Product Description
CID X-Treme Duty Rock Grapple Attachment | Working Width 66" to 84" inches | Tine Spacing 3" inches | For Skid Steer
DESCRIPTION
The CID X-Treme Duty Rock Grapple Attachment is the ultimate tool for skid steers handling demanding tasks like debris removal, rock handling, and land clearing. Built with Grade 50 & AR400 steel, this grapple ensures unmatched durability for the toughest jobs. Its dual independent grapple arms, powered by 2” bore x 10” stroke hydraulic cylinders, provide precision and secure handling of heavy materials.
With 3” tine spacing, this attachment efficiently separates smaller debris while securely grappling larger materials like rocks, logs, and brush. The hydraulic cylinders are protected by heavy-duty covers to ensure longevity and reliability, even in the harshest working conditions.
Available in 66", 72", 78", 81", and 84" widths, the CID X-Treme Duty Rock Grapple is versatile and compatible with most skid steers. Whether you're clearing land, moving debris, or handling hard materials, this American-made attachment is built to deliver superior performance.
Key Features
- Durable Construction: Built with 3/8” and 5/8” Grade 50 & AR400 steel to handle the heaviest loads.
- Efficient Tine Spacing: 3” tine spacing separates smaller debris while securely handling larger materials.
- Dual Grapples: Two independent grapple arms powered by heavy-duty hydraulic cylinders for precision handling.
- Cylinder Protection: Hydraulic cylinders are shielded by protective covers to prevent wear and damage.
- Wide Application: Suitable for handling rocks, brush, logs, and debris in various land management tasks.
Detailed Specifications
| Feature | 66” Model | 72” Model | 78” Model | 81” Model | 84” Model |
|---|---|---|---|---|---|
| Weight (lbs.) | 1000 | 1029 | 1087 | 1116 | 1145 |
| Width (") | 66 | 72 | 78 | 81 | 84 |
| Cylinders | 2” Bore x 10” Stroke | 2” Bore x 10” Stroke | 2” Bore x 10” Stroke | 2” Bore x 10” Stroke | 2” Bore x 10” Stroke |
| Tine Spacing (") | 3 | 3 | 3 | 3 | 3 |
| Tine Material | 3/8” A36 Steel | 3/8” A36 Steel | 3/8” A36 Steel | 3/8” A36 Steel | 3/8” A36 Steel |
| Grapple Arm Material | 5/8” A36 Steel | 5/8” A36 Steel | 5/8” A36 Steel | 5/8” A36 Steel | 5/8” A36 Steel |
