Products Description
Sitrex | Inline Hay Magnum Evolution 'V' Rakes | Model MKE10-60 To MKE20-60 | Working Width 21'3" To 38'3" | Horsepower 30 HP To 55 HP | For Tractors
DESCRIPTION
The Sitrex MKE Magnum Evolution "V" Rakes are robust, efficient, and easy-to-use raking solutions designed to meet the high demands of modern agricultural operations. Available in various configurations, from 10 to 18 finger wheels, these rakes are ideal for gathering hay quickly and thoroughly. With high-quality finger wheels, each equipped with 40 tines, the MKE rakes deliver reliable performance across diverse terrains.
Each model features an adjustable swath width through a ratchet or optional hydraulic system, making it easy to adapt to different field conditions directly from the tractor. The durable lattice framework and spring-loaded rake wheels ensure consistent ground pressure for effective raking. Optional kits such as the central kicker wheel and rear tandem wheel offer additional customization to enhance raking performance and durability.
Key Features
- Durable Build: High-grade structural tubing and components for long-lasting performance.
- Flexible Raking Widths: Adjustable swath width from 3' to 6', adaptable to various field sizes.
- Optional Hydraulic Kits: Allow for easy swath adjustment from the driver’s seat.
Detailed Specifications
| Specification | MKE10-60 | MKE12-60 |
|---|---|---|
| Model | MKE10-60 | MKE12-60 |
| Part # | 802.924 | 802.925 |
| Finger Wheels | 10 | 12 |
| Finger Wheel Diameter | 55” / 60” | 55” / 60” |
| Operating Weight (55") | 3,520 lbs (1,600 kg) | 3,700 lbs (1,680 kg) |
| Operating Weight (60") | 3,625 lbs (1,645 kg) | - |
| Tractor HP Required | 30 HP | 30 HP |
| Max Working Width | 21'3" (6.5 m) | 25'7" (7.6 m) |
| Max Windrow Width | 6' (1.8 m) | 6' (1.8 m) |
| Specification | MKE14-60 | MKE16-60 |
|---|---|---|
| Model | MKE14-60 | MKE16-60 |
| Part # | 802.926 | 802.927 |
| Finger Wheels | 14 | 16 |
| Finger Wheel Diameter | 55” / 60” | 55” / 60” |
| Operating Weight (55") | - | 5,290 lbs (2,400 kg) |
| Operating Weight (60") | - | 5,400 lbs (2,450 kg) |
| Tractor HP Required | 30 HP | 40 HP |
| Max Working Width | 28'5" (8.7 m) | 32'8" (9.96 m) |
| Max Windrow Width | 6' (1.8 m) | 6' (1.8 m) |
| Specification | MKE18-60 | MKE20-60 |
|---|---|---|
| Model | MKE18-60 | MKE20-60 |
| Part # | 802.928 | 802.929 |
| Finger Wheels | 18 | 20 |
| Finger Wheel Diameter | 55” / 60” | 55” / 60” |
| Operating Weight (55") | 6,610 lbs (3,000 kg) | - |
| Operating Weight (60") | 6,740 lbs (3,060 kg) | - |
| Tractor HP Required | 55 HP | 55 HP |
| Max Working Width | 34'5" (10.5 m) | 38'3" (11.65 m) |
| Max Windrow Width | 6' (1.8 m) | 6' (1.8 m) |
