Timpte | Rough Neck Bottom Dump Trailer | 2024 Model | 39' Length | Weight 5.02 Tons | 96" Width | For Bulk Material Hauling & Industrial Use
Timpte | Rough Neck Bottom Dump Trailer | 2024 Model | 39' Length | Weight 5.02 Tons | 96" Width | For Bulk Material Hauling & Industrial Use
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Timpte | Rough Neck Bottom Dump Trailer | 2024 Model | 39' Length | Weight 5.02 Tons | 96" Width | For Bulk Material Hauling & Industrial Use
Ripping It is Partnered with Western Truck to provide the best pricing and service for Timpte.
DESCRIPTION
The 2024 Timpte Rough Neck Bottom Dump Trailer is a high-performance bulk hauling solution, built for maximum efficiency, durability, and superior load management. With its reinforced steel sub-frame, advanced air-ride suspension, and high-clearance hopper, this trailer ensures optimal transport performance for demanding applications such as frac sand, aggregate, and bulk material transport.
Featuring a 39-foot length and a single Ag hopper with a 25-inch clearance, the Timpte Rough Neck Trailer is designed for smooth and efficient material discharge. The low-torque roller trap with EZ Flow hydraulic opener allows for precise control over unloading, while the upper and lower knock rails provide additional structural integrity.
Built with power requirements (kW/HP optimized) for seamless integration with hauling systems, this trailer includes a Thunder 7000 electric tarp system, stainless steel corner posts, and sloped rear panels, ensuring long-term reliability and transport security. Equipped with DOT-compliant lighting, high-strength aluminum wheels, and industry-leading suspension, the Timpte Rough Neck Bottom Dump Trailer delivers exceptional hauling performance.
Key Features
- High-Capacity Ag Hopper for Bulk Material Transport: Single hopper with a 25-inch clearance ensures smooth material flow.
- Optimized Power Requirements: Designed for efficient hydraulic operation (kW/HP optimized) ensuring seamless unloading cycles.
- Advanced Suspension & Stability Enhancements: Hendrickson air ride suspension for superior ride comfort and load stability.
- Heavy-Duty Steel Frame & Reinforced Protection: Steel upper coupler and enclosed upper coupler system for extra durability.
- Premium Wheels & Tires for Hauling Efficiency: Four inside steel wheels, four outside aluminum wheels (24.5") for maximum traction and stability. High-performance 11R24.5 TR528 tires for long-haul durability.
- Precision Load Management with Hydraulic Trap System: Low-torque roller trap with EZ Flow hydraulic opener ensures quick and controlled material discharge.
- DOT-Approved Lighting & Safety Features: Side markers, rear header lights, stop/turn/tail lights across the lower rail for enhanced visibility.
- Integrated Tarp System for Load Protection: Thunder 7000 electric tarp system for secure containment during transport.
Detailed Specifications
| Category | Details |
|---|---|
| Model Year | 2024 |
| Make & Model | Timpte Rough Neck |
| Condition | New |
| Dimensions (LxWxH) | 39' x 72" x 96" |
| Weight | 10,048 lbs |
| Frame | Steel Sub Frame |
| Hopper Type | Single Ag Hopper (25" High Clearance) |
| Hopper Door | Low Torque Roller Trap, EZ Flow Hydraulic Opener |
| Door Size | 24"W x 27"L |
| Knock Rails | Upper & Lower Knock Rails on All Sides |
| Wheels | (4) Inside Steel, (4) Outside Aluminum (24.5") |
| Tires | 11R24.5 TR528 |
| Suspension | Hendrickson Air Ride |
| Tarp System | Thunder “7000” Electric Tarp |
| Lighting | 1 Row of 3 Bullet Side Markers, 5 Bullet Rear Lights, 6 Across Lower Rail |
| Rear Panels | Sloped |
| Exterior Panels | White Nose, Side, & Rear Panels |
| Corner Posts | Stainless Steel |
| Ladders & Platforms | Removed |
