Product Description
Bedrock Attachments Long Reach Arm and Boom | Model EL320D-18-SCN | Reach 59' Ft | Machine Size 20-23 Tons | For Excavators CAT 320-323D2L
DESCRIPTION
The Bedrock Attachments Long Reach Arm and Boom is designed to enhance the operational capabilities of CAT 320, 320GC, 320GX, 320D, 320DL, 320D2, 320D2L, 320D2GC, 323, 323GC, 323GX, 323DL, and 323D2L excavators, making it the perfect solution for deep excavation, dredging, and material handling. With an 18-meter total reach, this attachment ensures durability, hydraulic efficiency, and structural integrity, allowing for seamless performance in demanding job sites. The supporting structure simplifies packing and transportation, making logistics easier.
Key Features
- Extended Reach: 18m total reach with 9.7m boom and 8.3m stick, improving excavation depth.
- High-Efficiency Bucket: 0.6m³ capacity, optimized for dredging and material handling.
- Precision Engineering: Computerized stress distribution analysis optimizes structural durability.
- Advanced Manufacturing: Large-scale milling equipment enhances welding precision.
- Premium Hydraulic System: Cold-rolled precision steel pipes, finished with phosphoric acid washing, ensuring smooth oil flow and reducing hydraulic circuit contamination.
- Top-Tier Welding: Robotic ultrasonic-tested welding guarantees maximum structural integrity.
- Pin Hole Accuracy: High-quality boring machine ensures parallelism, providing flawless pin alignment.
- Surface Treatment: Fully sandblasted finish, offering a clean and polished appearance.
- Reliable Cylinders: Equipped with Bucket Cylinder, Stick Cylinder for smooth hydraulic operation.
- Robust Linkage: 315 Linkage system with 2 x 70mm Pins for enhanced attachment stability.
-
CE Certified: Meets strict European safety standards, ensuring quality and reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EL320D-18-SCN |
| Total Reach | 18m (59 ft) |
| Boom Length | 9.7m |
| Stick Length | 8.3m |
| Bucket Capacity | 0.6m³ |
| Pin Count | 8 |
| Pin Size | 2 x 70mm Pins |
| Hydraulic System | Cold-rolled precision steel pipes with phosphoric acid treatment |
| Welding Method | Robotic welding with ultrasonic non-destructive testing |
| Surface Treatment | Sandblasted for smooth finish |
| Transport Support | Supporting structure included for easier packing and shipment |
| Cylinder Type | Bucket Cylinder, Stick Cylinder |
| Linkage Type | 315 Linkage |
| Certification | CE Marked |
