Sicma (Phoenix) 3-Point Tractor Offset Rotary Tiller | T4 Series | Working Width 40", 48" & 59" inches | Horsepower 15-25 HP | For Tractors
Sicma (Phoenix) 3-Point Tractor Offset Rotary Tiller | T4 Series | Working Width 40", 48" & 59" inches | Horsepower 15-25 HP | For Tractors
Regular price
$2,702.50
Regular price
Sale price
$2,702.50
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Sicma (Phoenix) 3-Point Tractor Offset Rotary Tiller | T4 Series | Working Width 40", 48" & 59" inches | Horsepower 15-25 HP | For Tractors
DESCRIPTION
Phoenix T4 Series Rotary Tillers are well suited for hobby farmers, fruit and vegetable growers, landscapers, nurseries, vineyards, and gardeners. Applications include: soil conditioning weed control, fertilizer incorporation and seedbed preparation. Available in working widths of 40, 48 and 59 inches, all come standard with slip clutch PTO, 6 tines per flange, adjustable lower links, and heavy duty drag boards.
The Phoenix T4 family of rotary tillers are perfect for the independent week end gardener or horticultural enthusiast that likes to do things for themselves. No worries about these tillers, they are built for dependable trouble free performance year after year.
Key Features
- Working Width Options: Available in three sizes—40", 48", and 59"—to suit different tractor needs.
- Power Requirement: Designed for tractors with 15-25 HP, making it suitable for smaller to mid-size farming equipment.
- Tilling Efficiency: Equipped with 6 tines per flange, ensuring smooth tilling with reduced power consumption.
- Adjustable Offset Hitch Blocks: The lower hitch blocks can be adjusted or offset up to 4", providing flexibility for specific tilling tasks.
- Customizable Skids: Adjustable skids allow you to control the depth of tilling based on your requirements.
- Durable Build: Features heavy-duty castings and bearings, complemented by double lip seals for extended durability.
- Powder-Coated Finish: Comes in a choice of red or orange for a long-lasting and visually appealing exterior.
- Reinforced Drag Board: Includes a heavy-duty adjustable drag board, secured with a zinc-plated check chain for added stability.
- Premium PTO Shaft: Supplied with a Eurocardan Series 4 PTO shaft that includes a slip clutch for efficient power transfer and safety.
- Quick Hitch Compatibility: Ready to attach quickly to most tractor setups, saving time during equipment changes.
- Pre-Lubricated Gearbox: Shipped with gear oil already added to the central gearbox and rotor drive for convenience.
- Minor Assembly Required: Comes mostly assembled, requiring only a few finishing touches before use.
Detailed Specifications
| T4-40OS | T4-48 | T4-59 | |
|---|---|---|---|
| Working Width (Inches) | 40 | 48 | 59 |
| Working Depth (Inches) | 7 | 7 | 7 |
| Blades per Flange | 6 | 6 | 6 |
| Scroll Diameter (Inches) | 15.7 | 15.7 | 15.7 |
| Total Blades | 24 | 30 | 36 |
| Rotor Flange Thickness | 3/8 | 3/8 | 3/8 |
| Rotor Speed (RPM) | 250 | 250 | 250 |
| Drive Chain | #60 | #60 | #60 |
| Driveline Protection | Slip Clutch | Slip Clutch | Slip Clutch |
| Hitch | Cat I | Cat I | Cat I |
| PTO Shaft Series | 4 | 4 | 4 |
| PTO Power Required (HP) | 15-18 | 18-22 | 22-25 |
| Optimum PTO Speed (RPM) | 540 | 540 | 540 |
| Approximate Weight (LBS) | 308 | 335 | 360 |
Manual & Documents
General Warranty Info:
-
Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
