Product Description
Erskine Industrial Grapple Rake | 60", 72" & 84" Model | With Flat Faced Couplers | For Skid Steer
DESCRIPTION
The Erskine Industrial Grapple Rake is an incredibly versatile and robust attachment for skid steers, designed to tackle the toughest tasks. With its high-strength T-1 steel construction and powerful hydraulic cylinders, this grapple rake easily handles heavy debris such as logs, brush, rocks, and concrete. Its large 48" opening and curved teeth make it ideal for efficient raking and lifting without damaging the ground, enhancing your cleanup, demolition, and landscaping efforts.
Available in 60", 72", and 84" models, this grapple rake is built for demanding applications. The design includes tubular steel construction for added strength, durable hydraulic cylinders, and a fully enclosing grapple that secures debris tightly. Whether used as a root rake, storm cleanup tool, or for demolition, the Erskine Grapple Rake offers reliability and performance for heavy-duty operations.
Key Features
- Versatility: Capable of handling debris, including logs, rocks, and concrete
- Durable Construction: Built with T-1 steel for maximum durability
- Large Opening: Opens up to 48", accommodating large items
- Powerful Jaws: Securely clamps and holds materials
- High-Strength Teeth: T-1 steel teeth, nearly three times stronger than standard steel
- Hydraulic Power: Equipped with two 3,000 lb. hydraulic cylinders
- Wide Opening: Opens to a full 48" for large material handling
- Curved Teeth: Glide over the ground, ideal for surface raking without damage
- Multiple Uses: Ideal for clearing, storm cleanup, demolition, and raking
- Tubular Steel Frame: Provides enhanced strength and resilience
Detailed Specifications
| Specification | Details |
|---|---|
| Model | 60" / 72" / 84" |
| Part Number | 900316 / 900317 / 900318 |
| Shipping Weight | 730 lb / 865 lb / 950 lb |
| Operating Weight | 680 lb / 815 lb / 900 lb |
| Overall Width | 61.25" / 73.25" / 85.25" |
| Overall Depth | 33.6" |
| Width Between Teeth | 7.5" |
| Height with Teeth Closed | 37.6" |
| Maximum Height with Teeth Open | 46.3" |
| Maximum Opening | 48" |
| Grapple Teeth (Upper) | 7 / 9 / 11 |
| Grapple Teeth (Lower) | 8 / 10 / 12 |
| Hydraulic Cylinders | 3" x 8" (2) |
| Tooth Construction | 1/2” T-1 |
In Package
- Erskine Industrial Grapple Rake attachment (60", 72", or 84" model)
- Flat-Faced Couplers
- Hydraulic Cylinder Set (2 x 3,000 lb)
- Product Manual and Installation Guide
Available Options
- Additional Flat-Faced Coupler Sets
- Enhanced Hydraulic Hose Kits
- Extended Warranty Options
