JMA Attachments Hydraulic Hammer | Model JMA-400 Dingo | Energy Class 280 Joules | For Skid Steers
JMA Attachments Hydraulic Hammer | Model JMA-400 Dingo | Energy Class 280 Joules | For Skid Steers
Regular price
$3,626.70
Regular price
Sale price
$3,626.70
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
JMA Attachments Hydraulic Hammer | Model JMA-400 Dingo | Energy Class 280 Joules | For Skid Steers
Description
Maximize your skid steer's demolition potential with the 280 Joules Hydraulic Hammer for Skid Steers. Engineered specifically for Skid Steers, this compact powerhouse brings unparalleled breaking force to your most challenging jobs. Transform your skid steer into a demolition dynamo. The 280 Joules Hydraulic Hammer for Skid Steers is your key to tackling tough breaking tasks with precision and power.
Key Features
- Impressive Power: 280 Joules energy class delivers exceptional breaking capabilities in a compact package.
- Rapid Performance: 800 - 1,400 bpm impact frequency ensures swift material processing.
- Optimized Pressure: 90 - 120 kgf/m² operating pressure for efficient hydraulic system integration.
- Durable Construction: Built with AR400 Steel for longevity in demanding conditions.
- Ready for Action: Includes 2 Hydraulic Hoses,1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 4 Bushings for immediate deployment.
Detailed Specifications
| Attribute | Value |
|---|---|
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Energy Class (J) | 280 Joules |
| Energy Class (ft·lb) | 206.52 ft·lb |
| Impact Frequency (bpm) | 800 - 1,400 bpm |
| Operating Pressure (kgf/m²) | 90 - 120 kgf/m² |
| Operating Pressure (lbs/ft²) | 18.43 - 24.58 lb/ft² |
| Oil Flow (GPM) | 3.96 – 5.28 gpm |
| Accessories Included | 2 Hydraulic Hoses, 1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 4 Bushings |
| Tool Chisel Bit Diameter (mm) | 40 mm |
| Tool Chisel Bit Length (mm) | 450 mm |
| Working Weight (kg) | 102 kg |
| Product Weight (lbs) | 407.38 lb |
| Product Weight (kg) | 184.78 kg |
