Product Description
MTW | RTS Power Rake | Series 3 | Carbide & Replaceable Teeth | Sizes 84" To 120" | 50" Length | 8" Rotor | High Flow 30-40 GPM | Heavy Universal Mount | For Skid Steer Attachments
DESCRIPTION
Unleash the power of heavy-duty performance with the MTW RTS Skid Steer Power Rake Series 3. Designed for the most demanding applications, this robust attachment is more than just a power box rake; it’s a versatile surface preparer that excels in tackling tough jobs with ease. Whether you're working on hard-packed clay, gravel alleyways, or preparing surfaces for landscaping, the Series 3 delivers exceptional results every time.
Crafted with an industry-leading 3/8 inch wall frame tube, 2-inch diameter rotor shafts, and a #100 chain, the Series 3 stands out in its class. Its formidable construction allows it to rip through the toughest materials while leaving behind a smooth, high-quality finish. With the MTW RTS Power Rake Series 3, you can confidently take on any project, knowing you have the right tool for the job.
Key Features
- Heavy-Duty Construction: Built with a 3/8 inch wall frame tube and reinforced skid mounts for unmatched durability and stability.
- Powerful Performance: Designed for high-flow skid steers operating at 30 to 40 GPM, ensuring optimal efficiency in heavy-duty applications.
- Versatile Rotor Options: Equipped with an 8-inch diameter rotor, the rake is compatible with various rotor types, including carbide replaceable teeth for extended wear.
- Smooth Surface Finishing: Capable of ripping through tough surfaces while providing a smooth finish, making it ideal for landscaping and site preparation.
- Multiple Size Options: Available in 84", 96", and 120" working widths to accommodate a range of project sizes and requirements.
- Choice of Angling Mechanisms: Select between manual angle or hydraulic options for precise control during operation.
Detailed Specifications
| Model | Mount Type | Overall Width | Overall Height | Working Width | Weight | Angled Width 10° | Angled Width 20° | Chain Type | Rotor Diameter |
|---|---|---|---|---|---|---|---|---|---|
| PR384H CR | Heavy Universal | 94" | 35" | 84" | 1,425 lbs | 81" | 78" | #80 Heavy | 8" |
| PR384H RT | Heavy Universal | 94" | 35" | 84" | 1,425 lbs | 81" | 78" | #80 Heavy | 8" |
| PR396H CR | Heavy Universal | 106" | 35" | 96" | 1,530 lbs | 93" | 90" | #80 Heavy | 8" |
| PR396H RT | Heavy Universal | 106" | 35" | 96" | 1,530 lbs | 93" | 90" | #80 Heavy | 8" |
| PR3120H CR | Heavy Universal | 130" | 35" | 120" | 1,640 lbs | 117" | 114" | #80 Heavy | 8" |
| PR3120H RT | Heavy Universal | 130" | 35" | 120" | 1,640 lbs | 117" | 114" | #80 Heavy | 8" |
