PH Outdoors Faunamaster Harrow | Model DH-140 | Length 140.6" | Working Width 55.1" | Horsepower 27 HP | For ATVs, UTVs & Small Tractors
PH Outdoors Faunamaster Harrow | Model DH-140 | Length 140.6" | Working Width 55.1" | Horsepower 27 HP | For ATVs, UTVs & Small Tractors
Regular price
$6,667.00
Regular price
Sale price
$6,667.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
PH Outdoors Faunamaster Harrow | Model DH-140 | Length 140.6" | Working Width 55.1" | Horsepower 27 HP | For ATVs, UTVs & Small Tractors
DESCRIPTION
The Faunamaster Harrow DH140 is the ultimate solution for those seeking a flexible and efficient harrow designed for professional use with ATVs, UTVs, and Category 1 tractors. Ideal for weed cleaning in existing seedbeds, newly planted forest cultures, creating new seedbeds, and preparing areas for biodiversity, cover crops, and wildflowers. Its robust build ensures reliability and longevity, capable of handling demanding tillage tasks with ease.
Key Features
- 55.1-Inch Working Width Ideal for cultivating, leveling, and cleaning seedbeds in wildlife areas, food plots, and restoration zones
- Tow-Behind or 3-Point Hitch Compatible Designed for use with ATVs, UTVs, or Category I tractors for flexible field deployment
- Heavy-Duty Construction (877 lbs) Built to withstand demanding tillage tasks with excellent ground contact and durability
- Multi-Stage Soil Prep System • 5 Harrow Tines for surface loosening • 5 Goose Feet for deeper soil penetration • 2 Axles with Disc Harrows for mixing and cutting • Rear Spring Rake for smoothing and finishing the seedbed
- Adjustable Working Depth: Up to 3.9 Inches (100 mm) Allows individual control of each soil tool for tailored land preparation
- Recommended Operating Speed: 6.2–8.7 mph (10–14 km/h) Optimized for efficient coverage without sacrificing soil quality
- Compact Dimensions: (140.6" L × 84" W × 47.2" H) Maneuverable in tight areas while offering full coverage
- Horsepower Requirement: 27 HP Suitable for small tractors and utility vehicles with moderate power output
Detailed Specifications
| Feature | Specification |
|---|---|
| Model | DH140 |
| Length | 140.6 in (3570 mm) |
| Width | 84.0 in (2135 mm) |
| Height | 47.2 in (1200 mm) |
| Working Width | 55.1 in (1400 mm) |
| Working Depth | 3.9 in (100 mm) |
| Operating Weight | 877 lbs (398 kg) |
| Recommended Speed | 6.2–8.7 mph (10–14 km/h) |
| Horsepower | 27 HP |
