CID 63", 66" & 72" STEER STANDARD GRAPPLE RAKE FOR SKID STEER
CID 63", 66" & 72" STEER STANDARD GRAPPLE RAKE FOR SKID STEER
Regular price
$2,524.00 USD
Regular price
Sale price
$2,524.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Share
CID 63", 66" & 72" STEER STANDARD GRAPPLE RAKE FOR SKID STEER
DESCRIPTION
The Standard Skid Steer Grapple Rake from CID is a versatile attachment designed for various tasks, including land clearing, debris management, and yard cleanup. Here are some key features:
- Efficient Design: The grapple rake efficiently collects and deposits materials into neat piles. Whether you’re dealing with brush, shrubbery, storm debris, or demolition remnants, this attachment can handle it.
- Durable Construction: Constructed with top-quality 1/2" steel, this grapple rake is engineered to withstand demanding applications. It’s built to last and tackle tough jobs.
- Enhanced Gripping Power: The addition of teeth tines improves the attachment’s gripping power, allowing you to handle materials effectively.
- Quick Attachment Changes: With a full opening of 51", the grapple rake features a quick attach-system. This makes it easy to switch between attachments as needed.
- Superior Protection: The powder coating and included hoses with protective sleeves ensure durability and longevity.
What's Included?
- Skid Steer Grapple Rake
- Universal Skid Steer Mounting Plate
- Hoses
- Flat Faced Couplers
- Owner's manual
SPECIFICATIONS
- Hydraulic cylinders rated at 4000 psi, opening to 51"
- 2" Bore 10" Stroke
- 1/2" Top Quality Grade 50 Steel
- Powder Coated
Model 63"
- Width ("): 63
-
Standard Duty Weights (lbs.): 455
- Heavy Duty Weights (lbs.): 777
- X-Treme Weights(lbs.): 850
-
Standard Duty HP: 35-50
-
Heavy Duty HP: 45-65
-
X-Treme Duty HP: 65+
- Bore Size ("): 2
- Stroke Cylinders ("): 10
Model 66"
- Width ("): 66
- Standard Duty Weights (lbs.): 487
-
Heavy Duty Weights (lbs.): 805
-
X-Treme Weights(lbs.): 863
-
Standard Duty HP: 35-50
-
Heavy Duty HP: 45-65
-
X-Treme Duty HP: 65+
- Bore Size ("): 2
-
Stroke Cylinders ("): 10
Model 72"
- Width ("): 72
- Standard Duty Weights (lbs.): 750
- Heavy Duty Weights (lbs.): 867
- X-Treme Weights(lbs.): 867
-
Standard Duty HP: 35-50
-
Heavy Duty HP: 45-65
-
X-Treme Duty HP: 65+
- Bore Size ("): 2
-
Stroke Cylinders ("): 10
