Product Description
Tanco Round Bale Wrapper | Model D66-E100-SA Autowrap | Width 8'1" | 25-45 GPM | 40-60 HP | For Skid Steer, Tractor & Loaders
DESCRIPTION
The Tanco Round Bale Wrapper Model D66-E100-SA Autowrap is engineered for small to medium-sized operations, delivering reliability and efficiency with every bale. This semi-automatic wrapper is designed with a "One-Touch" system for ultimate convenience just set the wrap cycle and let the machine handle the rest. Its robust hydraulic Cut & Start feature cuts plastic automatically after the bale is ejected, enhancing operational speed. The Swivel Wheel allows for flexible use, carrying up to 2,205 lbs of bale weight with ease. With a focus on comfort and durability, the E100-SA offers an impressive up to 35 bales per hour wrapping capacity. Whether you’re on a Skid Steer, Tractor, or Loader, this machine ensures smooth, efficient operations in any environment.
Key Features
- Automatic Cut & Start: Automatically cuts and starts plastic wrapping after each bale is ejected, improving output times significantly.
- Swivel Wheel Design: Foldable wheel for easy transport and secure handling of bales up to 1,000 kg (2,205 lbs).
- RDS Controller: Tracks the number of bale wraps and revolutions for precision and operational control.
- Hydraulic Power: Operates with 25-60 GPM for smooth and powerful bale wrapping.
- 'One-Touch' System: Allows the operator to focus on other tasks while the wrapping cycle completes automatically.
- Dual Stretch Options: Includes a Tanco Dual Stretch Aluminium Dispenser for 55% and 70% stretch settings to fit your needs.
- Compact Size: Transport length of 14' 3" and width of 8'1" for easy maneuverability.
- Heavy Duty Construction: Built to last with high-quality components for peace of mind operation.
- High-Speed Wrapping: Capable of wrapping up to 35 bales per hour for maximum productivity.
- User-Friendly Interface: Simple cable-operated controls for precise handling.
- Versatile Bale Size: Handles bales from 3'3" to 5' in diameter, offering flexibility for different bale types.
- Load Sensing Capability: Ensures that the machine adjusts to different load conditions for optimal performance.
- Pre-Stretcher Options: Includes a 750mm Pre-Stretcher for consistent film application.
- Off-Load Lock: Keeps bales stable during offloading, ensuring precise placement.
- Ergonomic Operation: Designed to reduce operator fatigue during long working hours.
- Optional End-Tip Kit: Places bales on their end, ensuring maximum plastic coverage and minimizing bale movement during storage.
Detailed Specifications
| Feature | E100-SA |
|---|---|
| Transport Length | 14' 3" (4.36 m) |
| Transport Width | 8' 1" (2.49 m) |
| Transport Height | 7' 7" (2.37 m) |
| Weight | 2,116 lbs (960 kg) |
| Wheel Dimensions | 10.0 / 80-12 |
| Max. Bale Weight | 2,205 lbs (1,000 kg) |
| Bale Dimensions (Width x Diameter) | 4' x 3.3' - 5' (1.25 x 1.00 - 1.50 m) |
| Min. Oil Consumption | 6.6 GPM (25 l/min) |
| Max. Oil Consumption | 16 GPM (60 l/min) |
| Min. Oil Pressure | 2,200 PSI (150 bar) |
| Free Flow Return | Yes |
| Load Sensing Option | No |
| Cable Controlled Valve Bank | Yes |
| Joystick Controls | No |
| Programmable Computer Controls | No |
| Automatic Hydraulic Cut & Start | Yes |
| Pre-Stretcher (750mm) | Yes |
