Bedrock Attachments Long Reach Arm and Boom | Model EL320C-18-SCN | Reach 59' Ft | Machine Size 20-23 Tons | For Excavators CAT 320B/320C
DESCRIPTION
The Bedrock Attachments Long Reach Arm and Boom is specifically engineered to enhance the capabilities of CAT 320B and 320C excavators, making it the perfect solution for deep excavation, dredging, and precise material handling. With an 18-meter total reach, this attachment is manufactured using advanced engineering techniques, high-quality materials, and robotic welding, ensuring structural integrity, hydraulic efficiency, and optimal performance. Featuring a supporting structure, transportation and packing are made simple and efficient.
Key Features
- Extended Reach: 18m total reach with 9.7m boom and 8.3m stick, allowing for deeper excavation.
- High-Efficiency Bucket: 0.6m³ capacity, perfect for dredging and material handling.
- Precision Engineering: Computerized stress distribution analysis ensures maximum durability and optimal design.
- Advanced Manufacturing: Large-scale milling equipment improves welding precision.
- Premium Hydraulic System: Cold-rolled precision steel pipes, treated with phosphoric acid washing, reducing oil flow resistance and contamination.
- Top-Tier Welding: Robotic ultrasonic-tested welding ensures long-lasting reliability.
- Pin Hole Accuracy: High-quality boring machine ensures parallelism, providing flawless pin alignment.
- Surface Treatment: Fully sandblasted finish, offering a clean and polished appearance.
- Reliable Cylinders: Equipped with Bucket Cylinder, Stick Cylinder for smooth hydraulic operation.
- Robust Linkage: 315 Linkage system with 2 x 70mm Pins for enhanced attachment stability.
-
CE Certified: Meets strict European safety standards, ensuring quality and reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EL320C-18-SCN |
| Total Reach | 18m (59 ft) |
| Boom Length | 9.7m |
| Stick Length | 8.3m |
| Bucket Capacity | 0.6m³ |
| Pin Count | 8 |
| Pin Size | 2 x 70mm Pins |
| Hydraulic System | Cold-rolled precision steel pipes with phosphoric acid treatment |
| Welding Method | Robotic welding with ultrasonic non-destructive testing |
| Surface Treatment | Sandblasted for smooth finish |
| Transport Support | Supporting structure included for easier packing and shipment |
| Cylinder Type | Bucket Cylinder, Stick Cylinder |
| Linkage Type | 315 Linkage |
| Certification | CE Marked |
