Abyss® 36V 105Ah Lithium Trolling Motor Battery
Abyss® 36V 105Ah Lithium Trolling Motor Battery
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Abyss® 36V 105Ah Lithium Trolling Motor Battery
DESCRIPTION
The ABYSS® 36V 105Ah Lithium Trolling Motor Battery is your ultimate power solution for marine adventures. Specifically engineered for center console boats 39 feet and larger, this Group 4D lithium battery is a game-changer. It replaces three 12V lead-acid or AGM batteries, saving valuable storage space and reducing overall weight.
This battery is perfect for deep cycle use, providing reliable and consistent power for load-heavy applications like trolling motors and onboard electronics. Whether you're navigating calm waters or braving strong winds, the ABYSS® 36V 105Ah ensures uninterrupted performance. With advanced Bluetooth® monitoring, you can track your battery's performance in real time, and the built-in heating system guarantees seamless operation in colder environments.
Design Features:
- Higher qualified cylindrical cells 🔋
UL1642, IEC62619, IEC62133 listed with Cycle life more than 3000 times and excellent consistency.
- Bluetooth® Connectivity 📲
Monitor the battery status (charge, discharge, current, temperature, cycle life and so on) and change the data for different applications.
- Built-in Heating ♨️
- More stable and firm internal structure ⚙️
The cell holders within our battery protect and separate each cell to avoid any short circuit risks caused by intense vibration or impact. The separation and space created between each cell also improves the overall heat dissipation within the battery pack while charging and discharging.
Battery Safety
ISO 14001:2004 Environmental Management System
Abyss Battery®, Inc manufacturing process is compliant and licensed on a international level by TÜV Rheinland for Functional Safety as a result of exposure to harsh marine environments such as vibration, impact, ignition protection, water ingress and salt spray corrosion common on pleasure craft and boats. TÜV Rheinland stands for safety and quality in virtually all areas of business and life. TÜV Rheinland’s highly qualified experts test technical systems and products around the world, support innovations in technology and business, train people in numerous professions and certify management systems according to international standards. In doing so, the independent experts generate trust in products as well as processes across global value-adding chains and the flow of commodities. Since 2006, TÜV Rheinland has been a member of the United Nations Global Compact to promote sustainability and combat corruption.
UN/DOT 38.3: Lithium Battery Transportation
All Abyss Battery®, Inc. Lithium Batteries are required to pass section 38.3 of the UN Manual of Tests and Criteria, to ensure the safety of using products for our end users and for shipping purposes. We are proud of our investment to ensure our products have been UN38.3 certified.
T1 – Altitude Simulation
This is low pressure testing that simulates unpressurized airplane space (cargo area) at 15,000 meter altitude. After storing batteries at 11.6kPa for >6 hours, these criteria shall be met: no mass loss, leaking, venting, disassembly, rupture or fire, and voltage within 10% of pre-test voltage.
T2 – Thermal Test
This test covers changes in temperature extremes from -40°C to +75°C. Batteries are stored for 6 hours at -40°C (12 hours for large cells/batteries), then 6 hours at +75°C (12 hours for large cells/batteries), for a total of 10 cycles. Testing may be performed in a single chamber or thermal shock chamber, but less than 30-minute transitions shall be used.
T3 – Vibration
This test simulates vibration during transportation. Test is a Sine Sweep: 7Hz – 200Hz – 7Hz in 15 Minutes; 12 Sweeps (3 hours); 3 mutually perpendicular axes.
T4 – Shock
This test also simulates vibration during transportation. Test is a Half-Sine pulse: 150G/6ms for small cells/batteries; 50G/11ms for large cells/batteries; 3 pulses per direction; 6 directions (+/-z, +/-x, +/-y). Same pass criteria as T1.
T5 – External Short Circuit
This test simulates an external short to the terminals of the cell or battery. At temperature of +55°C, apply short circuit (<0.1ohm) across terminals. Maintain at least an hour after sample temperature returns to +55 +/-2°C. Pass criteria are: Case temperature does not exceed +170°C and no disassembly, rupture, or fire within 6 hours of test. Fuse, current limiting circuit, and venting mechanism activation are allowable.
T6 – Impact
This test is only applicable to primary and secondary cells. For cylindrical cells >20mm diameter, it simulates impact to case of cell. For cylindrical cells <20mm diameter and all other cell constructions, it simulates crushing of a cell. Pass criteria for any type is: Case temperature does not exceed +170°C & no disassembly or fire within 6 hours of test.
T7 – Overcharge
This test is for secondary or rechargeable batteries only. It simulates an overcharge condition on a rechargeable battery: 2x the manufacturer’s recommended charge current for 24 hours. Then battery shall be monitored for 7 days for fire or disassembly.
T8 – Forced Discharge
This testing simulates a forced discharge condition for primary and secondary cells only.
Warranty
Manufacturer’s Limited Warranty
| Warranty Coverage | 5-Year Free Replacement | After 5 years, 35% Off a New Replacement up to 10-Years |
Extended Warranty
| Extended Coverage | 7-Year Free Replacement | After 7 years, 50% off a new Replacement For Life |
Enjoy 7 years of peace of mind when you buy ReCharge+ for your Battery. ReCharge+ for Abyss Battery® Extends your Free 5-Year Replacement Coverage by 2+ additional years from your purchase. In addition to a free battery replacement, you’ll get 24/7 priority access to our Battery experts by chat or phone.
One stop for support:
- 24/7 priority access to Battery experts by chat or phone
- Global repair coverage
- Onsite repair for Batteries: Request that a technician come to your work site
- Mail-in repair: Mail in your Battery using a prepaid shipping box provided by Abyss Battery
- Carry-in repair: Bring your Battery in to our Authorized Service Providers
Key Features
- Compact & Lightweight Design: Efficiently replaces three bulky 12V lead-acid batteries.
- Smart Monitoring: Bluetooth® app for real-time tracking of battery status, temperature, and performance metrics.
- Cold-Weather Performance: Built-in heating system for optimal functionality in low-temperature conditions.
- Extended Cycle Life: 3000 cycles at 100% DOD and up to 6000 cycles at 80% DOD.
- Durable & Waterproof: IP65-rated case for water and dust resistance, ensuring marine-grade durability.
Detailed Specification
36V 105AH BATTERY DATASHEET
| TECHNICAL SPECIFICATIONS | DETAILS |
| Nominal Voltage | 38.4V |
| Nominal Capacity | 105Ah |
| Parallel Connection | Maximum 6 units |
| Serial Connection | No |
| Bluetooth Management System (BMS) | 12S80A (Available on Android/iOS) |
| Charge Voltage | 43.2±0.6 |
| Standard Charge Current | 21A |
| Fast Charge Current | 52A |
| Max. Continuous Discharge Current | 100A |
| Peak Discharge Current | 700A (300ms) |
| Discharge Cut-off Voltage | 30V |
| Cycle Life | 3000 cycles @ 100% Depth of Discharge (DOD) and 6000 cycles @ 80% DOD |
| Self Discharge Rate | Less than 3% per month |
| Charge Efficiency | 100% @0.2C |
| Discharge Efficiency | 98-100% @1C |
| Operating Charge Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Operating Discharge Temperature Range | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature Range | -5°C to 45°C (23°F to 113°F) |
Physical Specifications
- Dimensions: 20.47" x 9.44" x 8.66" in
- 521 x 238 x 218mm (Group 4D）
- Approximate Weight: 61 lbs (29 Kg)
- Terminal Type: M8
- Case Color/Material: Black Plastic case (ABS)
- IP Rating: IP65
- Cell Type: Cylindrical LiFePO4 cell
- Cell Holder: Yes
In Package
- ABYSS® 36V 105Ah Lithium Trolling Motor Battery
- Bluetooth® Monitoring App (Android/iOS compatible)
- User Manual
Manuals & Documents
BATTERY MANUAL
CHARGER MANUAL
BLUETOOTH® APP QUICK GUIDE
ELECTRIC REEL BATTERY
ABYSS 12V120AH DATA SHEET
GROUP 31 BATTERY DATA SHEET
