Product Description
Wallenstein | Log Splitters | WX900 Series | Split Force 25-31 Ton | Horizontal & Vertical Splitting | For Heavy-Duty Wood Processing
DESCRIPTION
Split smarter, not harder meet the Wallenstein WX900 Series. Whether you’re managing a rural property, processing firewood commercially, or building a high-demand rental fleet, the Wallenstein WX950 through WX980L log splitters deliver unmatched performance and versatility.
Powered by the reliable Honda GX270 270cc engine, these heavy-duty gas log splitters boast 25 to 31 tons of direct hydraulic force, making quick work of dense hardwoods and oversized logs. Choose from models designed for horizontal splitting or dual-mode vertical/horizontal configurations, all with wide wedge blades that “pop” logs apart cleanly and quickly.
Thanks to the integrated hydraulic log lifter, even the biggest rounds are lifted with ease, reducing fatigue and improving safety. Available in multiple split lengths 24", 36", or 48" you can select the model that fits your firewood workflow best.
Built to work all day and tow anywhere, the WX900 series is engineered for rugged dependability and peak efficiency in real-world conditions.
Key Features
- 25 to 31 Tons of Split Force Handle anything from backyard firewood to commercial hardwood processing.
- Reliable Honda GX270 270cc Engine Renowned for power, durability, and easy starts.
- Hydraulic Log Lifter Save your back; lift heavy rounds with minimal effort.
- Wide Wedge Design Pops logs early for faster, cleaner splits.
- Horizontal or Dual Horizontal/Vertical Models Choose the right configuration for your needs.
- Variable Splitting Capacity Models support 24", 36", or 48" log lengths.
- Tow-Ready Frame with 2” Ball Hitch Take it anywhere the job demands.
- High-Capacity Hydraulic Reservoir Up to 5 gallons for longer operation time.
- Cycle Times as Fast as 5.24 Seconds High throughput for demanding workloads.
- Available with Factory Light Kit (WX980L) Road-ready with enhanced visibility.
- Customizable Colors Choose from 9 durable powder coat options, including. Realtree® Camo
Detailed Specifications
| Specification | WX950 | WX960 | WX970 | WX980 | WX980L |
|---|---|---|---|---|---|
| Split Force | 25 Ton | 25 Ton | 25 Ton | 31 Ton | 31 Ton |
| Split Opening | 24" (61 cm) | 36" (91 cm) | 48" (122 cm) | 24" (61 cm) | 24" (61 cm) |
| Orientation | Horizontal | Horizontal | Horizontal | Horizontal / Vertical | Horizontal / Vertical |
| Cycle Time (Avg/Full) | 5.24s / 10.48s | 7.86s / 15.72s | 10.48s / 20.96s | 6.69s / 13.38s | 6.69s / 13.38s |
| Cylinder Diameter | 4.5" (11 cm) | 4.5" (11 cm) | 4.5" (11 cm) | 5" (13 cm) | 5" (13 cm) |
| Engine | Honda GX270 (270 cc) | Honda GX270 (270 cc) | Honda GX270 (270 cc) | Honda GX270 (270 cc) | Honda GX270 (270 cc) |
| Weight | 785 lbs (356 kg) | 990 lbs (449 kg) | 1135 lbs (515 kg) | 635 lbs (288 kg) | 635 lbs (288 kg) |
| Dimensions (L×W×H) | 81" x 63" x 38" | 107" x 63" x 38" | 130" x 63" x 38" | 80" x 50" x 42" | 80" x 50" x 42" |
| Bed Height | 25" (64 cm) | 25" (64 cm) | 25" (64 cm) | 26" (66 cm) | 26" (66 cm) |
| Wedge Height | 10" (25 cm) | 10" (25 cm) | 10" (25 cm) | 10" (25 cm) | 10" (25 cm) |
| Towable | Yes | Yes | Yes | Yes | Yes (w/ lights) |
| Hydraulic Capacity | 5 US gal (20 L) | 5 US gal (20 L) | 5 US gal (20 L) | 4.5 US gal (17 L) | 4.5 US gal (17 L) |
| Hitch | 2" Ball | 2" Ball | 2" Ball | 2" Ball | 2" Ball |
Manuals & Documents
W4110, W4120, W4130, W4140 Wedge install instructions
Z97822 W4211 Splitter Clamp on Shelf Installation Instructions
W4213 & W4214 SPLITTER STROKE LIMITER KITS Installation & Use Instructions
WX Series Wood Splitters 500, 600 ,and 900 Series
WX Series Wood Splitters 500, 600 ,and 900 Series (After May 2016)
CE Certified EU WX Series Trailer Wood Splitter
