Product Description
2025 Barko Trailer-Mounted Loader | Model 295B | Width 8' 5" Ft | Horsepower 173 HP | For Efficient Loading Operations
Ripping It has partnered with Quality Equipment to provide you the best pricing and service on all your Barko's needs!
DESCRIPTION
The Barko 295B Trailer-Mounted Loader is engineered for outstanding operational efficiency and performance in heavy-duty loading tasks. Powered by a 173 HP Cummins QSB6.7 Tier 4 diesel engine, this compact yet robust machine delivers excellent fuel efficiency and power. Featuring pilot-operated controls, load-sensing hydraulics, and a durable all-welded boom design, the 295B ensures operator comfort, precision, and reliable productivity. Its trailer-mounted frame provides exceptional stability, making it ideal for demanding industrial and forestry environments.
Key Features
- Powerful Engine: Driven by a 173 HP Cummins QSB6.7 Tier 4 diesel engine with SCR aftertreatment for fuel efficiency and reduced emissions.
- Trailer Stability: Mounted on a center unitized subframe with foldaway stabilizers for added stability during operation.
- Hydraulic Precision: Load-sensing hydraulic system provides precise power metering, adapting to most attachments while reducing operator fatigue.
- 360-Degree Boom Rotation: Continuous boom rotation with dual motors and planetary gearboxes delivers 30,000 ft-lbf swing torque for smooth and accurate performance.
- Boom Strength: All-welded box-type boom construction ensures durability and fatigue resistance, with a maximum horizontal reach of 30 feet.
- Operator Comfort: Climate-controlled, insulated cab with suspension seat, ergonomic joystick controls, and tinted windows for safe and comfortable operation.
- Service Accessibility: Centralized grease points, removable panels, and bolt-on cylinder glands simplify maintenance and extend the machine’s longevity.
Detailed Specifications
| Category | Details |
|---|---|
| Overall Height | 13' 8" (417 cm) |
| Overall Length | 38' 10" (1,184 cm) with boom extended |
| Overall Width | 8' 5" (257 cm) |
| Ground Clearance | 7" (178 mm) |
| Stabilizer Width | 15' 8" (478 cm) |
| Tail Swing | 8' 8" (264 cm) with 1,300 lbs counterweight, 8' 10" (269 cm) with 3,000 lbs counterweight |
| Operating Weight | 23,500 lbs (10,659 kg) without attachment |
| Maximum Speed | N/A for trailer-mounted configuration |
| Horizontal Reach | 30' (914 cm) |
| Vertical Reach | 37' 6" (1,143 cm) |
| Maximum Lift Capacity | 22,820 lbs (10,351 kg) |
| Tank Capacity | 112 gal. (424 L) |
| Pump Flow Rate | 88 GPM (333 LPM), variable displacement piston |
| Operating Pressure | 3,000 psi (206 bar) |
| Swing Torque | 30,000 ft-lbf (40,674 Nm) |
| Rotation Speed | 8 RPM |
| Operator Comfort | Weather-sealed, insulated, and climate-controlled cab with ergonomic joystick controls |
| Service-Friendly Design | Centralized hydraulic valves, removable panels |
