CID Hydraulic Angle Broom Attachment | 48" to 96" Multiple Working Width | For Skid Steer

Name: CID Hydraulic Angle Broom Attachment | 48" to 96" Multiple Working Width | For Skid Steer
Brand: CID
Price: 4602.0 USD
Availability: InStock

$4,602.00

Sale Sold out

Product variants

Quantity

305-391-2008

Info@rippingitoutdoors.com

Powerful Sweeping Action: High-torque reversible motor ensures efficient sweeping of dirt, snow, and debris in large areas.
Hydraulic Angle Adjustment: Easily angles 22.62° left or right with a built-in 2" hydraulic cylinder for flexible operation.
Customizable Wafer Options: Standard 8" core with 26" wafers or upgrade to 10" core with 32" wafers; choose between Poly for normal sweeping or Steel for aggressive debris removal.
Robust Build: Made with high-quality materials and a powder-coated finish for durability and corrosion resistance.
Versatile Compatibility: Options for universal, 8-pin, or 14-pin wiring harnesses to fit your skid steer setup.

View full details

Product Description

CID Hydraulic Angle Broom Attachment | 48" to 96" Multiple Working Width | For Skid Steer

Included Options

Universal Wiring Harness (+$312)
7 Pin Harness (+$393)
8 Pin Pigtail (+$125)
14 Pin Pigtail (+$125)

DESCRIPTION

The CID Hydraulic Angle Broom Attachment is a versatile and powerful tool designed for skid steers, making it perfect for clearing dirt, snow, and debris from roads, parking lots, warehouses, and more. Equipped with a high-torque reversible motor, this broom delivers reliable performance for heavy-duty sweeping tasks.

The broom's hydraulic angle adjustment allows you to sweep 22.62° to the left or right effortlessly, improving efficiency and control. Choose between Poly wafers for standard sweeping or Steel wafers for tackling tougher debris. With options for an upgraded broom core and wiring harness compatibility, this attachment can be customized to meet your specific needs.

Durable, American-made, and finished with a powder coat, the CID Hydraulic Angle Broom is built to last, offering professional-grade performance for all your sweeping needs.

Key Features

Reversible high-torque motor for powerful sweeping action.
Hydraulic angle adjustment: 22.62° left or right with a 2" x 6" cylinder.
Wafer options: Poly (standard sweeping) or Steel (aggressive cleaning).
Core options: 8" (standard) or 10" (upgrade) with 26" or 32" wafers.
Durable powder-coated finish for corrosion resistance.
Available wiring harness options: Universal, 8-pin, or 14-pin.
Compatible with all skid steers equipped with standard mounting plates.

Detailed Specifications

CD-HAB Models (48" and 60")

Feature	CD-HAB48	CD-HAB60
Width (in)	48	60
Weight (lbs)	564	635
Broom Angle (°)	22.62	22.62
Motor Type	High-Torque Reversible	High-Torque Reversible
Wafer Material	Poly or Steel	Poly or Steel
Hydraulic Cylinder (in)	2 x 6	2 x 6

CD-HAB Models (72" and 84")

Feature	CD-HAB72	CD-HAB84
Width (in)	72	84
Weight (lbs)	706	747
Broom Angle (°)	22.62	22.62
Motor Type	High-Torque Reversible	High-Torque Reversible
Wafer Material	Poly or Steel	Poly or Steel
Hydraulic Cylinder (in)	2 x 6	2 x 6

CD-HAB96 Model

Feature	CD-HAB96
Width (in)	96
Weight (lbs)	765
Broom Angle (°)	22.62
Motor Type	High-Torque Reversible
Wafer Material	Poly or Steel
Hydraulic Cylinder (in)	2 x 6

In Package

Skid Steer Hydraulic Angle Broom
Universal Skid Steer Mounting Plate
Hydraulic Hoses
Flat Faced Couplers
Owner's manual
