Tanco Bale Handler | Model D80 & D85 | 5' 2" Width | 20-60 GPM | 40-60 HP | For Skid Steer, Tractor & Loaders

Tanco Bale Handler | Model D80 & D85 | 5' 2" Width | 20-60 GPM | 40-60 HP | For Skid Steer, Tractor & Loaders

$8,770.00
$8,770.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Width: 5' 2" (1.58 m) for efficient bale handling.
  • Hydraulic Flow: 20-60 GPM for smooth operation.
  • Weight: 860 lbs (390 kg) for robust performance.
  • Max Bale Capacity: 3,307 lbs (1,500 kg) for large bales.
  • Compatibility: For Skid Steer, Tractor, Loaders.
View full details

Product Description

Tanco Bale Handler | Model D80 & D85 | 5' 2" Width | 20-60 Gpm | 40-60 Hp | For Skid Steer, Tractor & Loaders

DESCRIPTION

The Tanco D80 Square Bale Handler and D85 Round Bale Handler offer the ultimate solution for handling both square and round bales with unparalleled safety and precision. Designed for heavy-duty use, these handlers are built to endure tough agricultural environments while providing secure, damage-free bale handling. The D80 is ideal for square bales, while the D85 is engineered specifically for round bales, offering maximum versatility in one compact solution. Equipped with double-acting hydraulic rams and an arm-locking system, both models ensure a firm grip, preventing any potential damage to the wrap. Whether you're using a Skid Steer, Tractor, or Loader, these handlers are compatible with various machinery to ensure seamless operation. Get more done, faster, with the reliable Tanco Bale Handlers.

Key Features

  • D80 & D85 Compatibility: Handles both square and round bales with ease.
  • Heavy-duty construction: Built for tough farm conditions and long-lasting performance.
  • Double-acting hydraulic rams: Secure grip prevents damage to bale wrap.
  • Max Bale Capacity: Handles up to 3,307 lbs (1,500 kg) bales.
  • Hydraulic arm-locking system: Easily stack bales with no hassle.
  • Efficient oil consumption: 20-60 GPM hydraulic flow for smooth operation.
  • D80 for Square Bales: Perfect for large square bales, up to 6.5 ft (2.0 m).
  • D85 for Round Bales: Ideal for handling round silage bales up to 6.5 ft (2.0 m).
  • Compact transport dimensions: 4' 9" length, 1' 9" width for easy storage.
  • Max Bale Diameter: Accommodates bales up to 6.5 ft (2.0 m) in diameter.
  • Operator visibility: Provides excellent sightlines for safe, accurate handling.
  • Lightweight yet robust: D80 weighs 860 lbs (390 kg), D85 weighs 441 lbs (200 kg).
  • Versatile compatibility: Compatible with Skid Steer, Tractor, and Loaders.
  • Hydraulic safety valve: Protects during hydraulic failure for added reliability.
  • Ideal for silage and hay: Versatile for various agricultural applications.

Detailed Specifications

Specification D80 Bale Handler D85 Bale Handler
Model D80 D85
Width 5' 2" (1.58 m) 5' 2" (1.58 m)
Hydraulic Flow 20-60 GPM 20-60 GPM
Horsepower 40-60 HP 40-60 HP
Weight 860 lbs (390 kg) 441 lbs (200 kg)
Bale Capacity Up to 3,307 lbs (1,500 kg) Up to 3,086 lbs (1,400 kg)
Max Bale Diameter 6.5 ft (2.0 m) 6.5 ft (2.0 m)
Opening Width 6.9 ft (2.1 m) 6.9 ft (2.1 m)
Closing Width 2 ft (0.6 m) 2 ft (0.6 m)
Min Oil Consumption 5.3 GPM (20 l/min) 5.3 GPM (20 l/min)
Min Oil Pressure 2,200 PSI (150 bar) 2,200 PSI (150 bar)
Height (Transport Mode) 2 ft (0.62 m) 2 ft (0.66 m)
Transport Length 4' 9" (1.50 m) 4' 6" (1.40 m)
Transport Width 1' 9" (0.57 m) 4' 6" (1.40 m)
Compatibility Skid Steer, Tractor, Loaders Skid Steer, Tractor, Loaders



Manuals & Documents

Product Brochure

Product Manual - Bale Handler D80

Product Manual - Bale Handler D85
