Baumalight Fixed Tooth Mulcher | Model MX948R | Rotor Width 48" | Machine Size 6-20 Tons | For Excavators
Baumalight Fixed Tooth Mulcher | Model MX948R | Rotor Width 48" | Machine Size 6-20 Tons | For Excavators
Regular price
$38,920.00
Regular price
Sale price
$38,920.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Baumalight Fixed Tooth Mulcher | Model MX948R | Rotor Width 48" | Machine Size 6-20 Tons | For Excavators
Description
The Baumalight MX948R Brush Mulcher has a 48” rotor and is designed for excavators starting at 12 tons. With a 70” path, the MX948R uses a fixed tooth holder and has 27 heavy duty double carbide tipped teeth (R9000) that are ideal for clearing heavy brush and trees. The MX948R comes with aggressive root rake teeth that are built into the frame. The root rake is perfect for ripping out rocks and moving logs. The unit also has a heavier duty body, built with a low-weight, high-strength AR400 steel and is equipped with replaceable body wear plates.
Key Features
MX948R Brush Mulcher – Features & Specifications |
|
|---|---|
| Replaceable Bolt-In Liner | AR400 wear plates can be replaced without removing the rotor, reducing downtime. |
| Adjustable Belt Tensioner | Quick belt tension adjustment via motor mount lift — no idler wheel required. |
| Optional Two-Speed Motor | Available to optimize torque and speed for changing mulching conditions. |
| Bent Axis Piston Motor | Standard high-efficiency motor maximizes hydraulic flow and pressure output. |
| Case Drain – Vent to Atmosphere | Protects motor seals from pressure spikes and notifies operator if blocked or missed. |
| Wire Protection Kit | Rotor end shielding prevents fence wire from damaging bearings and shafts. |
| Chain Curtain | 3/8” thick chain curtain controls mulch discharge and feed-in brush flow. |
| Root Rake Teeth | Replaceable scraper teeth assist with log pushing and debris clearing. |
| 6 Free Teeth | Ships with 6 spare cutting teeth stored in an onboard enclosed compartment. |
| Easy Grease Fittings | Accessible fittings on exterior frame—no tools required for maintenance. |
| Overtorque Protection | Relief valve mitigates pressure spikes to safeguard motor and hydraulic system. |
| Reinforced Belt | Durable transmission belt handles shocks from heavy mulching loads. |
| Powder Coated Finish | Rugged exterior resists abrasion, corrosion, and rust during high-duty use. |
| Hydraulic Database | Database available to match PSI and flow specs with over 1,000 carrier models. |
| Technical Specifications | |
| Model | MX948R |
| Connection Code | A03 |
| Path Width | 70" |
| Rotor Width | 48" |
| Tracked Excavator Size | 12–30 ton |
| Wheeled Excavator Size | 15–33 ton |
| Cutting Depth | Level |
| Holder Style | Fixed |
| Cutting Style | Double Tipped Carbide |
| Tooth Part # | R9000 |
| Number of Cutters | 27 |
| Rotor Shaft Size | 2" |
| Rotor Diameter (Tool Tips) | 18.5" |
| Rotor Weight (with Tools) | 617 lbs |
| Motor Count | 1 |
| Case Drain | Critical |
| Unit Weight | 2838 lbs |
Detailed Specifications
MX Series Excavator Mulcher Specifications |
||||||||
|---|---|---|---|---|---|---|---|---|
Feature |
MX230 |
MX330 |
MX530 |
MX530R |
MX548R |
MX948R |
MX960R |
MX1160R |
| Connection Code | A02 | A02 | A02 | A02 | A03 | A03 | A03 | A03 |
| Path Width | 38" | 38" | 40" | 40" | 62" | 70" | 90" | 90" |
| Rotor Width | 30" | 30" | 30" | 30" | 48" | 48" | 60" | 60" |
| Min Tracked Excavator Ton | 2 | 3 | 4 | 4 | 7 | 12 | 18 | 18 |
| Min Wheeled Excavator Ton | 4 | 5 | 6 | 6 | 9 | 15 | 21 | 21 |
| Max Tracked Excavator Ton | 6 | 8 | 12 | 12 | 20 | 30 | 33 | 33 |
| Max Wheeled Excavator Ton | 8 | 10 | 14 | 14 | 22 | 33 | 36 | 36 |
| Cutting Depth | Level | Level | 1.5" Above to 1" Below | 1.5" Above to 1" Below | 1.5" Above to 1" Below | Level | Level | Level |
| Holder Style | Swing | Fixed | Fixed | Fixed | Fixed | Fixed | Fixed | Fixed |
| Cutting Style | Flail | High Speed Teeth | Carbide Tipped Bolt In | Carbide Tipped Bolt In | Carbide Tipped Bolt In | Double Tipped Carbide | Double Tipped Carbide | Sharpenable Planer Teeth |
| Tooth Part # | F2000 | H3000 | P5000 | P5000 | P5000 | R9000 | R9000 | P11000 |
| Number of Cutters | 22 | 36 | 44 | 44 | 72 | 27 | 38 | 31 |
| Rotor Shaft Size | 1.5" | 2" | 2" | 2" | 2" | 2" | 2" | 2" |
| Rotor Diameter (Tool Tips) | 17.25" | 15" | 15" | 15" | 15" | 18.5" | 18.5" | 18.5" |
| Rotor Weight (with Tools) | 125 lbs | 175 lbs | 300 lbs | 300 lbs | 408 lbs | 617 lbs | 860 lbs | 872 lbs |
| No. of Motors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Case Drain | Not Important | Not Important | See Motor Options | See Motor Options | Critical | Critical | Critical | Critical |
| Unit Weight | 500 lbs | 750 lbs | 1036 lbs | 1166 lbs | 2167 lbs | 2838 lbs | 2910 lbs | 2925 lbs |
