Product Description
MAZIO DEMOLITION TOOLS FPV SERIES PULVERIZER | FPV-6 TO FPV-100 MODELS | WIDTH 13-37.4" INCHES | FOR EXCAVATORS
DESCRIPTION
The Mazio FPV Series pulverizers have been designed to work on the ground. As a result, they satisfy all the secondary demolition needs and make perfect recycling and pulverizing jobs. That’s why the load and the transport of demolition result material will be easier and simpler.
Key Characteristics
- Designed for Ground-Level Work: Tailored for secondary demolition needs. Ideal for recycling and pulverizing tasks. Eases load and transport of demolition materials
- Robust Construction: 100% HARDOX steel structure. Reversed cylinder to protect the rod from accidental strikes
- Efficiency and Productivity: Speed valve in some models. Innovative PRV (Pressure Relief Valve) system to protect from high pressur. Regenerative installation for fast idle movements and maximum thrust
- User-Friendly Design: Interchangeable teeth and blades for ease of maintenance. Designed for significant productivity and efficiency
Key Features
- 100% HARDOX Steel Structure: Ensures maximum durability and longevity.
- Reversed Cylinder: Protects the rod from accidental strikes, enhancing the lifespan.
- Interchangeable Teeth: Easily replaceable for sustained performance.
- Speed Valve (on some models): Enhances operational efficiency.
- Innovative PRV (Pressure Relief Valve) System: Safeguards the pulverizer from high pressure.
- Regenerative Installation: Enables rapid idle movements and maximum thrust in seconds for high productivity.
- Interchangeable Blades: Allows for quick and efficient blade replacement.
-
Engineered for the toughest jobs, designed for maximum efficiency!
Detailed Specifications
FPV 6 & FPV 12
| Attribute | FPV 6 | FPV 12 |
|---|---|---|
| Opening (mm/in) | 510 / 20 | 700 / 27 |
| Length (mm/in) | 1300 / 51 | 1920 / 76 |
| Width (mm/in) | 330 / 13 | 400 / 15.75 |
| Carrier (Ton) | 6-7 | 12-17 |
| Weight (Kg/lbs) | 500 / 1102 | 1100 / 2425 |
| Oil Pressure (Bar/psi) | 250 / 3625 | 310 / 4495 |
| Oil Flow (L/min/gal/min) | 80-100 / 21-26 | 180-220 / 47-58 |
FPV 17 & FPV 20.1
| Attribute | FPV 17 | FPV 20.1 |
|---|---|---|
| Opening (mm/in) | 815 / 32 | 850 / 34 |
| Length (mm/in) | 2080 / 82 | 2300 / 91 |
| Width (mm/in) | 460 / 18.1 | 550 / 21.65 |
| Carrier (Ton) | 16-20 | 21-29 |
| Weight (Kg/lbs) | 1550 / 3417 | 2050 / 4520 |
| Oil Pressure (Bar/psi) | 340 / 4930 | 340 / 4930 |
| Oil Flow (L/min/gal/min) | 200-240 / 52-63 | 220-300 / 58-79 |
FPV 30.1 & FPV 45
| Attribute | FPV 30.1 | FPV 45 |
|---|---|---|
| Opening (mm/in) | 1040 / 41 | 1080 / 42.5 |
| Length (mm/in) | 2660 / 105 | 2700 / 106 |
| Width (mm/in) | 600 / 23.6 | 600 / 23.6 |
| Carrier (Ton) | 30-45 | 40-60 |
| Weight (Kg/lbs) | 2800 / 6173 | 4500 / 9921 |
| Oil Pressure (Bar/psi) | 340 / 4930 | 340 / 4930 |
| Oil Flow (L/min/gal/min) | 280-340 / 73-90 | 300-350 / 79-92 |
FPV 60 & FPV 100
| Attribute | FPV 60 | FPV 100 |
|---|---|---|
| Opening (mm/in) | 1130 / 44.5 | 1800 / 71 |
| Length (mm/in) | 2800 / 110 | 3200 / 126 |
| Width (mm/in) | 750 / 29.9 | 950 / 37.4 |
| Carrier (Ton) | 60-80 | 80-130 |
| Weight (Kg/lbs) | 5400 / 11904 | 10400 / 22928 |
| Oil Pressure (Bar/psi) | 340 / 4930 | 340 / 4930 |
| Oil Flow (L/min/gal/min) | 400-500 / 106-132 | 500-600 / 132-158 |
