Autel Robotics EVO II Dual 640T V3 Thermal Drone Rugged Bundle

Product Description

Autel Robotics EVO II Dual 640T V3 Thermal Drone Rugged Bundle

DESCRIPTION

Autel EVO 2 Dual 640T V3 thermal drone is an industry-first drone combining infrared imaging camera with 8K video camera. With thermal resolution up to 640x512 and an 8k sensor EVO 2 becomes a workhorse. First responders, contractors, and business owners finally have a compact and portable tool that gives them the data they have been asking for.

• No Geofencing
• 7.9" Smart Controller
• 15KM Image Transmission
• SkyLink 2.0
• 50MP Picture/0.8" CMOS Sensor
• 640*512 Thermal Imaging Resolution
• 10 Thermal Color Palettes
• 360° Obstacle Avoidance
• Dynamic Track 2.1
• 38 Mins Flight Time

Thermal Drone

Equipped with a 640 x 512 high-resolution thermal imaging camera featuring a 13mm focal length lens and 16x digital zoom, Autel 640T V3 is easier than ever to observe distant targets. The system uses a new image processing algorithm, making thermal details clearer and more discernible than other options with similar resolution and hardware..

DRI Ranges

See a specific subject's identity, activity, or personal items.

Multiple Temperature Measurement Modes

Central, Spot, And Regional Temperature Measurement EVO II 640T V3 Central temperature measurement:

View real-time display of the temperature in the center area of the screen. Spot temperature measurement: Tap the screen, and the temperature of the selected object will be displayed in real time. Regional temperature measurement: Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.

 Temperature Alarm And Image Enhancement Temperature alarm: Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set threshold. Isotherm: Set a temperature range and the system will detect any objects within the temperature range specified. Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.
 10 Thermal Color Palettes White Hot | Cold and Hot | Rainbow | Enhanced Rainbow | Ironbow | Lava | Arctic | Searing | Gradation |Heat Detection
 Picture-in-Picture Display Mode Visual and thermal imagery of 640T V3 are combined to help users quickly interpret data and aid in critical decision making.

Powerful Infrared Thermal Analysis Tool IRPC TOOL: This free temperature measurement analysis tool is developed specifically for the 640T Series, and enables users to quickly import images, edit and analyze temperature measurements, and generate detailed reports for sharing and collaboration.

50MP Ultra-Sensitive Camera

The EVO II Dual 640T V3's RYYB sensor features the Moonlight Algorithm 2.0 that provides excellent noise reduction in limited lighting conditions, further enhancing its 50 megapixel camera to give users more detail for better forensics and analysis.

• Visual and thermal imagery are combined to help users quickly interpret data and critical decision making. From top to bottom are "Picture in Picture Mode", "infraed More", and "visible Light Mode"

Spot Temperature Measurement:

• Tap the screen, and the temperature of the selected object will be displayed in real time.

Regional Temperature Measurement:

• Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.
• The temperature measurement frame can be dragged to any position on the screen.



Temperature Warning

• Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set thresholds

Note: The temperature alarm takes effects only in Regional temperature measurement mode.





Image Enhancement

• Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.

10 Thermal Color Palettes

• White Hot | Cold and Hot | Rainbow | Enhanced Rainbow | Iron bow | Lava | Arctic | Searing | Gradation | Heat Detection

•






4x Lossless Zoom

Human Search

Powerful Infrared Thermal Analysis Tool(IRPC)



This free temperature measurement analysis tool is developed for the 640T V3, and enables users to quickly import images, edit and analyze temperature measurement, and to generate detailed reports for sharing and coolaboration.(Select the "Word" icon Export report. Generate analysis report)



Applications

Wildlife Management	Wildlife Hunting	Roof Inspection
Industrial Inspection	Iine Inspection	Catch Suspects

Thermal Drones In Wildlife Management

More than 6 million feral hogs roam the United States. From Hawaii to Florida, these invasive cousins of domestic swine have increased their range from 17 states in the 1980s to more than 35 states today. Able to breed year-round with average litters of five-eight piglets, feral hog populations can double in size within four months. Weighing between 75 and 500 pounds, feral hogs’ aggressive behavior is very destructive to agriculture, natural ecosystems, people, pets and livestock.



Thermal imaging helps spot predators that could injure or kill farm animals. This will ensure peace of mind for farm owners. This footage show just how hard Wild Boar are to identify with the naked eye but with the help of the thermal drone they are easy to locate and count.

Crops	Pasture
Livestock	Horticulture



Why Autel EVO II Dual 640T?

Tools for detecting wildlife have evolved a lot in the last century. Binoculars are now quite commonly used throughout the world, followed by light amplifying nighttime vision systems that can be used to spot animals at night. But even nightvision sometimes isn't enough for spotting animals in difficult to see conditions, which is why Autel Robotics offers a range of ever-evolving thermal drones for detecting wildlife.

At the same time, looking down at an altitude of several hundred meters,thermal drone EVO II 640T see through darkness and ignore visual camouflage. Unlike all other nighttime vision systems, they require no light whatsoever to produce a clear image. Many warm-blooded animals are mostly active at night, using the cover of darkness to remain undetected, but will show up clearly in a thermal image, even in total darkness and in practically all weather conditions.

Thermal Drones in Hunting

Welcome to the drone world! While I am vegetarian, I can endorse your efforts for wanting to use a drone for hog hunting!

Using drones to hunt wild hogs is an excellent use case. Add a thermal camera, and they are easier to spot. Using drones to hunt hogs has been a common practice for many years, but it used to be extremely expensive; Hunters in the past have used $15,000+ rigs to make it happen.

Now drones with thermal cameras are cheaper than ever before — and extremely easy to fly.



Thermal Drones In Residential Roof Inspection

On shingle, tile or slate roof structures, you can document the exterior condition of the roof using UAV based high resolution visible imaging where we can easily observe hail damage, wind damage, openings in the roof, cracked tiles and much much more. When it gets wet, it creates a hotter temperature on the surface of the membrane that can be easily detected with infrared imaging.

Low Sloped | Flat Roof Scans

You can identify moisture in commercial roofs with using EVO II Dual 640T Thermal Drone, confirm moisture with further physical testing and process a detailed report that calculates how much of the roof contains moisture.

Shingle | Tile | Slate Roof Surveys

Using drones with high resolution cameras, you can capture detailed images observing hail damage, wind damage, broken or missing shingles or tiles and more, processing detailed reports based on Thermal Drone 640T.

Thermal Drone in Industrial Inspection

•

  The EVO II 640T uses an 8K Visual Spectrum Sensor and 640 Radiometric Thermal Sensor, giving inspectors the ability to perform multiple roof inspections in half the time it takes by conventional methods. Our drone kits will not only allow you to visually inspect the entire building , but also use thermal technology to check for hot spots.

  This enables you to safely and quickly check the status of the structure. As well as to help you identify defects, leakage, and corrosion issues, without having to spend on additional personnel and equipment.

• No production shutdown: Without shutting down the production, a UAV thermal analysis enables us to detect leaks, structures’ heat problems and early signs of weaknesses.
• Safer: Autel EVO II Dual 640T thermal drone enables us to detect anomalies beforehand to avoid real problems, breakdowns or accidents.
• Faster: A thermal camera can detect oil and gas leaks and directly assess reliable assets.
• More accurate:640T thermal drrone take accurate pictures based on different detected temperatures.
• Easier to operate: EVO II Dual 640T drone teams operate with a two-men team and one backpack carrying the intervention equipment. EVO II DUAL 640T interventions are fast, accurate and do not require complex deployment.
• More efficiently: The EVO II Dual 640T with a 40-minute flight time and a 640 x 512 thermal camera can quickly find hidden dangers that were previously invisible to the naked eye.

Thermal Drones In Line Inspections

• When failures occur within electricity networks, they can lead to blackouts, or worse – destructive fires. Advanced thermodiagnostic tools have an important role to play in the prevention of these disasters. One such tool combines cutting-edge thermal imaging systems with the UAV, or drone, to give advance warning of a potential problem.Thermography is the technical field concerned with the contact-free determination of the allocation of a temperature field on the surface of a given body.



A major advantage of this method is that it facilitates the investigation of installations that are already in use at full or partial operational load. Thus, instead of requiring operational shut-down, thermal camera inspections can only be carried out during normal operations – a major boost to efficiency. In fact, full operational loads enhance the accuracy of the inspection.EVO II Dual 640T is equipped with 640*512 high-resolution thermal imaging camera featuring a 13mm focal length lens and 16x digital zoom, it is easy to observe distant targets.



Thermal Drones in Police Use

An Autel EVO II Dual thermal drone saved the day for a Nevada sheriff’s department when a suspect fleeing into the cover of darkness could be located because of his “heat signature.” While one suspect was apprehended pretty quickly, the other fled the scene on foot into the night.Typically, when that happens, the person running gets away because there’s not a great way to maintain visuals in the dark. However, Greenhut used the EVO II’s thermal camera to explore the area until he found the suspect attempting to hide behind a tree. Greenhut locked the drone’s sight in on the man until backup arrived to arrest him.

Deputy Greenhut was able to get eyes on the suspect and provide intel to his responding partners to advise them on the suspect’s whereabouts and whether it appeared he had any weapons. This information is very helpful to ensure a safe and effective response when encountering an unknown individual in the dark of night.

SPECIFICATION

Camera: 8K Camera + FLIR BOSON Thermal Camera

Thermal Camera

Sensor	FLIR BOSON Sensor 640*512/ 320*256
Pixels	EVO II Dual (640) 640*512 EVO II Dual (320) 320*256
Pixel Pitch	12 µm
Wavelength	7.5 - 13.5µm
FOV	EVO II Dual (640) 32° EVO II Dual (320) 34°
Lens	EVO II Dual (640) 14 mm EVO II Dual (320) 6.3 mm
Zoom	1 ~ 8x
Still Image Resolution	Infrared Mode:640x512 Picture in Picture Mode: 1920x1080, 1280x720
Still Image Format	JPEG
Still Photography Modes	Single shot, Burst shooting, Time
Video Resolution	Infrared Mode: 640x512 (US) Picture in Picture Mode: 1920x1080 p30, 1280x720 p30
Video Format	MOV/MP4 (H.264/H.265 supported)

8k Camera

Sensor	1/2" CMOS Effective Pixels: 48 MP Performance temperature: -20~60°C
Lens	FOV: about 79° 35mm Format Equivalent: 25.6 mm Aperture: f/1.8 Shooting Range: 0.5 m to ∞
ISO Range	Video: ISO100~3200 (Auto) Video: ISO100~3200 (Manual) Photo: ISO100~3200 (Auto) Photo: ISO100~3200 (Manual)
Shutter Speed	Electronic Shutter: 8 ~ 1/8000s
Digital Zoom	1 ~ 8x (Max. 4x lossless zoom)
Still Image Resolution	8000x6000 (4:3) 7680x4320 (16:9) 4000x3000 (4:3) 3840x2160 (16:9)
Still Image Format	JPEG / DNG / JPEG+DNG
Still Photography Modes	Single Shot Burst Shooting: 3/5 frames
Video Resolution	7680x4320 p25/p24 5760x3240 p30/p25/p24 3840x2160 p60/p50/p48/p30/p25/p24 2720x1528 p120/p60/p50/p48/p30/p25/p24 1920x1080 p120/p60/p50/p48/p30/p25/p24
Video Format	MOV / MP4
Codecs	H.264 / H.265
Max Video Bitrate	120Mbps
HDR Video Recording	Supports 3840x2160, 2720x1528, 1920x1080 HDR video recording

Gimbal

Weight	0.30 lbs (135 grams)
Mechanical Range	Pitch: -135° to +45 Yaw: -100° to +100°
Controllable Range	Pitch: -90° to +30° Yaw: -90° to +90°
Stabilization	3-Axis (Tilt, Roll, Pan)
Max Control Speed (Tilt)	300°/s
Angular Vibration Range	±0.005°

Aircraft

Takeoff Weight	2.5 lbs (1150 g)
Max Takeoff Weight	4.4 lbs (2000 g)
Dimensions	Folded: 8.98 x 5.24 x 4.33 inch (L x W x H) (228 x 133 x 110 mm) Unfolded: 16.69 x 13.94 x 4.33 inch (L x W x H) (424 x 354 x 110 mm)
Diagonal Distance	15.63 in (397 mm)
Max Service Ceiling Above Sea Level	22,965 ft (7000 m)
Max Flight Time (no wind)	EVO II Dual (640) 38min EVO II Dual (320) 40min
Max Hovering Time (no wind)	EVO II Dual (640) 33min EVO II Dual (320) 35min
Max Flight Distance (no wind)	15.53 miles (25 km)
Max Wind Speed Resistance	39-46 mph (Level 8)
Max Tilt Angle	Standard mode: 28° Ludicrous mode: 33°
Max Angular Velocity	120°/second
Max Ascent Speed	Standard mode: 11.18 mph (5 m/s) Ludicrous mode: 17.89 mph (8 m/s)
Max Descent Speed	Standard mode: 6.71 mph (3 m/s) Ludicrous mode: 8.94 mph (4 m/s)
Max Speed (near sea level, no wind)	Standard mode: 33.55 mph (15 m/s) Ludicrous mode: 44.73 mph (20 m/s)
Operating Temperature Range	14°F to 104°F (-10°C to 40°C)
Operating Frequency	2.4~2.4835GHz
Transmission Power (EIRP)	2.4~2.4835GHz FCC: ≤26 dBm ISED: ≤26 dBm CE: ≤20 dBm RCM: ≤20 dBm SRRC: ≤26 dBm
GNSS	GPS/GLONASS/VIO/ATTI
Hovering Accuracy Range	Vertical: ± 0.78 in (when vision positioning is active) ± 7.87 in (with GPS positioning) Horizontal: ± 0.78 in (when vision positioning is active) ± 3.28 ft (with GPS positioning)
Internal Storage	8 GB
SD Storage	Standard: 32 GB Max Micro SD Card Supported: 256 GB

Sensing System (Obstacle Avoidance)

Sensing System	Omnidirectional Binocular Obstacle Sensing System
Forward	Precision Measurement Range: 0.5-20 m Detectable Range: 0.5-40m Effective Sensing Speed: <15m/s FOV: Horizontal: 60°, Vertical: 80°
Backward	Precision Measurement Range: 0.5-16 m Detectable Range: 0.5-32m Effective Sensing Speed: <12m/s FOV: Horizontal: 60°, Vertical: 80°
Upward	Precision Measurement Range: 0.5-12 m Detectable Range: 0.5-24m Effective Sensing Speed: <6m/s FOV: Horizontal: 60°, Vertical: 50°
Downward	Precision Measurement Range: 0.5-11 m Detectable Range: 0.5-22m Effective Sensing Speed: <6m/s FOV: Horizontal: 100°, Vertical: 80°
Sides	Precision Measurement Range: 0.5-12 m Detectable Range: 0.5-24m Effective Sensing Speed: <10m/s FOV: Horizontal: 60°, Vertical: 50°
Operating Environment	Forward, Backward, Upward and Sides: Surface with clear pattern and adequate lighting (lux > 20) Downward: Surface with clear pattern and adequate lighting (lux > 20) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

Remote Controller

Operating Frequency	2.400 GHz to 2.4835 GHz
Max Transmission Distance	FCC：9 km（without interference or obstruction） CE：5 km（without interference or obstruction）
Real-time Image Transmission Quality	720p@30fps / 1080p@30fps
Maximum Bit Rate of Real-time Image Transmission	40Mbps
Transmission Power (2.4G)	FCC：≤26 dBm ISED：≤26 dBm CE：≤20 dBm RCM：≤20 dBm SRRC：≤20dBm
Display screen	3.26" OLED 854（W） * 480（H）Pixel Directly preview the video without connecting a mobile phone
Remote Controller Battery	5000mAh
Run Time	3 hours
Charging Time	2 hours fast charge
Supported Mobile Device Size	Max Length: 3.30" (84mm) Max Thickness: 0.51" (13mm)
Supported USB Port Types	Lightning, Micro USB (Type-B), USB-C
Working current/voltage	1.7A@3.7V

Battery

Capacity	7100 mAh
Voltage	11.55 V
Max Charging Voltage	13.2 V
Battery Type	LiPo 3S
Energy	82 Wh
Net Weight	0.81 lbs (365 grams)
Charging Temperature Range	41°F to 104°F (5°C to 40°C)
Max Charging Power	93 W
Charging Time	90min

IN THE BOX

VIDEOS

EVO II Dual 640T V3 Thermal Imaging Demonstration

EVO II Dual 640T V3: Thermal Analysis Tool Overview
