Brush Wolf Standard-Duty X- Brush Cutter Series | Cutting Width 36", 42" & 48" inches | Hydraulic Flow Range 8-40 GPM | For Excavators & Backhoe

Brush Wolf Standard-Duty X- Brush Cutter Series | Cutting Width 36", 42" & 48" inches | Hydraulic Flow Range 8-40 GPM | For Excavators & Backhoe

$6,679.20
$6,679.20
Sale Sold out
Customizable
Fast
24/7 Support
  • Blade Technology: Featuring high-tempered, updraft steel blades (14.75 x 4 x 0.5 in) for the 4200X and 4800X models, and Hardox® 500 non-updraft flat-blades (10 x 6 x 0.625 in) for the 3600X model.
  • Robust Construction: Equipped with a deck thickness of 10-ga (.135 in) for the 3600X & 4200X models and 7-ga (.188 in) for the 4800X models. Combined with the machined steel motor/gearbox coupler, pressure relief valves.
  • Advanced Blade Carriers: All Brush Wolf blade carriers, including the 1” GRD-50 disc for the 4200X and 4800X models, and two 1/2" steel bars for the 3600X model, are CNC balanced for ultra-smooth operation.
View full details

Product Description

Brush Wolf Standard-Duty X- Brush Cutter Series | Cutting Width 36", 42" & 48" inches | Hydraulic Flow Range 8-40 GPM | For Excavators & Backhoe

Description


These bulletproof little machines are packed with power and are perfect for clearing steep hillsides, ditches, and tree lines. Our first-generation rotary brush cutters for diggers feature a simplistic design that makes them easy to own and operate. The 3600X and 4200X are made for compact excavators and backhoes to fit flawlessly in tight places. While the 4800X models fit either compact or mid-size excavators/backhoes and offer a 48” cutting width.

Key Features

Image Description

Long-Lasting Blades

The Brush Wolf industrial-strength blades are heat treated, have a milled edge, and are Supertuf coated to stand the test of time.

Premium Hydraulic Motor

We paired the top-of-the-line Eaton® Geroler-style hydraulic motor with the most dependable right-angle Omni® gearbox to achieve maximum torque and ideal blade tip speed. This easy-to-maintain and tried-and-true pairing will survive the years of abuse it will see in the field.

Motor Protection

Pressure Relief Valves: Added pressure relief valves safeguard your motor from pressure spikes and allow for a faster shutdown.

Grade-2 Shear Bolt: protects the gearbox and driveline from damage.

Gearbox Seal Protection

A welded seal guard collar prevents wire, twine, and vegetation from wrapping around and damaging the gearbox.

Ultra-Rugged Deck Frame

Here’s why our brush cutters last for life. We build each deck frame from a single piece of formed heavy-duty steel, never pieced together. This means our frames are consistently better made and more durable, with the elimination of construction errors and frame failure. One-piece frames will always provide superior strength.

Seam Welding

Unlike our competitors, Brush Wolf’s deck and frame construction is fully boxed and continuously welded across each seam for an indestructible, rust-proof support structure.

Reinforced Gussets

We went above and beyond to make sure our cutters are crazy strong by adding boxed-in gusset reinforcements, extra bracing, and supports.

Powder-Coated Tough

Protected with the most durable finishing process, we powder coat every part to minimize rust, resist scratches, and prevent fading, so you get more life out of your brush cutter.

Blade Access Cover

Easy access to the blade bolts for quick blade replacement.

Plug + Play Ready

Everything is ready to go upon delivery with the included quick-connect couplers, 90" hydraulic hoses encased in protective wrap, and dust caps to prevent line contamination.

Chain Curtains

5/16” replaceable safety chains on two sides contain flying debris to protect you and your cutter and aid in mulching.

Pilot Guard

We took safety to the next level by welding a reinforced plate “pilot guard” to the underside of the cutter deck to protect you from flying objects.

Choose Your Color

Black, yellow, or make it your own custom color.



Detailed Specifications

3600X Model:

  • Number of Blades: 2
  • Blade Type: 10 x 6 x 0.625 in Hardox® 500 non-updraft flat-blades
  • Blade Carrier:
    • Two 1/2" steel bars
    • All Brush Wolf blade carriers are CNC balanced for ultra-smooth operation

4200X and 4800X Models:

  • Number of Blades: 2
  • Blade Type: 14.75 x 4 x 0.5 in; high-tempered updraft blades for lift and mulching action
  • Blade Carrier:
    • 1” GRD-50 disc
    • All Brush Wolf blade carriers are CNC balanced for ultra-smooth operation
  • PSI (Continuous/Intermittent):
    • 3,000/3,500 (except 4800X HF: 3,000/4,100)
  • Deck Thickness:
    • 3600X & 4200X: 10-ga (.135 in)
    • 4800X: 7-ga (.188 in)
  • Motor/Gearbox Coupler: Machined steel
  • Motor Protection:
    • Pressure relief valves
    • GRD-2 shear bolt
  • Blade Rotation: Counterclockwise
  • Hood: 12-ga motor guard
Specification 3600X 4200X 4800 X LF 4800 X SF 4800 X HF
Flow Type Low Flow Low Flow Low Flow Standard Flow High Flow
Cutting Width 36 in 42 in 48 in 48 in 48 in
Hydraulic Flow Range 8-20 GPM 8-20 GPM 8-15 GPM 16-25 GPM 26-40 GPM
Max Cutting Diameter 3 in 3 in 3 in 4 in 5 in
Tip Speed 5,500-13,750 ft/min 6,500-16,200 ft/min 7,500-14,000 ft/min 11,750-18,400 ft/min 7,500-11,600 ft/min
Overall Width 39 in 45.13 in 51.13 in 51.13 in 51.13 in
Overall Length 50 in 56.80 in 62.80 in 62.80 in 62.80 in
Weight 550 lbs 690 lbs 860 lbs 860 lbs 890 lbs
