The Taylor TD2000 Standby Diesel Generator is a high-capacity power solution, delivering a commanding 2000kW output. Powered by the robust Mitsubishi S16R-Y2PTAW2-1 V-16 Turbocharged engine, it is designed for reliability and efficiency in heavy-duty and emergency applications. Certified to UL2200 standards, this generator is tailored to meet diverse requirements with multiple power output configurations.
Taylor Power System Standby-Diesel Generators | Model TD-2000 | Horsepower 2856 HP | Power Output 2000kW (2500kVA) | Open & Enclosed Unit
Taylor Power System Standby-Diesel Generators | Model TD-2000 | Horsepower 2856 HP | Power Output 2000kW (2500kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-Diesel Generators | Model TD-2000 | Horsepower 2856 HP | Power Output 2000kW (2500kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
- Engine: Mitsubishi S16R-Y2PTAW2-1, 65.37L Turbocharged V-16, EPA Tier 2 Certified
- Horsepower: An impressive 2856 HP at 1800 RPM for superior performance
- Output Power Options: Flexible voltage configurations up to 2500kVA
- Durable Build: Heavy-duty steel base with vibration isolators
- Fuel Efficiency: Optimized for low-sulfur diesel with Mitsubishi PS8 fuel injection system
- Cooling System: High ambient unit-mounted radiator with significant coolant capacity
- Ease of Maintenance: Oil drain valve with extension, battery rack, and cables
- Emission Compliance: EPA Certified for stationary emergency use
- Sound Level: Operates at 113 dBA at 3.2 ft (1M)
- Safety Features: Advanced over-voltage, under-frequency, and over-excitation protection mechanisms
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Details |
|---|---|
| Engine Make | Mitsubishi S16R-Y2PTAW2-1 |
| Engine Type | 65.37L Turbocharged V-16, Tier 2 |
| Fuel Type | Diesel |
| Horsepower | 2856 HP @ 1800 RPM |
| Output Ratings | 2000kW/2500kVA |
| Cooling Capacity | 44.9 gal (170.0 L) |
| Compression Ratio | 14.0:1 |
| Fuel Consumption | 160.1 gal/hr (606 L/hr) at 100% load |
| Alternator Type | Marathon PMG with hybrid analog/digital voltage regulator |
| Voltage Regulation | ±0.25% |
| Temperature Rise | 125°C Standby |
| Heat Rejection | To coolant: 780 kW (44,374 BTUM) |
| Sound Level | 113 dBA @ 3.2 ft |
 |
Open Unit | Overall Size: 204”L x 88”W x 105”H Approximate Weight: 26,800 lbs. |
 |
Standard Enclosed Unit | N/A |
