Baumalight

Baumalight Tree Shear | Model IXP508G, IXP510G & IXP512G | Limb Size 8", 10" & 12" | Machine Size 3-20 Tons| For Excavators

Baumalight Tree Shear | Model IXP508G, IXP510G & IXP512G | Limb Size 8", 10" & 12" | Machine Size 3-20 Tons| For Excavators

Regular price $8,970.00
Regular price Sale price $8,970.00
Sale Sold out
Customizable
Fast
24/7 Support
  • ConstructionMaterial: AR400steel
  • EaseofUse: Greasepinsonallpivotpoints
  • Usage: Landclearing,fencelinemaintenance
  • Cutting Capacity: Efficiently shears trees up to 8 inches in diameter.
  • Built Tough: Constructed with abrasion-resistant AR400 steel for enhanced durability.
  • Hydraulic Power: Powerful hydraulic cylinder for effective cutting performance.
  • Safety Focused: Includes sleeved hydraulic hoses and hose armor for added operator safety.
  • Versatile Mounting: Bolt-on mounting plate with multiple mounting holes for flexible installation
View full details

Product Description

Baumalight Tree Shear | Model IXP508G, IXP510G & IXP512G | Limb Size 8", 10" & 12" | Machine Size 3-20 Tons| For Excavators

DESCRIPTION

The Baumalight IXP Series Pivoting Tree Shear is a high-powered attachment, designed for excavators ranging from 6,000 lbs to 40,000 lbs. Featuring a full 90-degree pivoting radius, these shears provide versatile tree felling options, allowing operators to cut trees upright or shear limbs horizontally. The Incisor model’s grabber arm and fixed curved cradle bar ensure that sheared limbs can be safely maneuvered, improving efficiency and control in forestry applications.

Key Features

  • Cutting Capacity: Capable of cutting trees up to 8 inches in diameter.
  • Construction Material: Made from tough, abrasion-resistant AR400 steel for long-lasting durability.
  • Hydraulic Drive: Equipped with a powerful hydraulic cylinder for efficient cutting.
  • Safety Design: Features sleeved hydraulic hoses and hose armor for operator protection.
  • Versatility: Suitable for both softwoods and hardwoods, including oak, ash, and maple.
  • Ease of Use: Grease pins on all pivot points ensure smooth operation and easy maintenance.
  • Flexible Mounting: Bolt-on mounting plate with multiple mounting holes for flexibility.
  • 90 Degree Rotation: Offers a full 90-degree radius, allowing you to fell trees in the upright position or cut limbs horizontally.
  • Grabber Arm: Comes with an individually moving grabber arm and a fixed curved cradle bar to securely move sheared limbs to a safe location.
Feature Description Image
Tough, Reliable AR400 Steel Constructed from abrasion-resistant AR400 steel, ensuring high durability and wear resistance in demanding cutting conditions.
Heavy Cutting Capability Designed to cut both softwoods and tough hardwoods like oak, ash, and maple. Heavy Cutting
Grabber Arms Individually moving grabber arm and fixed curved cradle bar for secure handling of sheared limbs. Grabber Arms
Grease Pins on Pivot Points Reduces equipment wear, ensuring longer service life and smooth operation. Grease Pins on All Pivot Points
Protected Hydraulic Hose Internally routed hoses with reinforced sleeving to prevent pinching, strain, and damage. Protected Hoses
Hardened Steel Bushing Uses high-grade chrome-vanadium AISI 6150 spring steel bushings for enhanced durability on pivot points. Hardened Steel Bushing

Greaseable Pins Zinc-plated pins prevent corrosion, ensuring smoother operation over time Greaseable Pins



Host Machines Compatibility Chart – Baumalight IXP Series Tree Shear

Here’s a structured breakdown of compatible excavators by weight class, ensuring optimal performance and attachment integration.

6,000 – 20,000 lbs Excavators

Brand Model
Bobcat E42 R2 (LA)
Bobcat E50
Bobcat E55
Bobcat E60
Bobcat E88
Case CX57C
Case CX60C
Case CX75C SR
Case CX80C
Caterpillar 305
Caterpillar 305.5
Caterpillar 306
Caterpillar 307
Caterpillar 308
Doosan DX42-5K
Doosan DX50-5K
Doosan DX62R-3
Doosan DX63-3
Doosan DX85R-3
Hitachi ZX50U-5
Hitachi ZX60USB-5
Hyundai R55-9A
Hyundai R60CR-9A
Hyundai R80CR-9A
John Deere 50G
John Deere 60G
John Deere 75G
John Deere 85G
Kobelco SK45SRX-6E
Kobelco SK55SRX-6E
Kobelco SK75SR-7
Komatsu PC45MR-5
Komatsu PC55MR-5
Komatsu PC78US-11
Kubota KX057
Kubota KX080
Kubota U55
New Holland E57C
New Holland E60C
Sany SY50U
Sany SY60U
Sany SY75C
Sany SY80U
Takeuchi TB260
Takeuchi TB280FR
Takeuchi TB290
Takeuchi TB370
Volvo EC55
Volvo EC60E
Volvo ECR50
Volvo ECR58
Wacker Neuson ET42
Wacker Neuson ET65
Yanmar VIO 50
Yanmar VIO 55
Yanmar VIO 80-1A

16,000 – 40,000 lbs Excavators

Brand Model
Bobcat E145
Bobcat E165
Bobcat E88
Case CX130D
Case CX145D
Case CX160D
Caterpillar 308
Caterpillar 309
Caterpillar 310
Caterpillar M314
Doosan DX140LC-5
Doosan DX140LCR-5
Doosan DX170LC-5
Hitachi ZX130-6
Hitachi ZX160LC-6
Hyundai HX85A
Hyundai R80CR-9A
John Deere 130G
John Deere 135G
John Deere 160G LC
Kobelco SK140SRLC-7
Kobelco SK85SC-7
Komatsu PC130-11
Komatsu PC138USLC-11
Sany SY135U
Sany SY155U
Sany SY80U
Sany SY95C
Takeuchi TB2150
Volvo EC140E
Volvo ECR145C
Volvo ECR88D
Wacker Neuson ET90
Wacker Neuson ET145
Yanmar SV100-2A

10,000 – 30,000 lbs Excavators

Brand Model
Bobcat E88v
Case CX130D
Case CX145D
Case CX60C
Case CX75C SR
Case CX80C
Caterpillar 306
Caterpillar 308
Caterpillar 309
Caterpillar 310
Caterpillar 307
Doosan DX62R-3
Doosan DX63-3
Doosan DX85R-3
Hitachi ZX130-6
Hitachi ZX60USB-5
Hyundai HX85A
Hyundai R60CR-9A
John Deere 130G
John Deere 60G
John Deere 75G
John Deere 85G
Kobelco SK75SR-7
Kobelco SK85SC-7
Komatsu PC130-11
Komatsu PC78US-11
Kubota KX080
New Holland E60C
Sany SY60U
Sany SY75C
Sany SY80U
Sany SY95C
Takeuchi TB280FR
Takeuchi TB290
Takeuchi TB370
Volvo EC60E
Volvo ECR88D
Wacker Neuson ET90
Wacker Neuson ET65
Yanmar SV100-2A
Yanmar VIO 80-1A



Detailed Specifications

IXP Series Limb Shear Specifications


Model

Carrier

Blade Angle

Weight Class

GPM

Limb Size

IXP508G Excavator Pivoting 3–10 ton 5–40 8
IXP510G Excavator Pivoting 5–15 ton 10–40 10
IXP512G Excavator Pivoting 8–20 ton 15–60 12
