| 10' PULL TYPE CUTTER | |
| The PTO powered Pulsar series of rotary cutters provide excellent mowing and shredding performance for tractors rated between 20-50 HP. The 3PH mount models are available in a variety of cutting widths providing a cutting path from 48" - 72". To better adapt to your conditions, the Pulsar features an adjustable cutting height of 2" - 10" and a floating top link. This combination allows you to get the ideal cut for your field or roadside. Shipping Weight (LBS.) 380 3PH Mount CAT 1 Cutting Height 2"-10" Cutting Path 48" Max Brush Diameter 1" Tip Speed (Ft/Min) 13,100 Wheels 16" SEGMENTED Blades 1/2" X 3" Tractor HP (min) 30 PTO RPM 540 Gearbox Rating 40 Deck 10GA Stump Jumper YES Rubber Guard STD. Protection (Std./Opt.) SHEAR PIN |
SPECIFICATION
| Part #: | PRCPLUS120 |
| Mfg: | MK MARTIN |
| Category: | TRACTOR ATTACHMENTS |
| SubCategory: | ROTARY CUTTER PULL TYPE |
| Industry: | AGRICULTURAL |
| Machine Size: | TRACTOR |
| Attachment Size: | 120" WORKING WIDTH |
FEATURES
| FIXED SKID SHOE |  |
| PULSAR BLADE ASSEMBLY |  |
| FLOATING TOP LINK |  |
| SEGMENTED WHEEL |  |
15' BATWING CUTTER
DESCRIPTION
| 15' BATWING CUTTER | |
| MK Martin presents the Pulsar Wing. Available in a 15' model, the three triple blade assemblies make short work of stubble whether in the pasture, field, or brush. Each wing can independently float 20° in either direction to conform to the contours of the ground. The 15' width of the cutter can be greatly reduced by folding up both hydraulic wings to better transport from one field to another, and to store the cutter in tight spaces. Features & Options 15' dual wing rotary cutter 4 heavy duty gearboxes, each covered with limited 5 year warranty Transport lock for each wing 1.5" diameter cutting capacity Shipping Weight (LBS.) 4,400 3PH Mount Draw Bar Hitch Cutting Height 3"-15" Cutting Path 180" Max Brush Diameter 1.5" Overall Width (Wings Down) 184" Folded Width (Wings Up) 78" Tip Speed (Ft/Min) 15,100 ft/min on Wings 14,850 ft/min on center Wheels (Pneumatic) 21" Blades 9 blades 1/2"x4" Tractor HP (min) 75HP PTO RPM 540 Gearbox Rating (Wing) 140 HP Gearbox Rating (Center) 105 HP Gearbox Rating (Divider) 87 HP Deck 3/16" Stump Jumper Yes Protection Independent Slip Clutch on Each Spindle |
SPECIFICATION
| Part #: | PW180 |
| Mfg: | MK MARTIN |
| Category: | TRACTOR ATTACHMENTS |
| SubCategory: | ROTARY CUTTER PULL TYPE |
| Industry: | AGRICULTURAL |
| Machine Size: | TRACTOR |
| Attachment Size: | 15' WORKING WIDTH |
FEATURES
| Pneumatic Wheels |  |
| 20° Contour Cutting |  |
| Gearbox |  |
| Standard Chain Curtain |  |
| 3 Blade Assembly |  |
| Steel Blade Guard |  |
| Transport Lock |  |
