Product Description
SmithCo | SX3 Side Dump Trailer | 42-34 Model | 34' Tub Length | 30.3 CY Capacity | 102" Width | For Heavy-Duty Bulk Hauling
Ripping It is Partnered with Western Truck to provide the best pricing and service for SmithCo.
DESCRIPTION
The SmithCo SX3 Side Dump Trailer is a top-tier bulk hauling solution, engineered for maximum efficiency, durability, and superior load handling. Built with reinforced AR400 steel, advanced hydraulic control, and Ridewell RW260 air suspension, this trailer offers exceptional strength and stability for demanding transport applications.
With a 34-foot round-bottom tub, the SX3 ensures precision material unloading, optimizing transport operations for construction sites, aggregate hauling, and industrial applications. The water-level capacity of 22.8 cubic yards and heaped volume of 30.3 cubic yards provide ample space for high-volume loads, making this trailer one of the most efficient side dump solutions available.
Designed with power requirements (kW/HP optimized) for seamless integration with hauling systems, this trailer features 5-inch hydraulic cylinders, a hydraulic control valve, and a robust dolly leg system. Equipped with ABS braking, a lift axle, and Duralite hubs, the SmithCo SX3 Side Dump Trailer ensures safe and smooth transport, meeting the highest industry standards.
Key Features
- Heavy-Duty AR400 Steel Construction: 1/4" AR400 steel side walls and floor for superior impact resistance and longevity.
- Optimized Power Requirements: Designed for efficient hydraulic performance (kW/HP optimized) for seamless dump cycles.
- Large Capacity for Bulk Material Transport: 22.8 cubic yards water level, 30.3 cubic yards heaped for maximum payload efficiency.
- Ridewell RW260 Air Suspension for Smooth Handling: Enhanced ride stability ensures minimal shifting of material loads during transit.
- Advanced Hydraulic System Control Valve: 5-inch hydraulic cylinders for precise control over material dumping. Air/hydraulic control valve for responsive system operation.
- Heavy-Duty Axle Configuration for Load Stability: Tri-axle setup, lift axle on third axle, ABS braking system for enhanced safety.
- Premium Wheels Tires for Hauling Efficiency: Super single aluminum wheels (6 units) with 385/65R22.5 J Ply tires for maximum traction.
- DOT-Approved Lighting Safety Features: Sealed LED tail lights, ID lights, and air gauge monitoring for secure hauling operations.
- Integrated Tarp System: Aero mesh tarp system for efficient load containment and transport safety.
Detailed Specifications
| Specification | Details |
|---|---|
| Model | SmithCo SX3-42-34 Side Dump Trailer |
| Overall Width | 102" |
| Frame Length | 42 feet |
| Tub Length | 34 feet |
| Tub Style | SX-Round Bottom |
| Side Floor Material | 1/4" AR400 Steel |
| Volume (Water Level) | 22.8 Cubic Yards |
| Volume (Heaped) | 30.3 Cubic Yards |
| Chassis Hydraulics | Binkley Dolly Legs, 5" Hydraulic Cylinders, Air/Hydraulic Control Valve |
| Suspension | Ridewell RW260 |
| Axle Spacing | 49" |
| Lift Axle | 3rd Axle |
| Axles | (1) 25K ABS, (2) 25K Non-ABS |
| Axle Track | 77.5" Standard |
| Hubs | Duralite Standard |
| Brakes | 16 ½" x 7" Drum Brakes |
| Drums | Cast Steel |
| Wheel Style | Hub-Piloted U/M |
| Wheel Type | AL SS 12.25x22.5, 6 Super Single Aluminum |
| Tires | 385/65R22.5 "J" Ply Super Single (6 Units) |
| Fenders | All Plastic |
| Tarp System | Aero Mesh Non-Sealed |
| Tarp Lockout | Yes |
| Push Block | W Style Standard |
| Air Gauge | Large Liquid-Filled on Driver's Side |
| Grease Bank | Hydraulic Cylinders (Front Rear) |
| Tail Lights | 3 Red |
| ID Lights | 5 at Rear |
