TAG Dirt Bucket | Quick Coupler | Heavy Duty & High Capacity | 1.75" T-Pin | 4.25–13.75 ft³ Capacity | Bucket Weight 300–530 lbs | 6–8 Ton | For Excavator & Backhoe Loaders
TAG Dirt Bucket | Quick Coupler | Heavy Duty & High Capacity | 1.75" T-Pin | 4.25–13.75 ft³ Capacity | Bucket Weight 300–530 lbs | 6–8 Ton | For Excavator & Backhoe Loaders
Regular price
$980.00
Regular price
Sale price
$980.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
TAG Dirt Bucket | Quick Coupler | Heavy Duty & High Capacity | 1.75" T-Pin | 4.25–13.75 ft³ Capacity | Bucket Weight 300–530 lbs | 6–8 Ton | For Excavator & Backhoe Loaders
DESCRIPTION
The TAG Quick Coupler Dirt Bucket Series is engineered for excavators & Backhoe Loaders in the 12,000–16,000 lbs (6–8 ton) class. Built to handle demanding excavation and grading conditions, these buckets feature the proven Wain-Roy style hook and 1.75" vertical T-pin (QC30) quick coupler design for secure attachment and easy bucket swaps.
Constructed for durability and precision, TAG buckets are available in Heavy Duty and Heavy Duty High Capacity configurations, with widths from 12" to 36". They are designed to dig through a wide range of materials, including mud, shale, compacted dirt, and sand, and typically include digging teeth for aggressive soil penetration. Toothless variants are available by special request.
Key Features
- Machine Compatibility: Fits 6–8 ton machines (12,000–16,000 lbs).
- Coupler Style: Quick Coupler – Wain-Roy hook with 1.75" T-Pin (QC30).
- Bucket Style Options: Choose from Heavy Duty (standard durability), High Capacity (max payload volume), or WRQ (alternate depth and opening geometry) based on project needs and machine specs.
- Tooth Option: Standard with teeth; toothless versions available upon request.
- Material Use: Performs well in dirt, mud, compacted soil, shale, and sand.
- Construction: Reinforced edges, robust welds, and precision fit-up for reliability.
-
Availability: Common items may be stocked; call to verify lead times.
Detailed Specifications
HEAVY DUTY
| Order # | Width | Capacity (ft³) | Weight (lbs) | Depth | Opening |
|---|---|---|---|---|---|
| 1230Q2 | 12" | 4.25 | 300 | 27.95" | 24.12" |
| 1630Q2 | 16" | 5.40 | 325 | 27.95" | 24.12" |
| 1830Q2 | 18" | 6.20 | 360 | 27.95" | 24.12" |
| 2030Q2 | 20" | 6.85 | 390 | 27.95" | 24.12" |
| 2430Q2 | 24" | 8.50 | 430 | 27.95" | 24.12" |
| 3030Q2 | 30" | 11.00 | 480 | 27.95" | 24.12" |
| 3630Q2 | 36" | 12.50 | 530 | 27.95" | 24.12" |
Heavy Duty High Capacity Series
| Order # | Width | Capacity (ft³) | Weight (lbs) |
|---|---|---|---|
| 1232Q2 | 12" | 4.35 | 300 |
| 1632Q2 | 16" | 5.45 | 325 |
| 1832Q2 | 18" | 6.98 | 360 |
| 2032Q2 | 20" | 8.00 | 390 |
| 2432Q2 | 24" | 9.25 | 430 |
| 3032Q2 | 30" | 11.50 | 480 |
| 3632Q2 | 36" | 13.75 | 530 |
Wain-Roy Quick Coupler (WRQ) Style
| Order # | Width | Capacity (ft³) | Weight (lbs) | Depth | Opening |
|---|---|---|---|---|---|
| 1230WRQ2 | 12" | 4.25 | 300 | 28" | 22" |
| 1630WRQ2 | 16" | 5.40 | 325 | 28" | 22" |
| 1830WRQ2 | 18" | 6.20 | 360 | 28" | 22" |
| 2030WRQ2 | 20" | 6.85 | 390 | 28" | 22" |
| 2430WRQ2 | 24" | 8.50 | 430 | 28" | 22" |
| 3030WRQ2 | 30" | 11.00 | 480 | 28" | 22" |
| 3630WRQ2 | 36" | 12.50 | 530 | 28" | 22" |
