Product Description
Paladin Auger Drive 2" Hex | 30" Max Auger | For Excavator
DESCRIPTION
The Paladin X1475D Auger Drive with a 2" hex drive is a versatile and powerful attachment for excavators, designed to handle augers up to 30 inches in diameter. Equipped with McMillen's 75 Series hydraulic motor, the auger drive offers consistent torque through a fully sealed planetary gear reduction system, ensuring reduced maintenance and increased durability. Its rugged construction and hydraulic relief valve provide protection from damage when encountering tough obstructions. The auger drive supports reverse rotation, allowing quick backout in challenging drilling conditions. Ideal for various excavation applications, the auger drive can be customized with several mount options, including wedge and pin grabber mounts, making it compatible with excavators from top brands like Kubota, John Deere, Volvo, and Yanmar.
With the optional cradle and a design that requires no hoses, the X1475D auger drive is adaptable to multiple setups and excavation requirements. Built to withstand rigorous use, this CE-certified auger drive delivers reliable performance in construction and utility projects.
Key Features
-
2" Hex Drive: Provides secure and reliable connection for heavy-duty applications.
-
Sealed Planetary Gear Reduction: Ensures continuous lubrication and low maintenance.
-
Reverse Rotation: Aids in quick backout from obstructions for smoother operation.
-
Hydraulic Relief Valve: Protects against damage from large, immovable objects
-
Multiple Mount Options: Wedge and pin grabber options available for versatile setups
-
Cradle Option: Adds stability during operation; available with or without cradle
-
No Hoses Required: Allows for flexible configurations to match specific excavator setups
-
Heavy-Duty Construction: Built for durability and longevity in demanding conditions
-
CE Certified: Meets international safety standards
-
Adaptable Use: Compatible with excavators from Kubota, John Deere, and more
Detailed Specifications
| Attribute |
Model 23537 |
| Part Numbers |
23537 / 113464, 23537 / 116003, 23537 / 123588, 23537 / 125488, 23537 / 19296, 23537 / 23745, 23537 / 24008, 23537 / 24749 |
| Manufacturer |
Paladin |
| Category |
Excavator Attachments |
| Subcategory |
Auger Drive |
| Industry |
Construction, Landscaping |
| Machine Compatibility |
Kubota KX080, Kubota KX057/U55, Kubota U15/U17/KX018/KX41, Yanmar VIO45/55/40/50, John Deere 50G/60G, Volvo EC55, John Deere 27G/35G |
| Attachment Size |
30″ Max Auger |
| Drive Type |
2″ HEX or 2.56″ Round |
| Cradle Type |
WITH Cradle (optional for select models) |
| Hoses Supplied |
No |
| Hydraulic Flow Range |
10–25 GPM (38–95 LPM) |
| Pressure Range |
Up to 3500 PSI (241 bar) |
| Output Speed |
40–104 RPM (depending on flow rate) |
| Output Torque |
1600–2630 ft-lbs (2169–3577 N·m) (depending on pressure) |
| Mount Compatibility |
Wedge Mount, Pin Grabber |
Performance Specifications (X1475D Motor)
