Product Description
Virnig V60 Two-Cylinder Pipe & Mat Pallet Fork Grapple | Models PPFG248 & PPFG260 | Widths 48" & 60" | Hydraulic Flow 15 To 25 GPM | For Skid Steer
DESCRIPTION
Upgrade your skid steer’s versatility and handling power with the Virnig V60 Two-Cylinder Pipe & Mat Pallet Fork Grapple engineered for efficiency, strength, and durability in demanding job sites. Designed for contractors, landscapers, farmers, and material handlers, this grapple attachment makes moving pallets, logs, scrap, and bulky materials faster, safer, and more precise.
With independently operating clamp arms that open near vertical, the V60 grapple delivers superior control and material retention, reducing spills and improving loading speed. Built with NitroSteel® cylinder rods and Teflon® coated bushings, it provides long-lasting performance even under heavy-duty use. Whether you’re handling palletized goods, pipe, or mats, this grapple makes your skid steer more versatile and productive.
The V60’s robust forged tines, available in 48" and 60" widths, are engineered to handle heavy loads while minimizing wear. Quick attachment design and rugged construction ensure minimal downtime, so you can focus on getting the job done efficiently.
Key Features
- Two-Cylinder Independent Clamp Arms Offers precision handling and near-vertical opening for effortless material control.
- Durable Forged Tines Available in 48” or 60”, perfect for pallets, pipes, mats, and bulky loads.
- Heavy-Duty NitroSteel® Cylinder Rods Enhanced strength for long-term performance under tough workloads.
- Hydraulic Flow Range Compatible with machines delivering 15–25 GPM.
- Teflon® Coated Pivot Bushings Reduced friction and longer-lasting pivot points for smooth operation.
- Skid Steer Compatible Fits most loaders with 1,500+ lbs capacity.
- High Lift Capacity Handles up to 6,200 lbs depending on tine size.
- Optimized Tine Spacing Min/max tine spacing ensures secure lifting of diverse materials.
- Quick-Attach Ready Easy mounting for fast skid steer integration.
- Rugged Build Heavy-duty steel construction resists bending, warping, and wear.
- Versatile Load Handling Perfect for construction, landscaping, agriculture, and industrial applications.
- Precision Control Independent arms allow delicate material positioning without tipping.
- Minimal Maintenance Teflon® bushings and hardened pins reduce the need for frequent servicing.
- Time-Saving Design Efficient material loading, stacking, and transport for job site productivity.
- Enhanced Safety Secure grip reduces material drops and improves operator confidence.
- Long-Term Investment Built for years of rugged, reliable service with heavy-duty performance.
Detailed Specifications
| Specification | PPFG248 |
|---|---|
| Overall Width (in) | 70.8 |
| Overall Height Open / Closed (in) | 81.4 / 40.4 |
| Overall Depth (in) | 56.0 |
| Grapple Arm Width (in) | 8.3 |
| Tine Space Min / Max (in) | 8.9 / 49.1 |
| Tine Length / Width / Thickness (in) | 48 / 4 / 1.75 |
| Cylinder Bore / Stroke (in) | 2.0 / 8.375 |
| Cylinder Pins / Hinge Pins Diameter (in) | 1.25 / 1.25 |
| Lift Capacity (lbs) | 6200 |
| Approx. Weight (lbs) | 920 |
| Recommended Loader Capacity (lbs) | >1500 |
| Required Skid Steer HP | 50–70 |
| Specification | PPFG260 |
|---|---|
| Overall Width (in) | 70.8 |
| Overall Height Open / Closed (in) | 81.4 / 40.4 |
| Overall Depth (in) | 67.5 |
| Grapple Arm Width (in) | 8.3 |
| Tine Space Min / Max (in) | 8.9 / 49.1 |
| Tine Length / Width / Thickness (in) | 60 / 4 / 1.5 |
| Cylinder Bore / Stroke (in) | 2.0 / 8.375 |
| Cylinder Pins / Hinge Pins Diameter (in) | 1.25 / 1.25 |
| Lift Capacity (lbs) | 5500 |
| Approx. Weight (lbs) | 925 |
| Recommended Loader Capacity (lbs) | >1500 |
| Required Skid Steer HP | 50–70 |
