Product Description
Spectra Geospatial LL100N Laser Level Package
DESCRIPTION
Spectra Geospatial LL100N Laser Level Package Includes laser level, HR320 laser receiver, clamp, tripod, 15´ grade rod graduated in inches, and case.
Setting a new standard for reliability and affordability, the fully automatic, self-leveling LL100N can handle a variety of general construction applications. By sending a 360° plane of laser light over an entire work area, the LL100N allows one person to take self-leveled elevation measurements using the included HR320 laser receiver. The HR320 provides two on-grade sensitivities and features grade displays on the front and back. In order to guard against erroneous readings, the LL100N’s Height of Instrument Alert stops laser rotation if the elevation changes. Easy, one-button operation requires minimal training, and an energy-efficient design ensures long battery life. The water-resistant laser level withstands drops up to 3 feet (1 meter) onto concrete and tripod tip-overs up to 5 feet (1.5 meters).
Key Features
- Complete Package: Includes laser level, HR320 receiver, clamp, tripod, and 15' grade rod.
- Automatic Self-Leveling: Quickly and accurately levels with minimal effort.
- Precision Accuracy: ±1/8 inch at 100 ft (±3 mm at 30 m).
- Long Working Range: Up to 1,150 ft (350 m) diameter with the HR320 receiver.
- Height of Instrument Alert: Stops rotation if disturbed, ensuring accurate readings.
- Durable Design: Drop-tested up to 3 ft and IP54 water-resistant.
- Easy One-Button Operation: No need for extensive training to operate.
- Efficient Battery Life: 80 hours of operation with 2 D alkaline batteries.
- Two-Year Warranty: Ensures peace of mind and dependable performance.
Detailed Sepcifications
LL100N Laser Specifications
| Feature | Details |
|---|---|
| Laser Source | 650 nm visible, Class 2 |
| Accuracy | ±1/8 inch at 100 ft (±3 mm at 30 m) |
| Rotation Speed | 600 rpm |
| Operating Range | Up to 1,150 ft (350 m) diameter |
| Self-Leveling Range | ±5° |
| Battery Life | 80 hours |
| Water Resistance | IP54 Rated |
| Dimensions | 8.5˝L x 6.7˝W x 6.0˝H |
| Weight | 3.3 lbs |
HR320 Receiver Specifications
| Feature | Details |
|---|---|
| On-Grade Sensitivities | Fine: 1/16 in (2 mm); Standard: 1/4 in (6 mm) |
| LCD Channels | 5 |
| Battery Life | 70 hours |
| Waterproof Rating | IP67 Rated |
| Weight | 12 oz |
In Package
- LL100N Laser Level
- HR320 Laser Receiver
- Clamp
- Tripod
- 15' Grade Rod (Inches)
- Carrying Case
