LJ-TECH AG ORCHARD AUTONOMOUS SPRAYER MODEL S1000 WITH SMART REMOTE CONTROL
LJ-TECH AG ORCHARD AUTONOMOUS SPRAYER MODEL S1000 WITH SMART REMOTE CONTROL
Couldn't load pickup availability
LJ-TECH AG ORCHARD AUTONOMOUS SPRAYER MODEL S1000 WITH SMART REMOTE CONTROL
DESCRIPTION
The LJ Tech S1000 is an impressive advancement in orchard robotics, offering a range of intelligent features and systems designed to enhance efficiency and precision in agricultural tasks. A complete and intelligent product that can spray autonomously by satellite navigation
Core Systems:
- Intelligent Spraying System
- Intelligent Control System
- Intelligent Drive System
SPECIFICATIONS
- Unmanned Navigation: Operates autonomously along a planned path, with interchangeable start and end points.
- Visual Navigation (Iterative): Enables unmanned operation even under weak signal conditions.
- Extended Range Endurance: Combines a diesel engine with a lithium battery, intelligently balancing the dynamic load using a generator.
- Intelligent Spray: Stops spraying when the vehicle stops, turns, or passes tree gaps.
- Intelligent Supply (Iterative): Features intelligent field edge parking, cluster supply, and coordinated operation of multiple machines.
- Intelligent Control: Includes cruise control, remote start/stop, obstacle detection, and early warning systems.
- Real-time Monitoring: Allows remote monitoring of engine, battery, and pesticide status via mobile phone, with alarms for any issues.
- Multifunction (Iterative): Capable of spraying, weeding, and transporting, with modular assembly.
- Fixed Amount of Pesticide per Acre: Automatically adjusts spray volume based on vehicle speed after setting the desired pesticide amount per acre.
| Section | Parameter | Specification |
|---|---|---|
| Overall Dimensions | Power dimensions | 4330mm x 1130mm x 2100mm (H) |
| Unloaded weight | 250kg | |
| Max. load type | 200kg | |
| Ground clearance | 200mm | |
| Track chassis | Chassis | |
| Power System | Engine power | 36.8kW / 50hp |
| Drive speed | 0-4km/h | |
| Endurance time | ≥4h | |
| Climbing angle | ≤30° | |
| Generator power | 48V | |
| Electric engine power | 13kW | |
| Lithium battery | 72V 100Ah | |
| Water Tank Capacity | Rated flow rate | ≥10L/min |
| Water tank capacity | ≥100L | |
| Number of nozzles | ≥2 | |
| Atomization System | Nozzle type | Rotary |
| Flow rate | ≤30m³/h | |
| Nozzle effective width | 4220cm | |
| Positioning Accuracy | Ways of navigation | Autopilot; RTK |
| Positioning accuracy | ±15cm | |
| Cloud Platform | Interactive System | PC, Big data management platform, APP of Smart phone |
OPTIONS
Smart remote control
- Serial No.: 1
- Supporting Hardware: Controller
Low level stop alarm
- Serial No.: 2
- Supporting Hardware: Liquid level gauge
Intelligent supply
- Serial No.: 3
- Supporting Hardware: Liquid level gauge knit
Stop spraying when turning around
- Serial No.: 4
- Supporting Hardware: Mobile Base Station
- Upcharge per unit: USD $1500
Unmanned Navigation without 4G/CORS net
- Supporting Hardware: Mobile Base Station
- Upcharge per unit: USD $1500
Single side spray
- Supporting Hardware: Solenoid valve kit, otc
- Upcharge per unit: USD $2000
Setting pesticide litres per hectare
- Supporting Hardware: Flow gauge
- Upcharge per unit: USD $2000
