/ ISED：≤31dBm
2.4G
FCC/ ISED：≤32dBm
SRRC/CE/MIC/RCM：≤20dBm
5.8G (non-Japan) ; 5.7G (Japan)
FCC/ISED/SRRC/MIC：≤33dBm
CE/ RCM：≤14dBm |
|
Hovering accuracy
|
When RTK is enabled and working normally:
Vertical: ±0.1 m; Horizontal: ±0.1 m |
Vertical: ±0.1 m (when the visual positioning is working normally);
±0.5 m (when GPS works normally)
Horizontal: ±0.3 m (when the visual positioning is working normally);
±1.5 m (when GPS works normally) |
| Image position compensation |
The position of the camera center relative to the phase center of the airborne A-RTK antenna, under the body axis system: (-2.63, 0.31, 83.5) mm, and the photo EXIF coordinates have been compensated. The positive XYZ axis of the body axis system points to the front, right, and bottom of the aircraft respectively. |
| Internal storage |
8GB |
| SD storage |
max. support 256GB (UHS-3 or Class 10) |
GNSS
|
| Single frequency high sensitivity GNSS |
GPS+BeiDou+Galileo（Asia）
GPS+GLONASS+Galileo（Other areas） |
|
Multi-frequency multi-system high-precision RTK GNSS
|
Frequency points used：
GPS：L1/L2；
GLONASS：L1/L2；
BeiDou：B1/B2；
Galileo：E1/E5 |
| First positioning time: <50 s |
Positioning accuracy:
vertical 1.5 cm + 1 ppm (RMS);
Horizontal 1 cm + 1 ppm (RMS)
1 ppm means that the error increases by 1 mm for every 1 km the aircraft moves |
Gimbal
|
| Gimbal |
3-axis stabilization |
| Mechanical range |
Tilt: -135° to +45°;
Pan: -100° to +100° |
| Controllable rotation range |
Tilt: -90° to +30°;
Pan: -90° to +90° |
| Max control speed (Tilt) |
300°/s |
| Angular Vibration Range |
±0.005° |
Remote controller and image transmission
|
| Operating frequency |
902-928MHz (FCC Only)
2.400-2.4835GHz
5.725-5.850GHz (non-Japan)
5.650-5.755GHz (Japan Only) |
| Transmission power |
FCC：≤33dBm
CE：≤20dBm@2.4G，≤14dBm@5.8G
SRRC：≤20dBm@2.4G，≤33dBm@5.8G/5.7G |
| Max Transmission Distance (unobstructed, free of interference) |
FCC：15km
CE：8km |
| Display screen |
2048x1536 60fps |
| Battery |
5800mAh |
| Operating time |
~3 hours (Max. Brightness)
~4.5 hours (50% Brightness) |
| Charging time |
120 minutes |
| Internal Storage |
ROM 128GB |
Sensing system
|
| Sensing system type |
Omnidirectional sensing system |
| Forward |
Accurate measurement range: 0.5-18 m
Effective sensing speed: <12m/s
Viewing angle: Horizontal: 60°, Vertical: 80° |
| Backward |
Accurate measurement range: 0.5-16 m
Effective sensing speed: <12m/s
Viewing angle: Horizontal: 60°, Vertical: 80° |
| Upward |
Accurate measurement range: 0.5-10 m
Effective sensing speed: <5m/s
Viewing angle: Horizontal: 65°, Vertical: 50° |
| Downward |
Accurate measurement range: 0.5-10 m
Effective sensing speed: <5m/s
Viewing angle: horizontal: 100°, vertical: 80° |
| Left and right |
Accurate measurement range: 0.5-10 m
Effective sensing speed: <5m/s
Viewing angle: horizontal: 65°, vertical: 50° |
| Operating Environment |
Forward, Backward and Sides:
Surface with clear pattern and adequate lighting (lux > 15)
Upward:
Detects diffuse reflective surfaces (>20%)
(walls, trees, people, etc.)
Downward:
Surface with clear pattern and adequate lighting (lux > 15)
Detects diffuse reflective surfaces (>20%)
(walls, trees, people, etc.) |
EVO II Pro RTK V3 visual camera
|
| Sensor |
1 inch CMOS; 20M pixels |
| Lens |
FOV: 82°
35 mm format equivalent focal length: 29 mm
Aperture: f/2.8 - f/11
Focus range: 0.5 m to infinity |
| ISO range |
Video: 100-44000
Photos: 100-6400 |
| Shutter speed |
Photo mode: 1/8000 ~ 8s
Other: 1/8000 ~ 1/frame rates |
| Zoom |
1-16x (up to 3x lossless zoom) |
| Photo mode |
Single shot/Burst shooting/AEB/Time Lapse/HDR |
| Maximum photo size |
5472*3648 (3:2)
5472*3076 (16:9)
3840*2160 (16:9) |
| Image Format |
JPG (default) / DNG / JPG+DNG |
| Photo mode |
5472x3076P30/P25/P24
3840x2160P60/P50/P48/P30/P25/P24
2720x1528P60/P50/P48/P30/P25/P24
1920x1080P60/P50/P48/P30/P25/P24 |
| Video format |
MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
| Max bitrate |
120Mbps |
| Supported file system |
FAT32/exFAT |
EVO II Dual 640T RTK thermal camera
|
| Sensor |
Uncooled VOx Microbolometer |
|
Lens
|
FOV H33°V26° |
| Focal length 13mm |
| Zoom |
1-16x |
| Sensor resolution |
640*512 |
| Pixel size |
12μm |
| Wavelength range |
8 - 14μm |
| Temperature range |
High gain mode: -20° to +150°
Low gain mode: 0° to +550° |
| Temperature measurement accuracy |
±3℃ or ±3% of reading (whichever is greater)
@Environmental temperature-20℃~60℃ |
Accurate temperature
measurement distance |
2-20 meters |
| Video resolution |
640x512@30fps |
| Video format |
MOV / MP4 (Support H.264/H.265) |
| Camera resolution |
Infrared mode: 640*512
Picture-in-picture mode: 1920*1080, 1280*720 |
| Photo mode |
Single shot
Burst shooting: 3/5 frames, 3 is the default
Time Lapse:JPG: 2s/5s/7s/10s/20s/30s/60s |
| Photo format |
JPG (with irg file) |
EVO II Dual 640T RTK V3 visual camera
|
| Sensor |
1/2 inch CMOS; 48M effective pixels |
| Lens |
FOV: 79°
35 mm format equivalent focal length: 25.6 mm
Aperture: f/1.8
Focus range: 0.5 m to infinity (with auto focus) |
| ISO range |
Video: 100-64000
Photos: 100-6400 |
| Shutter speed |
Photo mode: 1/8000 ~ 8s
Other: 1/8000 ~ 1/frame rates |
| Zoom |
1-16x (up to 4x lossless zoom) |
| Photo mode |
Single shot/Burst shooting/AEB/Time Lapse/HDR imaging |
| Maximum photo size |
8192*6144（4:3）
4096*3072（4:3）
3840x2160（16:9） |
| Image Format |
JPG (default) / DNG / JPG+DNG |
| Video format |
MOV / MP4 |
| Video resolution |
3840x2160P60/P50/P48/P30/P25/P24
2720x1528P60/P50/P48/P30/P25/P24
1920x1080P60/P50/P48/P30/P25/P24 |
| Max bitrate |
120Mbps |
| Supported file system |
FAT32/exFAT |
Battery
|
| Capacity |
7100 mAh |
| Voltage |
11.55 V |
| Battery type |
LiPo 3S |
| Energy |
82 Wh |
| Weight |
365 g |
| Charging temperature range |
5℃ to 45℃ |
| Storage temperature and humidity |
-10~30℃，65±20%RH |
| Recommended storage temperature |
22-28℃ |
| Max charging power |
93W |
| Charging time |
90 minutes |
Charger
|
| Input |
100-240 V, 50/60 Hz, 1.5A |
| Output |
13.2 V ⎓ 5 A
5V⎓3A 9V⎓2A 12V⎓1.5A |
| Voltage |
13.2±0.1V |
| Rated power |
66W |
Multi-Charger
|
| Voltage |
13.2 V |
| Charging temperature range |
5℃ to 45℃ |
