Turbo Turf Hydroseeder | Model HY-500-HE & HY-500-HE | Width 69” | Capacity 500 Gallon | Engine Horsepower 13 HP & 8 HP | For Landscapers, Golf Courses & Erosion Control

$16,495.00

Sale Sold out

Product variants

Quantity

305-391-2008

Info@rippingitoutdoors.com

Hybrid Design: Integrates jet and mechanical agitation for fast, thorough mixing of hydroseeding materials, allowing full bales to be loaded without breaking them up.
Dual Engine Power: Features a 13 H.P. Honda engine driving a high-pressure jet spray pump and an 8 H.P. Honda engine powering a paddle for mechanical mixing.
Large Coverage Capacity: Seeds up to 6,600 sq. ft. per load with materials like wood, cellulose, or pelletized mulch & width 69''
Efficient Spray System: Equipped with a tower gun and a 100-foot hose, achieving up to 100 feet of spray distance in about 7 minutes.
Durable Construction: 500-gallon molded poly tank on a skid frame, built with rust-resistant materials to prevent buildup, ensuring longevity.

View full details

Product Description

Turbo Turf Hydroseeder | Model HY-500-HE & HY-500-HE | Width 69” | Capacity 500 Gallon | Engine Horsepower 13 HP & 8 HP | For Landscapers, Golf Courses & Erosion Control

Lead Times:

HE & Harve Series - 24 - 26 Week
The T models 400 and up - 10 - 12 Week
Small 50-150 to Jet agitated models - 2 - 4 Week
300 is - 4-6 Week

DESCRIPTION

The Turbo Turf HY-500-HE Hydroseeder is a hybrid hydroseeding system that combines the best features of both jet and mechanical hydroseeders. Designed for landscapers, erosion control professionals, and golf course maintenance, it features dual Honda engines—a 13 HP electric start engine for the high-pressure centrifugal pump and an 8 HP electric start engine for paddle agitation. This innovative two-engine design ensures fast mixing, powerful spray capability, and superior trimming control.

The poly tank construction eliminates rust concerns, allowing users to mix fertilizers without corrosion worries. The rounded tank corners prevent material buildup, making cleanup quick and easy. The Jet Bale Buster system allows for full bale loading without breaking them up, ensuring efficient mixing.

Key Features

Hybrid System: Combines jet and mechanical agitation for fast mixing and powerful spraying.
Dual Engine Design: 13 HP Honda engine for the centrifugal pump, 8 HP Honda engine for paddle agitation.
Pump: 3” x 3” centrifugal pump delivers 333 GPM and 72 PSI for effective spraying.
Tank Capacity: 500-gallon poly tank, rust-resistant and durable.
Jet Bale Buster: Breaks down large mulch clumps for efficient mixing.
Hose: 100 feet of 1 1/2” I.D. hose with three nozzles (hydroseeding, straight distance, and trim).
Spray Distance: Up to 100 feet from the tower gun, 55 feet with the straight nozzle.
Coverage: Seeds up to 6,600 square feet per load.
Quick Spray Time: 7 minutes from the tower, 10 minutes with the hose.
Mulch Compatibility: Works with paper mulch, 50/50 blends, and some 70/30 blends.
Heavy-Duty Skid Frame: Structural steel supports ensure durability and stability.
20-Year Tank Warranty: Pro-rated warranty for long-term reliability.

Detailed Specifications

Feature	HY-500-HE (Skid Type)	HY-500-HE-P (Trailered Unit)
Tank Capacity	500 Gallons	500 Gallons
Engine	13 HP Honda (electric start) + 8 HP Honda (electric start)	13 HP Honda (electric start) + 8 HP Honda (electric start)
Pump	3” x 3” centrifugal, 333 GPM, 72 PSI	3” x 3” centrifugal, 333 GPM, 72 PSI
Agitation System	Paddle agitation + Jet agitation	Paddle agitation + Jet agitation
Coverage per Load	6,600 sq. ft.	6,600 sq. ft.
Spray Time per Load	7 minutes (tower), 10 minutes (hose)	7 minutes (tower), 10 minutes (hose)
Mixing Time	5-10 minutes	5-10 minutes
Tank Design	Poly tank with rounded corners	Poly tank with rounded corners
Hose Length	100 feet of 1 1/2” I.D. hose	100 feet of 1 1/2” I.D. hose
Mulch Compatibility	Paper mulch, 50/50 blends, some 70/30 blends	Paper mulch, 50/50 blends, some 70/30 blends
Empty Weight	1,510 lbs	1,550 lbs
Loaded Weight	5,100 lbs	5,150 lbs
Overall Dimensions	69” W x 120” L x 90” H	69” W x 120” L x 90” H
Transport Type	Skid-mounted	Trailer-mounted with hitch
Ideal Use	Landscapers, golf courses, erosion control	Landscapers, golf courses, erosion control

Material Cost Breakdown

50-Gallon Hydroseeder

Mulch: 0.5 bales at $11.95 per bale = $5.98
Seed: 5 pounds at $2.05 per pound = $10.25
Fertilizer: 1.33 pounds at $2.19 per pound = $2.91
Tackifier: 0.67 oz at $1.00 per oz = $0.67
Total Material Cost for the Load: $19.81
Coverage: Approximately 667 sq. ft.
Cost per Sq. Ft.: 2.97 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $297.00; Profit = $703.00.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $297.00; Profit = $1,203.00.

100-Gallon Hydroseeder

Mulch: 1 bale at $11.95 per bale = $11.95
Seed: 10 pounds at $2.05 per pound = $20.50
Fertilizer: 2.67 pounds at $2.19 per pound = $5.85
Tackifier: 1.33 oz at $1.00 per oz = $1.33
Total Material Cost for the Load: $39.63
Coverage: Approximately 1,333 sq. ft.
Cost per Sq. Ft.: 2.97 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $297.00; Profit = $703.00.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $297.00; Profit = $1,203.00.

150-Gallon Hydroseeder

Mulch: 1.5 bales at $11.95 per bale = $17.93
Seed: 15 pounds at $2.05 per pound = $30.75
Fertilizer: 4 pounds at $2.19 per pound = $8.76
Tackifier: 2 oz at $1.00 per oz = $2.00
Total Material Cost for the Load: $59.44
Coverage: Approximately 2,000 sq. ft.
Cost per Sq. Ft.: 2.97 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $297.00; Profit = $703.00.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $297.00; Profit = $1,203.00.
500-Gallon Hydroseeder
Mulch: 5 bales at $11.95 per bale = $59.75
Seed: 50 pounds at $2.05 per pound = $102.50
Fertilizer: 13 pounds at $2.19 per pound = $28.47
Tackifier: 6.67 oz at $1.00 per oz = $6.67
Total Material Cost for the Load: $197.39
Coverage: Assuming linear scaling, a 500-gallon unit covers approximately 6,667 sq. ft.
Cost per Sq. Ft.: 2.96 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $296.70; Profit = $703.30.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $296.70; Profit = $1,203.30.

750-Gallon Hydroseeder

Mulch: 7.5 bales at $11.95 per bale = $89.63
Seed: 75 pounds at $2.05 per pound = $153.75
Fertilizer: 20 pounds at $2.19 per pound = $43.80
Tackifier: 10 oz at $1.00 per oz = $10.00
Total Material Cost for the Load: $297.18
Coverage: Approximately 10,000 sq. ft.
Cost per Sq. Ft.: 2.97 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $297.18; Profit = $702.82.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $297.18; Profit = $1,202.82.

1000-Gallon Hydroseeder

Mulch: 10 bales at $11.95 per bale = $119.50
Seed: 100 pounds at $2.05 per pound = $205.00
Fertilizer: 26.67 pounds at $2.19 per pound = $58.43
Tackifier: 13.33 oz at $1.00 per oz = $13.33
Total Material Cost for the Load: $396.26
Coverage: Approximately 13,333 sq. ft.
Cost per Sq. Ft.: 2.97 cents per sq. ft.
10,000 Sq. Ft. Residential Job:
At 10 cents per sq. ft.: Charge = $1,000.00; Material Cost = $297.00 (rounded); Profit = $703.00.
At 15 cents per sq. ft.: Charge = $1,500.00; Material Cost = $297.00; Profit = $1,203.00.

General Supply Information for a One Acre Job

Paper Mulch Covering:

1000 lbs per acre: 25 40# paper bales, $21.95 per bale, totaling $548.75
1200 lbs per acre: 30 40# paper bales, $21.95 per bale, totaling $658.50
1500 lbs per acre (steeper slope): 38 40# paper bales, $21.95 per bale, totaling $834.10

Fertilizer:

2-4 bags per acre
For residential use: 4 bags
For non-residential use: 2 bags
Cost per bag: $59.95

Trafficker:

For flat to slight slope: Turbo Tack, covers one acre, $49.95

Tracker:

For slopes: Witches Brew, covers one acre, $69.96

Wood Blend Mulch or 100% Wood:

Typical coverage: 2000 lbs per acre
For steep slopes: Up to 3500 lbs per acre

Seed Costs:

Reach out to us or check your local seed supplier

How Quickly Can I Do a 10,000sf Hydroseeding Job?

50-Gallon Hydroseeder:

Coverage per Load: Approximately 667 sq. ft.
Number of Loads Needed: About 15 loads (10,000 / 667).
Estimated Time per Load: Assuming approximately 20 minutes per load (including refilling and application).
Total Time: 15 loads x 20 minutes = 300 minutes or 5 hours.

100-Gallon Hydroseeder:

Coverage per Load: Approximately 1,333 sq. ft.
Number of Loads Needed: About 8 loads (10,000 / 1,333).
Estimated Time per Load: Assuming approximately 25 minutes per load.
Total Time: 8 loads x 25 minutes = 200 minutes or about 3 hours and 20 minutes.

150-Gallon Hydroseeder:

Coverage per Load: Approximately 2,000 sq. ft.
Number of Loads Needed: 5 loads (10,000 / 2,000).
Estimated Time per Load: Assuming approximately 30 minutes per load.
Total Time: 5 loads x 30 minutes = 150 minutes or 2.5 hours.

300-Gallon Hydroseeder:

Coverage per Load: Approximately 4,000 sq. ft.
Number of Loads Needed: 2.5 loads (10,000 / 4,000).
Estimated Time per Load: Assuming approximately 40 minutes per load.
Total Time: 2.5 loads x 40 minutes = 100 minutes or about 1 hour and 40 minutes.

500-Gallon Hydroseeder:

Coverage per Load: Approximately 6,667 sq. ft.
Number of Loads Needed: 1.5 loads (10,000 / 6,667).
Estimated Time per Load: Assuming approximately 45 minutes per load.
Total Time: 1.5 loads x 45 minutes = 68 minutes or about 1 hour and 8 minutes.

750-Gallon Hydroseeder:

Coverage per Load: Approximately 10,000 sq. ft.
Number of Loads Needed: 1 load.
Estimated Time per Load: Assuming approximately 50 minutes per load.
Total Time: 50 minutes.

1000-Gallon Hydroseeder:

Coverage per Load: Approximately 13,333 sq. ft.
Number of Loads Needed: 1 load.
Estimated Time per Load: Assuming approximately 50 minutes per load.
Total Time: 50 minutes.
