Product Description
Checchi & Magli Nitro Power Shock (NPS) | Pressure Regulation Range 5 To 50 Bar | Higher Compaction Up To +60% | For Tractors
Included Options:
- NPS 2 Rows: For 2-row transplanting systems.
- NPS 3 Rows: Optimized for 3-row transplanting.
- NPS 4 Rows: Designed for 4-row setups.
- NPS 5 Rows: Enhanced packing for 5-row configurations.
- NPS 6 Rows: Ideal for large-scale, 6-row applications.
DESCRIPTION
Efficient Soil Compaction for Transplanting Success
The Checchi & Magli Nitro Power Shock (NPS) is engineered to provide superior packing pressure for compacting wheels on transplanting equipment. Designed to optimize the planting process, it enhances soil moisture retention and ensures rapid rooting and better root development for healthy, robust seedlings. Perfect for clay and hard soils, the NPS ensures the best agronomic outcomes with its adjustable pressure range.
This system’s independence from the tractor's hydraulic pressure ensures consistent performance without system imbalances. A compact and user-friendly design allows seamless integration into existing transplanting equipment. Experience enhanced seedling survival rates, faster plant establishment, and superior crop growth with the Nitro Power Shock.
Key Features
- Purpose: Ensures greater packing pressure on compacting wheels.
- Recommendation: Ideal for clay and hard, compact soils.
- Independence: Functions separately from the tractor to avoid hydraulic imbalances.
- Pressure Application: Individually applies pressure on each transplanting unit using a parallel system.
- Pressure Range: Adjustable from 5 to 50 Bar, achieving up to 60% higher compaction.
- Oscillation Maintenance: Ensured by a hydro-pneumatic nitrogen accumulator via double-articulated parallelograms.
- Design: Compact and retrofit-friendly for existing machinery.
- Versatility: Supports configurations for 2, 3, 4, 5, and 6-row transplanting units.
- Enhanced Root Development: Encourages moisture preservation and rapid rooting.
- Robust Build: Durable materials for reliable, long-term operation.
Detailed Specifications
| Feature | Details |
|---|---|
| Pressure Regulation Range | 5 to 50 Bar |
| Compaction Efficiency | Up to +60% higher compaction |
| Row Configurations Available | 2, 3, 4, 5, and 6-row systems |
| Oscillation Maintenance | Hydro-pneumatic nitrogen accumulator |
| System Independence | Works independently of tractor hydraulics |
| Material Compatibility | Ideal for clay and hard, compact soils |
| Design | Compact, retrofit-friendly |
In Package
- Nitro Power Shock unit
- Installation manual
- Required fittings and hardware
- Manufacturer warranty documentation
