Bushliner Cyclone Factory Experimental | Model 1850-FX | Engine Horsepower Up-To 350 HP | MT-3 Blade Expedition Propeller

Bushliner Cyclone Factory Experimental | Model 1850-FX | Engine Horsepower Up-To 350 HP | MT-3 Blade Expedition Propeller

$1.00
$1.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Lycoming IO-580 Engine: 315-350 horsepower for powerful performance.
  • Professional Finishing: Meticulous attention to detail for a high-quality finish.
  • AeroLED Lighting: Including NSP, Quasar wingtips, and landing lights with a pulse feature for better visibility.
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Bushliner Cyclone Factory Experimental | Model 1850-FX | Engine Horsepower Up-To 350 HP | MT-3 Blade Expedition Propeller

Description

The Bushliner Cyclone 1850FX Factory Experimental offers a hands-on building experience combined with top-of-the-line features. The model includes a variety of customization options and high-performance components that make it a standout in its class.

Key Features

  • Airframe & Equipment:
    • Professionally finished airframe based on the 1850EX section.
    • V-REF value guarantee.
  • Factory Amateur Built (FAB) Program:
    • Two one-week visits to Granite Falls, WA (WA25) facility:
    • Fab Visit 1 (Pre-Paint): Riveting, wiring, engine installation, and instrument panel fabrication.
    • Fab Visit 2 (After Paint): Seats, upholstery, final engine and wing installation, avionics, and rigging.
  • Engine Package:
    • Lycoming IO-580 with 315-350 horsepower.
    • Options for supercharger and Ly-Con tune.
  • Propeller:
    • MT 3 Blade Expedition Propeller.
    • Options for reverse function or four-blade upgrade.
  • Lighting Package:
    • AeroLED’s including NSP, Quasar wingtips, and wing leading edge landing lights with pulse feature.
  • Landing Gear:
    • Titanium main and tail.
    • Options for different configurations and floats.
    • Beringer wheels and brakes (color options available).
    • 29” Alaskan Bushwheels with extra tread.
  • Garmin Avionics Packages:
    • Garmin IFR NAV 1.
    • PFD/MFD: G3X.
    • NAV/COM/GPS 1: GTN 750XI (additional 650XI or 750XI available).
    • GMC 507 Autopilot with Pitch, Roll, yaw damper, electric trim, and Smart Glide.
    • GTX 45R Transponder.
    • Engine Monitor.
    • 2 USB Ports.
    • CIES Fuel Senders.
    • Artex ELT 1,000 USA.
  • Range:
    • 1,000 nautical miles.

Detailed Specifications

Dimensions

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Length 26 ft 25 ft 9 in 29 ft 28 ft 3 in
Height 8 ft 7 ft 9 in 9 ft 4 in 9 ft 4 in
Wingspan 38 ft 36 ft 36 ft 36 ft
Wing Area 186 sq ft 174 sq ft 174 sq ft 174 sq ft
Flap Area 21.5 sq ft 21 sq ft 34 sq ft -
Aileron Area 17.85 sq ft 17.85 sq ft 17.85 sq ft 14.75 sq ft
Horizontal Stabilizer Width 13 ft 10 ft 10 in 11 ft 8 in 13 ft
Horizontal Stabilizer SQFT 36 sq ft 30 sq ft 33 sq ft 36 sq ft
Tail Area % of Wing Area 19.35% 17.24% 18.96% 20.70%

Interior

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Height 50 in 48 in 49 in 50 in
Shoulder Width 45 in 40 in 42 in 44 in
Center Seat Spread (Yoke) 21 in 18 in 19 in 21 in
Length 11 ft 8 in (flat) 11 ft 8 in (stepped) 11 ft 2 in (stepped) 12 ft 1 in (stepped)
Maximum Passengers 4 Special Light Sport 6 4 6

Weights

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Maximum Ramp Weight 3,600 lb 3,350 lb 3,110 lb 3,806 lb
Maximum Takeoff Weight (Gross) 3,600 lb 3,350 lb 3,110 lb 3,789 lb
Maximum Landing Weight 3,600 lb 3,350 lb 2,950 lb 3,600 lb
Usable Fuel Weight (100LL) 672 lb 504 lb 522 lb 522 lb
Usable Fuel Volume 112 gal 84 gal 87 gal 87 gal
Basic Empty Weight 1,850 lb 1,850 lb 2,000 lb 2,365 lb
Useful Load 1,750 lb 1,500 lb 1,110 lb 1,441 lb
Full Fuel Payload 1,078 lb 996 lb 588 lb 919 lb
Wing Loading @ Gross Weight 19.35 lb/sqft 19.3 lb/sqft 17.8 lb/sqft 20.7 lb/sqft

Performance

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Max Endurance Range 1,042 nm 721 nm 930 nm 660 nm
Max Speed Range 752 nm 576 nm 773 nm 632 nm
Takeoff Distance 1,200 ft 1,365 ft 1,514 ft 1,970 ft
Ground Roll 650 ft 770 ft 795 ft 1,060 ft
Landing Distance 1,200 ft 1,400 ft 1,350 ft 1,395 ft
Ground Roll 480 ft 480 ft 590 ft 735 ft
Service Ceiling 19,000 ft 17,150 ft 18,100 ft 26,000 ft
Maximum Climb Rate 1,500 fpm 1,010 fpm 924 fpm 960 fpm
Maximum Limit Speed 175 kias (201 mph) 155 kias (178 mph) 175 kias (201 mph) 182 kias (209 mph)
Stall Speed 40 kcas (46 mph) 49 kcas (56 mph) 49 kcas (56 mph) 57 kcas (66 mph)
Maximum Cruise Speed 165 ktas (190 mph) 145 ktas (167 mph) 165 ktas (190 mph) 161 ktas (185 mph)
Power to Weight 11.42 lb/hp 11.17 lb/hp 13.5 lb/hp 11.6 lb/hp
Cruise Speed @ 75% 10,000 ft 150 kt (172 mph) 130 kt (150 mph) 145 kt (166 mph) 150 kt (172 mph)
Fuel Burn @ 75% Power 18 gph 100LL 15.6 gph 100LL 17.8 gph 100LL 19 gph 100LL

Powerplant

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Manufacturer Lycoming Continental Lycoming Lycoming
Model IO-580 IO-520D IO-540-AB1A5 TIO-540-AJ1A
Power Output 315 hp 300 hp 230 hp (235 hp) 310 hp (310 hp)
Propeller Manufacturer MT Propeller McCauley McCauley McCauley
Description 3 blade composite cs 2 blade aluminum cs 3 blade aluminum cs 3 blade aluminum cs

Cargo Capacity

Specification Bushliner 1850 Cyclone EST Cessna A185F Skywagon Cessna 182T Skylane Cessna T206H Stationair
Weight 200 lb 170 lb 200 lb 180 lb
Volume 34.8 cu ft 24.75 cu ft 32 cu ft 11 cu ft (39 cu ft total)
Cargo Door Dimension W x H 49 in x 36 in (aft 26") 15.25 in X 22 in 15.25 in X 22 in 43 in x 39 in
