Product Description
Rankin Level Best Tractor Grading Box | Model TD-84 | Working Width 84" inches | Dual Laser Capability | For Tractors
DESCRIPTION
The Level Best TD84 84" Tractor Laser Box Blade (Grading Box) with Double Cylinder is designed for precision and efficiency in grading tasks. Featuring advanced hydraulic controls and robust construction, this model excels in handling complex slopes and demanding job sites. The hydraulics have been upgraded to Danfoss valves, ensuring precise adjustments. The two 1-1/2" diameter mast poles provide stable support, while the flat-proof tires offer uninterrupted operation. Its powder-coated finish guarantees long-lasting protection, and the reversible cutting edge allows for versatile grading. Compatible with both Category I & II hitches, and equipped with two cylinders for precise height control, the TD84 ensures superior performance. It achieves finish grade elevation within 1/8 to 1/4 inches, depending on the laser system used. The model is built from durable steel plate and heavy-wall tubing, incorporating features like rugged casters, composite bushings, and flat-free tires to minimize maintenance and maximize durability. The easy-to-operate laser controls enable precise grading by automatically adjusting the grader box based on signals from a laser beacon, ensuring a consistently level finish. This model represents the pinnacle of technology and quality manufacturing, providing a reliable solution for all grading needs.
Key Features
- Budget-Friendly Fine Grading: Achieve fine grading at an affordable price with manual control for straightforward operation.
- Foam-Filled Tires: Provides excellent traction and stability, preventing flat tires and ensuring smooth movement across various terrains.
- Powder-Coated Finish: Offers superior protection against rust and corrosion, extending the lifespan of the grading box.
- Reversible Cutting Edge: Allows for efficient grading and leveling in both forward and reverse directions, enhancing versatility.
- Cat 1 & 2 Hitch Compatibility: Easily attaches to a wide range of tractors, making it convenient to use and switch between equipment.
- Dual Mast Poles: Features two 1-1/2" diameter mast poles for enhanced stability and performance.
- Rear Cutting Edge: Standard rear cutting edge for additional grading capabilities and improved efficiency.
Detailed Specifications
Attribute | Details |
---|---|
SKU | RAN-TD84 |
Weight | 1200 lbs |
Identifier | RAN-3478 |
Model | TD84 |
Capacity, Maximum | N/A |
Width - Overall | 84" (7 Feet; 213 cm) |
Width - Working | 84" (7 Feet; 213 cm) |
Horsepower Recommended | 60 - 125 HP (44.7 - 93.2 KW) |
Hitch Connection Type | Hoses w/flush-face couplers |
Color | Black |
Manufacturer | Rankin Equipment |
