Erskine High Capacity Grapple Bucket | 72", 84" & 96" Model | With Bolt-On Cutting Edge | For Skid Steer
Erskine High Capacity Grapple Bucket | 72", 84" & 96" Model | With Bolt-On Cutting Edge | For Skid Steer
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Erskine High Capacity Grapple Bucket | 72", 84" & 96" Model | With Bolt-On Cutting Edge | For Skid Steer
DESCRIPTION
Heavy-Duty Grapple for Secure Transport and Loading
The ERSKINE High Capacity Grapple Bucket is built for versatile, heavy-duty farm and construction tasks. With powerful 3,000 lb. hydraulic cylinders, it grips securely, making it ideal for transporting large bales, debris, and other materials. Its robust design with slender tines ensures safe handling while preserving bale integrity, making it a perfect choice for farmers and landscapers.
Designed for Durability and Efficiency
Available in three model sizes, the ERSKINE Grapple Bucket is constructed to handle the rigorous demands of any job. Four durable tines firmly secure your load, while the bolt-on cutting edge offers reinforced strength and increased wear resistance. Whether loading round bales or moving heavy materials, this grapple bucket ensures reliable and efficient performance.
Key Features
- Four Tines: Secures the load effectively
- Hydraulic Cylinders: 2 cylinders, 3,000 lb. capacity each
- Slender Tines: Maintains bale integrity during transport
- Three Model Sizes: Available in 72”, 84”, and 96” widths
- Ideal for Transport: Suitable for large, round bales and heavy loads
- Reinforced Cutting Edge: Bolt-on edge for enhanced durability
- Heavy-Duty Build: Grade 50 steel construction
- Easy Handling: Designed for skid steer compatibility
- High Load Capacity: Built for demanding farm and construction use
- Reliable Performance: Tested for durability and longevity
Detailed Specifications
| Specification | 72” Model |
|---|---|
| Part Number | 901115 |
| Shipping Weight | 1,075 lb. |
| Operating Weight | 1,025 lb. |
| Width | 72” |
| Height (Grapple Open) | 78.5” |
| Height (Grapple Closed) | 46.25” |
| Max Opening | 75” |
| Hydraulic Cylinders | 2" x 10" (2) |
| Number of Tines | 4 |
| Tine Material | 5/8” Grade 50 |
| Specification | 84” Model |
|---|---|
| Part Number | 901116 |
| Shipping Weight | 1,150 lb. |
| Operating Weight | 1,100 lb. |
| Width | 84” |
| Height (Grapple Open) | 78.5” |
| Height (Grapple Closed) | 46.25” |
| Max Opening | 75” |
| Hydraulic Cylinders | 2" x 10" (2) |
| Number of Tines | 4 |
| Tine Material | 5/8” Grade 50 |
| Specification | 96” Model |
|---|---|
| Part Number | 901117 |
| Shipping Weight | 1,225 lb. |
| Operating Weight | 1,175 lb. |
| Width | 96” |
| Height (Grapple Open) | 78.5” |
| Height (Grapple Closed) | 46.25” |
| Max Opening | 75” |
| Hydraulic Cylinders | 2" x 10" (2) |
| Number of Tines | 4 |
| Tine Material | 5/8” Grade 50 |
In Package
- ERSKINE High Capacity Grapple Bucket (72", 84", or 96" model)
- Bolt-on cutting edge
- User manual and maintenance guide
- Warranty documentation
Available Options
- Model Sizes: 72”, 84”, and 96” widths
- Hydraulic Cylinder Options: 2 x 3,000 lb. cylinders
- Tine Material: Grade 50 steel tines
