Larson Electronics 77' Hydraulic Megatower™ Light Plant - 33' Trailer - (20) LED Lamps - 20KW Genset - Auto Retract

Products Discription

Larson Electronics 77' Hydraulic Megatower™ Light Plant - 33' Trailer - (20) LED Lamps - 20KW Genset - Auto Retract

Discription

The WCDE-20KW-8X250LTL-LED-2.L09-1.L22-2.N10-M1 mobile light tower from Larson Electronics is a towable and self-contained lighting system equipped with a 20kW generator. This high-powered unit operates eight 240-watt LED lamps, producing a combined 259,200 lumens for optimal illumination over an 8-9 acre area, with a telescoping mast that reaches up to 30 feet. This robust lighting solution is ideal for emergency services, large-scale events, construction sites, mining operations, and other demanding environments requiring continuous lighting.

Key Features

• Power & Runtime: Driven by a Kubota 31.3 HP diesel engine, with a 20kW brushless generator and a 60-gallon fuel tank for prolonged use.
• LED Performance: Eight 240-watt LED lamps providing 32,400 lumens each, with a total output of 259,200 lumens, covering 8-9 acres.
• Heat Management: Individual heat sinks per LED bank enable 90% drive capacity without overheating, with an LED life expectancy of 80,000 hours.
• Durability: IP67-rated for resistance to dust, water, and extreme temperatures, with die-cast aluminum housing and high-transmission PMMA optics.
• Controls: Deepsea DSE3110 controller with manual or auto start, providing real-time monitoring, alarms, and safety features.
• Versatile Lighting: Independently adjustable light heads with 360° rotation, 50 mph wind resistance, and 4-point outrigger stability.
• Certifications: NRTL Certified to UL 1640, TAA, and Buy American Compliant.

Applications: Ideal for remote sites, temporary camps, construction zones, military operations, and other areas without reliable grid access.

 Detailed Specifications

• Generator: 20kW, Kubota engine, 60Hz, 120/240V single-phase.
• Lighting: Eight Cree® LED lamps (240W each, 259,200 total lumens).
• Fuel: 60-gallon tank supporting continuous operation.
• Mast: 30-foot height, aluminum, 4-section telescoping, 360° rotation.
• Trailer: 14-gauge steel, 12ga chassis, 2,200 lbs axle, DOT-approved lighting, adjustable outriggers with 2,000 lbs jacks.

Designed and manufactured in Texas, this unit adheres to high standards for durability and functionality, making it suitable for the most rigorous applications.
