Product Description
Farmer Helper | Commercial Centered Flail Mower | Model FMC Series | Working Width 49" To 78" | Horsepower 24 To 65 HP | For Tractor
DESCRIPTION
The Farmer-Helper FH-FMC Series Flail Mower is built for tough mowing, clearing, and landscaping tasks. Designed with a commercial-centered cutting width, the FH-FMC delivers consistent results for row mowing and mulching of prunings. The reinforced deck and advanced clump buster bars make it perfect for managing vegetation between rows, leaving behind a clean and even finish.
With powerful 27-ounce hammer-style blades, this flail mower can tackle grass, weeds, and brush with ease. The adjustable rear roller adds versatility, allowing operators to modify the cutting height to match various terrain conditions. Optional "Y" blades provide additional functionality, ideal for heavier cutting tasks such as mulching rocks.
Whether you need to mow rows in orchards, vineyards, or open fields, the Farmer-Helper FMC Flail Mower offers the performance and durability needed to handle a range of landscaping tasks. Upgrade your mowing operations today with a commercial flail mower that delivers precision, adaptability, and superior results.
Key Features
- Commercial-centered flail design ensures precise row mowing in orchards, vineyards, and fields.
- Compatible with tractors from 24 to 65 HP using Category I or II 3-point hitches.
- Reinforced 4mm housing and 5/16″ side plates offer long-lasting durability in tough conditions.
- 65 HP cast-iron gearbox delivers consistent power to blades via multiple drive belts
- Available in working widths from 49″ to 78″ to suit small plots or large acreage.
- Hammer-style blades (27 oz) efficiently mulch grass, weeds, and brush up to 1″ thick.
- Optional “Y” blades provide enhanced cutting for rocky terrain and heavier vegetation.
- Adjustable rear roller with mud scraper allows cutting height control from 0 to 6 inches.
- Balanced rotor tube minimizes vibration, reducing wear and improving operator comfort.
- Rotor swing diameter of 15″ builds blade inertia for cleaner, more powerful cuts.
- Under-deck clump buster bars break up debris for a smoother, more even finish.
- Multiple belt configurations (2 to 4 belts) ensure reliable power transmission across models.
- Weights range from 581 lbs to 865 lbs, offering stability and compatibility with various tractor sizes.
- Ideal for mowing between crop rows, clearing pasture, and maintaining roadside vegetation.
- Optional hydraulic offset kit allows lateral adjustment for hard-to-reach areas and fence lines.
Detailed Specifications
| Model | FH-FMC125 |
|---|---|
| Working Width | 49” |
| Overall Width | 55” |
| Min. HP Requirement | 24 HP |
| Hitch Type | Cat I |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 20 |
| Optional “Y”/Rock Blades | 40 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 15” |
| Number of Belts | 2 Belts |
| Weight | 581 lbs |
| Model | FH-FMC135 |
|---|---|
| Working Width | 53” |
| Overall Width | 59” |
| Min. HP Requirement | 26 HP |
| Hitch Type | Cat I |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 20 |
| Optional “Y”/Rock Blades | 40 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 15” |
| Number of Belts | 2 Belts |
| Weight | 616 lbs |
| Model | FH-FMC145 |
|---|---|
| Working Width | 57” |
| Overall Width | 63” |
| Min. HP Requirement | 28.5 HP |
| Hitch Type | Cat I |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 24 |
| Optional “Y”/Rock Blades | 48 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 15” |
| Number of Belts | 3 Belts |
| Weight | 646 lbs |
| Model | FH-FMC155 |
|---|---|
| Working Width | 61” |
| Overall Width | 67” |
| Min. HP Requirement | 30 HP |
| Hitch Type | Cat I |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 24 |
| Optional “Y”/Rock Blades | 48 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 15” |
| Number of Belts | 3 Belts |
| Weight | 665 lbs |
| Model | FH-FMC175 |
|---|---|
| Working Width | 69” |
| Overall Width | 75” |
| Min. HP Requirement | 34 HP |
| Hitch Type | Cat I |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 28 |
| Optional “Y”/Rock Blades | 56 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 15” |
| Number of Belts | 4 Belts |
| Weight | 718 lbs |
| Model | FH-FMC195 |
|---|---|
| Working Width | 78” |
| Overall Width | 83” |
| Min. HP Requirement | 35 HP |
| Hitch Type | Cat I or II |
| Gear Box Rating | 65 HP |
| Standard Hammer Blades | 32 |
| Optional “Y”/Rock Blades | 64 |
| Housing Thickness | 4mm |
| Side Plate Thickness | 5/16” |
| Rotor Diameter | 4” |
| Rotor Shaft Diameter | 4 1/2” |
| Blade Swing | 14” |
| Number of Belts | 4 Belts |
| Weight | 865 lbs |
