Product Description
Virnig Rail Pallet Fork Walk-Through | Models PFWT4240 To PFWT4862 | Tine Length 42" To 72" | Widths 50.5" / 45.5" | Hydraulic Flow 15 To 25 GPM | For Skid Steer
DESCRIPTION
The Virnig Walk-Through Rail Pallet Fork is engineered for operators who want faster, safer, and more efficient entry into the skid steer cab without sacrificing lifting strength. Its open walk-through frame eliminates the traditional step-over bar, allowing quick cab access even when wearing heavy work boots or carrying tools.
Built with forged ITA Class II adjustable tines, a high-visibility brickguard, and a rugged beveled rail, this skid steer pallet fork delivers exceptional load stability and versatility on construction sites, farms, landscaping jobs, or material-handling operations. Whether you need to lift lumber, pallets, feed, block, pipe, or building materials, Virnig’s premium rail design ensures superior durability and operator comfort.
Because pallet forks require no hydraulic flow, they are compatible with virtually all skid steers typically 45+ HP and up, including standard and high-capacity models.
Key Features
- Walk-Through Frame Design for effortless cab entry and exit
- ITA Class II Forged Tines for maximum lifting strength and durability
- 1/4" High-Visibility Brickguard improves sightlines to the load
- Hydraulic Flow Range Compatible with machines delivering 15–25 GPM.
- 3/4" Beveled Rail ensures smooth tine adjustment under heavy loads
- Brickguard Flush With Tines to help stabilize tall or uneven materials
- Centered Bracing on Quick-Tach for stable, easy hook-up to the machine
- Bolt-On Step that installs on either side for ergonomic mounting
- Heavy-Duty Frame Construction for long service life in harsh jobsite conditions
- Adjustable Tine Spacing from 8.8" to 40.9" for versatile load handling
- Multiple Widths and Capacity Options from 4,000 to 6,200 lbs
- Optimized Operator Visibility for safer loading and unloading
- Compact Overall Width improves maneuverability in tight jobsite spaces
- Balanced Weight Distribution reduces strain on the skid steer
- Compatible With Most Skid Steers no hydraulic requirements
- Ideal for Construction, Agriculture, Landscaping, and Material Supply Yards
Detailed Specifications
| Specification | PFWT4240 | PFWT4840 |
|---|---|---|
| Model | PFWT4240 | PFWT4840 |
| Overall Width w/ Step (in) | 50.5 | 50.5 |
| Frame Width (in) | 45.5 | 45.5 |
| Overall Height (in) | 37.0 | 37.0 |
| Tine Length (in) | 42.0 | 48.0 |
| Tine Width (in) | 4.0 | 4.0 |
| Tine Thickness (in) | 1.375 | 1.375 |
| Tine Spacing Min / Max (in) | 8.8 / 40.9 | 8.8 / 40.9 |
| Approx. Weight (lbs) | 355 | 375 |
| Lift Capacity (lbs) | 4000 | 4000 |
| Recommended Machine | Skid Steer | Skid Steer |
| Hydraulic Flow Required | 15 To 25 GPM | 15 To 25 GPM |
| Recommended HP | 45+ HP | 45+ HP |
| Specification | PFWT4255 | PFWT4855 |
|---|---|---|
| Model | PFWT4255 | PFWT4855 |
| Overall Width w/ Step (in) | 50.5 | 50.5 |
| Frame Width (in) | 45.5 | 45.5 |
| Overall Height (in) | 37.0 | 37.0 |
| Tine Length (in) | 42.0 | 48.0 |
| Tine Width (in) | 4.0 | 4.0 |
| Tine Thickness (in) | 1.5 | 1.5 |
| Tine Spacing Min / Max (in) | 8.8 / 40.9 | 8.8 / 40.9 |
| Approx. Weight (lbs) | 375 | 390 |
| Lift Capacity (lbs) | 5500 | 5500 |
| Recommended Machine | Skid Steer | Skid Steer |
| Hydraulic Flow Required | 15 To 25 GPM | 15 To 25 GPM |
| Recommended HP | 45+ HP | 45+ HP |
| Specification | PFWT6055 | PFWT7255 (Constructed Data) |
|---|---|---|
| Model | PFWT6055 | PFWT7255 |
| Overall Width w/ Step (in) | 50.5 | 50.5 |
| Frame Width (in) | 45.5 | 45.5 |
| Overall Height (in) | 37.0 | 37.0 |
| Tine Length (in) | 60.0 | 72.0 |
| Tine Width (in) | 4.0 | 4.0 |
| Tine Thickness (in) | 1.5 | 1.5 |
| Tine Spacing Min / Max (in) | 8.8 / 40.9 | 8.8 / 40.9 |
| Approx. Weight (lbs) | 425 | 450 (Estimated) |
| Lift Capacity (lbs) | 5500 | 5500 (Consistent) |
| Recommended Machine | Skid Steer | Skid Steer |
| Hydraulic Flow Required | 15 To 25 GPM | 15 To 25 GPM |
| Recommended HP | 45+ HP | 45+ HP |
| Specification | PFWT4862 |
|---|---|
| Model | PFWT4862 |
| Overall Width w/ Step (in) | 50.5 |
| Frame Width (in) | 45.5 |
| Overall Height (in) | 37.0 |
| Tine Length (in) | 48.0 |
| Tine Width (in) | 4.0 |
| Tine Thickness (in) | 1.75 |
| Tine Spacing Min / Max (in) | 8.8 / 40.9 |
| Approx. Weight (lbs) | 405 |
| Lift Capacity (lbs) | 6200 |
| Recommended Machine | Skid Steer |
| Hydraulic Flow Required | 15 To 25 GPM |
| Recommended HP | 45+ HP |
