Virnig V40 Low Profile Dirt Bucket | Models EDV60 To EDV84 | Widths 61.5" To 85.5" | Hydraulic Flow <22 GPM | For Skid Steer & Track Loaders
DESCRIPTION
The Virnig V40 Low Profile Dirt Bucket delivers reliable performance, smart design, and proven Virnig craftsmanship all at an accessible price point. Built specifically for small skid steers and compact track loaders under 2,200 lbs operating capacity, this low-profile bucket gives operators the visibility and control needed to work efficiently on dirt, gravel, and general-purpose material handling tasks.
Engineered for value without compromise, the V40 features a 3/4" x 6" weld-on cutting edge and a visible edge from the cab, allowing operators to grade, dig, and backdrag with precision. Reinforced gusseting and 1/2" x 3" wear bars protect the bucket bottom from heavy wear, extending the service life even in demanding conditions.
Whether you’re leveling driveways, cleaning job sites, or moving loose materials, the Virnig V40 Dirt Bucket is the dependable, low-maintenance choice for compact machines. It’s everything you need in a dirt bucket tough, balanced, and built to perform day after day.
Key Features
- Optimized for Small Skid Steers & Track Loaders Designed for machines under 2,200 lbs rated operating capacity.
- Excellent Visibility from the Cab Low-profile design keeps the cutting edge in sight for precise grading and digging.
- Heavy-Duty Cutting Edge 3/4" x 6" weld-on edge ensures durability and clean cuts in dirt, gravel, and light aggregate.
- Hydraulic Flow Range Compatible with machines delivering <22 GPM.
- Reinforced Construction Additional gusseting along the back adds strength and resists bucket flexing under load.
- Wear Protection for Longevity Two to three 1/2" x 3" wear bars on the bucket bottom reduce metal fatigue.
- Compact Machine Compatibility Ideal for light-duty skid steers and track loaders with lower hydraulic flow systems.
- Low Overall Height At only 20" tall, the bucket provides excellent forward visibility for precise operation.
- Durable Shell & Side Plates 3/16" (0.19") steel thickness balances strength and weight for smaller machines.
- Efficient Material Handling Heaped capacity up to 20.0 cubic feet (depending on model) boosts productivity.
- Optimized 66° Back Angle Ensures smooth loading, dumping, and material retention.
- Available Widths 60" to 84" Multiple model sizes fit a range of compact loaders and job requirements.
- Optional Bolt-On Cutting Edges Choose from reversible or serrated bolt-on edges for extended service life.
- Precision Fitment Works seamlessly with universal skid steer quick attach systems.
- Compact Weight Profile Weighs between 395 and 505 lbs for balanced performance on smaller equipment.
- Virnig-Quality Fabrication Designed, welded, and finished in the USA for professional-grade durability.
Detailed Specifications
| Specification | EDV60 | EDV66 |
|---|---|---|
| Overall Width (in) | 61.5 | 67.5 |
| Inside Width (in) | 59.3 | 65.3 |
| Overall Height (in) | 20.0 | 20.0 |
| Depth (Overall / Inside in) | 35.0 / 31.8 | 35.0 / 31.8 |
| Capacity (Struck / Heaped cu ft) | 11.6 / 13.9 | 12.8 / 15.4 |
| Shell Thickness (in) | 0.19 | 0.19 |
| Side Plate Thickness (in) | 0.19 | 0.19 |
| Structural Wear Bars (½" x 3") | 2 | 2 |
| Bucket Back Angle (°) | 66 | 66 |
| Approximate Weight (lbs) | 395 | 420 |
| Recommended Loader Capacity | < 2,200 lbs | < 2,200 lbs |
| Recommended Machine Power | 35–50 HP | 35–50 HP |
| Hydraulic Flow | < 22 GPM | < 22 GPM |
| Compatible Machines | Skid steers & compact track loaders | Skid steers & compact track loaders |
| Primary Use | Light dirt work, grading, and material handling | Light dirt work, grading, and material handling |
| Specification | EDV72 | EDV78 |
|---|---|---|
| Overall Width (in) | 73.5 | 79.5 |
| Inside Width (in) | 71.3 | 77.3 |
| Overall Height (in) | 20.0 | 20.0 |
| Depth (Overall / Inside in) | 35.0 / 31.8 | 35.0 / 31.8 |
| Capacity (Struck / Heaped cu ft) | 14.1 / 16.9 | 15.4 / 18.9 |
| Shell Thickness (in) | 0.19 | 0.19 |
| Side Plate Thickness (in) | 0.19 | 0.19 |
| Structural Wear Bars (½" x 3") | 2 | 3 |
| Bucket Back Angle (°) | 66 | 66 |
| Approximate Weight (lbs) | 445 | 480 |
| Recommended Loader Capacity | < 2,200 lbs | < 2,200 lbs |
| Recommended Machine Power | 35–50 HP | 35–50 HP |
| Hydraulic Flow | < 22 GPM | < 22 GPM |
| Compatible Machines | Skid steers & compact track loaders | Skid steers & compact track loaders |
| Primary Use | Grading, site cleanup, and general dirt work | Grading, site cleanup, and general dirt work |
| Specification | EDV84 |
|---|---|
| Overall Width (in) | 85.5 |
| Inside Width (in) | 83.3 |
| Overall Height (in) | 20.0 |
| Depth (Overall / Inside in) | 35.0 / 31.8 |
| Capacity (Struck / Heaped cu ft) | 16.7 / 20.0 |
| Shell Thickness (in) | 0.19 |
| Side Plate Thickness (in) | 0.19 |
| Structural Wear Bars (½" x 3") | 3 |
| Bucket Back Angle (°) | 66 |
| Approximate Weight (lbs) | 505 |
| Recommended Loader Capacity | < 2,200 lbs |
| Recommended Machine Power | 35–50 HP |
| Hydraulic Flow | < 22 GPM |
| Compatible Machines | Skid steers & compact track loaders |
| Primary Use | Dirt work, grading, and light material loading |
