Product Description
Chasing Cerulean Omniscan Sonar | Model 450-FS | Maximum Operating Depth 100 & 300 meters | For Chasing M2 Pro Max
Description
The Omniscan 450 FS is ideally suited for forward looking ROV applications. The transducer and electronics are housed in a single enclosure with the CHASING Ethernet + power interface. Two enclosure options are available for 100m or 300m depth rating.
As the M2 Pro Max moves, Cerulean SonarView “paints” the image of the scanned area of the sea floor giving excellent situational awareness in the murkiest conditions. For vehicles without positioning information, Omniscan's Dopper Position Tracking can be used for translational information in the direction of the beam. Using a pair of Omniscan 450 FS units, one forward and one 90 degrees to either side, full 2d motion tracking is available
What's in the Box
- Omniscan (100m or 300m) with Ethernet × 1
- Power Wiring Cable × 1
- Blue Robotics RJ45 to JST GH Adapter × 1
Key Features
- Forward-Looking ROV Applications: Ideal for scanning the sea floor and providing situational awareness.
- Single Enclosure Design: Houses both the transducer and electronics with Ethernet and power interfaces.
- Depth Rating Options: Available in 100m or 300m versions.
- Translational and Rotational Scanning: Provides comprehensive area scanning with Doppler Position Tracking.
- Manual Operator Control: Allows direct control of scanning for focused inspection.
- Dual Models: Available in FS (forward scanning) and SS (side scanning) versions.
- High-Brightness Display: 13-inch 1000cd/m² screen for clear viewing under direct sunlight.
Detailed Specifications
| Feature | Specification |
|---|---|
| Viewing Software | SonarView by Cerulean |
| Frequency | 450 kHz |
| Range Resolution | Up to 1/1200 of range setting |
| Maximum Ping Rate | 20 pings per second (up to 30m range) |
| 10 pings per second (at 50m range) | |
| 5 pings per second (at 140m range) | |
| Power Supply | 10-30 Volts, 5 watts max at idle, 10 watts max while pinging |
| Data Interface | CHASING Ethernet cable |
| Electrical Connection | CHASING Ethernet cable |
| Maximum Range | 100m |
| Far Field (Note 1) | 7m |
| Beam Width (Note 2) | 0.8° |
| Beam Height | 50° |
| Maximum Operating Depth | 100m and 300m versions |
| Weight in Air | 440g (100m), 825g (300m) |
| Weight in Water | -60g (100m), +325g (300m) |
| Overall Dimensions | 55x67x200mm |
